SDO HMI 2011-10-13 14:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 40.21 | 114.34 | 21.11 | 60.02 | 19.98 | 97.76 | 13.71 | 317.73 | 0.3330 | -186.9 | -229.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-13 14:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.05 | 59.62 | 0.55 | 31.33 | 19.58 | 99.00 | 14.94 | 314.42 | 0.3417 | -588.4 | -539.0 | |
| 0.00 | 1.75 | 0.00 | 0.92 | 19.79 | 98.92 | 14.87 | 315.04 | 0.3432 | -699.0 | -615.2 | |
| 13.37 | -1.00 | 7.03 | -1.00 | 19.43 | 98.69 | 14.64 | 314.67 | 0.3365 | -1111.3 | 999999 | |
| 5.24 | 8.39 | 2.77 | 4.42 | 20.08 | 98.72 | 14.66 | 316.03 | 0.3440 | -930.6 | -779.8 | |
| 2.80 | -1.00 | 1.47 | -1.00 | 19.35 | 98.42 | 14.37 | 314.98 | 0.3324 | -1202.2 | 999999 | |
| 0.00 | 2.80 | 0.00 | 1.47 | 19.94 | 98.18 | 14.12 | 316.75 | 0.3363 | -915.0 | -793.6 | |
| 0.00 | 0.44 | 0.00 | 0.23 | 19.63 | 98.09 | 14.03 | 316.26 | 0.3318 | -748.0 | -588.8 | |
| 0.00 | 2.88 | 0.00 | 1.51 | 19.26 | 97.93 | 13.87 | 315.76 | 0.3258 | -1081.0 | -857.0 | |
| 0.00 | 1.31 | 0.00 | 0.69 | 19.34 | 97.31 | 13.26 | 317.17 | 0.3197 | 580.0 | 427.9 | |
| 4.46 | 35.75 | 2.34 | 18.72 | 21.22 | 96.36 | 12.30 | 323.12 | 0.3324 | 820.8 | 706.5 | |
| 1.75 | -10.00 | 0.91 | -10.00 | 20.57 | 95.91 | 11.86 | 322.84 | 0.3199 | 900.3 | 999999 | |
| 11.19 | -10.00 | 5.86 | -10.00 | 20.98 | 95.91 | 11.86 | 323.64 | 0.3250 | 1096.2 | 999999 | |
| 0.35 | 1.40 | 0.18 | 0.73 | 19.84 | 95.40 | 11.35 | 322.51 | 0.3054 | 944.2 | 845.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
