SDO HMI 2011-10-13 16:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 39.68 | 111.45 | 20.93 | 58.79 | 19.93 | 97.86 | 14.90 | 315.36 | 0.3457 | -241.7 | -211.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-13 16:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.20 | 0.00 | 2.22 | 19.85 | 99.01 | 16.06 | 313.08 | 0.3578 | -657.0 | -496.0 | |
| 14.33 | 61.27 | 7.58 | 32.37 | 19.52 | 98.82 | 15.86 | 312.69 | 0.3519 | -1028.1 | -529.1 | |
| 5.42 | 7.25 | 2.87 | 3.84 | 20.07 | 98.81 | 15.85 | 313.91 | 0.3577 | -926.2 | -814.7 | |
| 4.02 | -2.00 | 2.12 | -2.00 | 19.41 | 98.44 | 15.49 | 313.08 | 0.3463 | -1183.5 | 999999 | |
| 0.00 | 1.66 | 0.00 | 0.88 | 20.00 | 98.30 | 15.35 | 314.62 | 0.3509 | -921.0 | -783.4 | |
| 1.57 | 2.10 | 0.83 | 1.10 | 19.30 | 97.97 | 15.02 | 313.66 | 0.3395 | -906.3 | -916.8 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 19.38 | 97.13 | 14.17 | 315.43 | 0.3306 | 776.0 | 624.3 | |
| 0.00 | 1.49 | 0.00 | 0.78 | 19.39 | 96.57 | 13.62 | 316.55 | 0.3244 | -865.0 | -699.1 | |
| 11.45 | 25.96 | 6.02 | 13.66 | 20.95 | 95.92 | 12.97 | 321.18 | 0.3358 | 1086.1 | 703.7 | |
| 2.45 | 4.20 | 1.28 | 2.20 | 20.49 | 95.88 | 12.93 | 320.33 | 0.3297 | 980.7 | 910.3 | |
| 0.44 | 2.18 | 0.23 | 1.14 | 19.82 | 95.27 | 12.32 | 320.24 | 0.3152 | 1072.6 | 850.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
