SDO HMI 2011-10-13 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 106.52 | 722.29 | 63.44 | 433.04 | 26.90 | 57.34 | -28.36 | 48.89 | 0.5637 | -674.5 | -330.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-13 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.10 | 0.00 | 1.23 | 25.43 | 59.00 | -26.71 | 49.82 | 0.5333 | 548.0 | 382.8 | |
| 102.15 | 623.31 | 60.73 | 370.80 | 27.03 | 58.18 | -27.52 | 48.10 | 0.5552 | -1148.7 | -378.0 | |
| 0.87 | 18.80 | 0.53 | 11.43 | 28.02 | 56.56 | -29.15 | 48.04 | 0.5804 | -569.9 | -80.0 | |
| 0.00 | 3.24 | 0.00 | 1.94 | 26.28 | 56.64 | -29.07 | 50.56 | 0.5663 | -737.0 | -645.8 | |
| 0.00 | 1.57 | 0.00 | 0.91 | 20.65 | 57.75 | -27.96 | 58.93 | 0.5143 | -736.0 | -585.9 | |
| 0.00 | 1.84 | 0.00 | 1.11 | 26.58 | 56.13 | -29.58 | 50.52 | 0.5741 | -639.0 | -541.5 | |
| 0.00 | 1.22 | 0.00 | 0.74 | 26.32 | 56.16 | -29.54 | 50.88 | 0.5719 | -620.0 | -550.4 | |
| 0.00 | 1.40 | 0.00 | 0.85 | 26.69 | 55.90 | -29.80 | 50.52 | 0.5775 | -527.0 | -479.9 | |
| 0.00 | 1.57 | 0.00 | 0.91 | 20.01 | 57.37 | -28.34 | 60.35 | 0.5153 | -701.0 | -575.3 | |
| 0.00 | 1.22 | 0.00 | 0.74 | 26.81 | 55.64 | -30.07 | 50.56 | 0.5812 | -537.0 | -451.3 | |
| 0.00 | 0.61 | 0.00 | 0.37 | 25.32 | 56.06 | -29.65 | 52.49 | 0.5659 | -686.0 | -538.9 | |
| 0.00 | 1.49 | 0.00 | 0.90 | 26.55 | 55.52 | -30.18 | 51.05 | 0.5806 | -630.0 | -463.8 | |
| 0.00 | 2.01 | 0.00 | 1.21 | 25.22 | 55.86 | -29.85 | 52.81 | 0.5674 | -721.0 | -565.6 | |
| 0.00 | 1.14 | 0.00 | 0.69 | 27.11 | 55.28 | -30.43 | 50.39 | 0.5874 | -440.0 | -267.8 | |
| 0.00 | 0.96 | 0.00 | 0.60 | 29.44 | 54.16 | -31.54 | 47.93 | 0.6160 | -583.0 | -461.8 | |
| 0.00 | 0.87 | 0.00 | 0.53 | 26.55 | 54.98 | -30.73 | 51.46 | 0.5866 | -700.0 | -477.9 | |
| 0.00 | 1.14 | 0.00 | 0.66 | 19.55 | 56.66 | -29.05 | 61.67 | 0.5218 | -639.0 | -479.4 | |
| 0.00 | 1.22 | 0.00 | 0.75 | 26.74 | 54.80 | -30.90 | 51.31 | 0.5898 | -406.0 | -357.7 | |
| 0.00 | 0.96 | 0.00 | 0.59 | 27.24 | 54.65 | -31.06 | 50.68 | 0.5951 | -554.0 | -392.3 | |
| 0.00 | 1.05 | 0.00 | 0.66 | 29.13 | 53.91 | -31.80 | 48.55 | 0.6164 | -611.0 | -528.2 | |
| 0.00 | 2.10 | 0.00 | 1.29 | 27.04 | 54.47 | -31.23 | 51.11 | 0.5956 | -577.0 | -336.1 | |
| 0.00 | 0.79 | 0.00 | 0.49 | 28.63 | 53.72 | -31.99 | 49.39 | 0.6148 | -621.0 | -516.6 | |
