SDO HMI 2011-10-13 20:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.48 | 188.54 | 24.03 | 128.37 | -14.75 | 119.11 | 38.36 | 240.96 | 0.6885 | 310.9 | 274.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-13 20:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 7.60 | 0.00 | 5.38 | -13.69 | 122.13 | 41.38 | 244.12 | 0.7162 | 690.0 | 517.8 | |
| 0.00 | 1.31 | 0.00 | 0.91 | -13.25 | 121.26 | 40.51 | 244.22 | 0.7045 | 677.0 | 579.3 | |
| 0.00 | 0.70 | 0.00 | 0.49 | -14.98 | 121.51 | 40.76 | 242.13 | 0.7159 | 460.0 | 454.2 | |
| 0.00 | 1.31 | 0.00 | 0.92 | -13.85 | 121.22 | 40.47 | 243.42 | 0.7070 | 547.0 | 462.9 | |
| 0.00 | 0.79 | 0.00 | 0.54 | -13.02 | 120.65 | 39.90 | 244.20 | 0.6965 | 589.0 | 534.7 | |
| 0.00 | 1.49 | 0.00 | 1.02 | -13.52 | 120.15 | 39.40 | 243.25 | 0.6934 | 660.0 | 545.2 | |
| 0.00 | 2.36 | 0.00 | 1.61 | -13.37 | 119.72 | 38.97 | 243.21 | 0.6878 | 796.0 | 653.3 | |
| 1.22 | 137.65 | 0.84 | 94.59 | -14.07 | 119.82 | 39.07 | 242.34 | 0.6926 | 828.6 | 404.5 | |
| 25.96 | -8.00 | 17.87 | -8.00 | -14.71 | 119.87 | 39.12 | 241.54 | 0.6966 | 982.2 | 999999 | |
| 1.22 | -8.00 | 0.84 | -8.00 | -15.11 | 119.64 | 38.89 | 240.88 | 0.6962 | 736.6 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.67 | -16.77 | 119.67 | 38.92 | 238.76 | 0.7058 | 469.0 | 378.2 | |
| 0.00 | 1.05 | 0.00 | 0.73 | -16.72 | 119.37 | 38.62 | 238.64 | 0.7024 | 233.0 | 290.7 | |
| 0.00 | 1.49 | 0.00 | 1.03 | -17.46 | 118.79 | 38.05 | 237.34 | 0.7007 | -387.0 | -501.9 | |
| 0.00 | 1.84 | 0.00 | 1.21 | -14.66 | 116.81 | 36.06 | 239.65 | 0.6623 | -686.0 | -596.5 | |
| 0.00 | 0.96 | 0.00 | 0.64 | -14.86 | 116.85 | 36.10 | 239.42 | 0.6639 | -604.0 | -466.4 | |
| 0.00 | 0.96 | 0.00 | 0.63 | -14.98 | 116.72 | 35.97 | 239.17 | 0.6631 | -600.0 | -507.5 | |
| 0.00 | 1.14 | 0.00 | 0.74 | -14.58 | 115.50 | 34.76 | 238.85 | 0.6470 | -554.0 | -504.3 | |
| 0.00 | 1.49 | 0.00 | 0.98 | -16.22 | 115.63 | 34.88 | 236.75 | 0.6590 | -459.0 | -323.9 | |
| 0.00 | 1.49 | 0.00 | 0.95 | -13.70 | 115.09 | 34.34 | 239.77 | 0.6366 | 851.0 | 691.7 | |
| 0.00 | 0.96 | 0.00 | 0.63 | -16.47 | 115.00 | 34.25 | 235.95 | 0.6538 | -567.0 | -470.9 | |
| 0.00 | 1.14 | 0.00 | 0.74 | -16.39 | 114.72 | 33.97 | 235.84 | 0.6501 | -792.0 | -684.5 | |
| 5.77 | 6.47 | 3.63 | 4.07 | -13.00 | 113.97 | 33.23 | 239.95 | 0.6191 | 831.8 | 681.5 | |
| 0.00 | 1.31 | 0.00 | 0.85 | -16.74 | 114.60 | 33.85 | 235.29 | 0.6512 | -587.0 | -518.4 | |
| 0.00 | 1.14 | 0.00 | 0.73 | -16.27 | 114.32 | 33.57 | 235.70 | 0.6449 | -739.0 | -650.8 | |
| 1.31 | 2.10 | 0.85 | 1.36 | -16.46 | 114.28 | 33.53 | 235.41 | 0.6458 | -753.6 | -766.2 | |
| 0.00 | 1.22 | 0.00 | 0.79 | -16.16 | 114.11 | 33.36 | 235.68 | 0.6419 | -706.0 | -571.4 | |
| 0.00 | 1.66 | 0.00 | 1.07 | -16.57 | 114.00 | 33.26 | 235.05 | 0.6436 | -701.0 | -551.1 | |
| 0.00 | 1.31 | 0.00 | 0.84 | -16.15 | 113.92 | 33.17 | 235.55 | 0.6397 | -702.0 | -581.1 | |
| 0.00 | 2.62 | 0.00 | 1.70 | -16.95 | 113.89 | 33.15 | 234.46 | 0.6451 | -709.0 | -624.5 | |
| 0.00 | 2.45 | 0.00 | 1.55 | -15.70 | 112.95 | 32.20 | 235.37 | 0.6258 | -912.0 | -711.9 | |
| 0.00 | 0.87 | 0.00 | 0.55 | -15.26 | 112.47 | 31.72 | 235.59 | 0.6172 | -959.0 | -730.3 | |
| 0.00 | 0.70 | 0.00 | 0.45 | -17.93 | 112.27 | 31.52 | 231.84 | 0.6349 | -690.0 | -503.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
