SDO HMI 2011-10-13 21:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 35.67 | 109.35 | 19.09 | 58.48 | 19.86 | 97.92 | 17.73 | 310.58 | 0.3786 | -277.9 | -226.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-13 21:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.73 | 10.93 | 3.63 | 5.88 | 20.08 | 99.08 | 18.89 | 309.26 | 0.3944 | -767.8 | -379.2 | |
| 17.92 | 60.92 | 9.61 | 32.67 | 19.53 | 98.81 | 18.62 | 308.48 | 0.3860 | -1042.1 | -485.1 | |
| 0.00 | 3.76 | 0.00 | 2.02 | 20.03 | 98.44 | 18.24 | 310.08 | 0.3861 | -907.0 | -770.7 | |
| 0.00 | 1.14 | 0.00 | 0.61 | 19.64 | 98.16 | 17.96 | 309.65 | 0.3789 | -923.0 | -742.6 | |
| 0.00 | 1.22 | 0.00 | 0.65 | 19.34 | 97.92 | 17.73 | 309.34 | 0.3731 | -865.0 | -648.6 | |
| 0.00 | 1.31 | 0.00 | 0.70 | 19.10 | 96.87 | 16.67 | 310.40 | 0.3576 | -903.0 | -705.7 | |
| 0.00 | 0.96 | 0.00 | 0.51 | 21.34 | 96.08 | 15.89 | 316.46 | 0.3718 | 687.0 | 573.0 | |
| 8.92 | 15.91 | 4.74 | 8.47 | 20.94 | 95.94 | 15.74 | 315.91 | 0.3658 | 1028.2 | 720.4 | |
| 2.10 | 4.11 | 1.11 | 2.18 | 20.51 | 95.83 | 15.63 | 315.21 | 0.3598 | 982.6 | 804.8 | |
| 0.00 | 4.28 | 0.00 | 2.26 | 19.26 | 95.44 | 15.24 | 313.18 | 0.3418 | 596.0 | 176.4 | |
| 0.00 | 3.76 | 0.00 | 1.98 | 19.92 | 95.01 | 14.81 | 315.41 | 0.3439 | 778.0 | 731.0 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 20.48 | 93.45 | 13.26 | 319.63 | 0.3331 | 845.0 | 674.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