| 0.00 | 0.87 | 0.00 | 0.55 | 28.68 | 53.46 | -32.25 | 49.51 | 0.6178 | -629.0 | -505.3 | |
| 0.00 | 2.62 | 0.00 | 1.64 | 28.07 | 53.63 | -32.08 | 50.25 | 0.6118 | -591.0 | -514.9 | |
| 2.80 | 14.69 | 1.74 | 9.16 | 27.49 | 53.78 | -31.93 | 50.97 | 0.6062 | 415.7 | -410.0 | |
| 0.00 | 0.96 | 0.00 | 0.60 | 27.83 | 53.51 | -32.20 | 50.67 | 0.6115 | -767.0 | -607.2 | |
| 0.70 | 3.94 | 0.44 | 2.47 | 27.54 | 52.96 | -32.75 | 51.47 | 0.6154 | -495.9 | -522.1 | |
| 0.00 | 1.14 | 0.00 | 0.71 | 26.29 | 52.41 | -33.29 | 53.65 | 0.6133 | -582.0 | -503.2 | |
| 0.00 | 0.79 | 0.00 | 0.50 | 20.99 | 48.36 | -37.34 | 63.81 | 0.6334 | 598.0 | 444.9 | |
| 0.00 | 1.40 | 0.00 | 0.90 | 21.14 | 48.28 | -37.43 | 63.62 | 0.6351 | 295.0 | 350.1 | |
| 0.00 | 1.84 | 0.00 | 1.16 | 19.69 | 48.57 | -37.14 | 65.70 | 0.6259 | 776.0 | 645.4 | |
| 0.00 | 2.01 | 0.00 | 1.30 | 21.76 | 47.80 | -37.90 | 62.88 | 0.6433 | 751.0 | 444.9 | |
| 0.00 | 1.05 | 0.00 | 0.72 | 27.33 | 45.47 | -40.23 | 56.09 | 0.6937 | 605.0 | 480.2 | |
| 0.00 | 0.79 | 0.00 | 0.54 | 26.27 | 45.58 | -40.13 | 57.48 | 0.6878 | 430.0 | 430.8 | |
| 0.00 | 0.79 | 0.00 | 0.51 | 22.09 | 47.04 | -38.67 | 62.73 | 0.6536 | 595.0 | 484.0 | |
| 0.00 | 2.19 | 0.00 | 1.44 | 21.90 | 46.40 | -39.31 | 63.28 | 0.6604 | 707.0 | 609.8 | |
| 0.00 | 0.52 | 0.00 | 0.36 | 26.02 | 44.80 | -40.91 | 58.16 | 0.6950 | 624.0 | 537.0 | |
| 0.00 | 1.31 | 0.00 | 0.84 | 18.92 | 47.21 | -38.50 | 67.40 | 0.6401 | 558.0 | 458.7 | |
| 0.00 | 1.31 | 0.00 | 0.88 | 23.67 | 45.52 | -40.19 | 61.11 | 0.6773 | 665.0 | 580.4 | |
| 0.00 | 1.14 | 0.00 | 0.76 | 23.48 | 45.55 | -40.16 | 61.36 | 0.6763 | 649.0 | 593.7 | |
| 0.00 | 1.22 | 0.00 | 0.84 | 25.66 | 44.69 | -41.02 | 58.70 | 0.6946 | 751.0 | 601.3 | |
| 0.00 | 0.87 | 0.00 | 0.61 | 26.75 | 43.99 | -41.71 | 57.54 | 0.7065 | 475.0 | 462.6 | |
| 0.00 | 1.92 | 0.00 | 1.34 | 26.52 | 43.96 | -41.75 | 57.86 | 0.7059 | 548.0 | 485.3 | |
| 0.00 | 1.84 | 0.00 | 1.29 | 26.56 | 43.67 | -42.04 | 57.93 | 0.7091 | 524.0 | 408.6 | |
| 0.00 | 2.27 | 0.00 | 1.58 | 25.62 | 44.00 | -41.71 | 59.06 | 0.7018 | 549.0 | 541.0 | |
| 0.00 | 3.15 | 0.00 | 2.19 | 25.83 | 43.82 | -41.89 | 58.85 | 0.7046 | 678.0 | 584.8 | |
| 0.00 | 1.05 | 0.00 | 0.75 | 26.76 | 42.21 | -43.50 | 58.27 | 0.7250 | 491.0 | 360.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
