SDO HMI 2011-10-14 00:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 163.14 | 809.29 | 98.24 | 489.27 | -12.23 | 48.58 | -29.96 | 121.65 | 0.5743 | 68.0 | -83.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-14 00:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 50.45 | 237.12 | 29.26 | 137.37 | -11.68 | 52.51 | -26.03 | 124.29 | 0.5223 | 1137.6 | 514.4 | |
| 0.26 | -1.00 | 0.15 | -1.00 | -12.03 | 52.47 | -26.07 | 124.81 | 0.5256 | 529.3 | 999999 | |
| 2.36 | 3.06 | 1.40 | 1.81 | -13.70 | 51.77 | -26.78 | 126.68 | 0.5479 | 805.7 | 627.9 | |
| 0.00 | 1.05 | 0.00 | 0.62 | -13.51 | 51.72 | -26.82 | 126.35 | 0.5469 | 36.0 | 66.6 | |
| 0.00 | 0.96 | 0.00 | 0.57 | -12.60 | 51.66 | -26.89 | 124.89 | 0.5401 | 605.0 | 346.7 | |
| 0.00 | 0.96 | 0.00 | 0.57 | -12.42 | 51.50 | -27.04 | 124.46 | 0.5405 | 602.0 | 399.1 | |
| 0.00 | 1.49 | 0.00 | 0.87 | -11.16 | 51.60 | -26.94 | 122.55 | 0.5294 | -82.0 | -45.1 | |
| 0.00 | 1.31 | 0.00 | 0.77 | -11.82 | 51.50 | -27.04 | 123.52 | 0.5358 | 705.0 | 550.7 | |
| 2.19 | 102.12 | 1.29 | 60.51 | -12.66 | 51.06 | -27.48 | 124.40 | 0.5478 | -326.4 | 234.9 | |
| 29.47 | -9.00 | 17.43 | -9.00 | -12.30 | 50.76 | -27.78 | 123.55 | 0.5486 | 939.2 | 999999 | |
| 0.00 | 1.40 | 0.00 | 0.84 | -14.05 | 49.84 | -28.70 | 125.33 | 0.5733 | 733.0 | 591.2 | |
| 0.00 | 1.14 | 0.00 | 0.68 | -12.13 | 49.73 | -28.81 | 122.35 | 0.5598 | 398.0 | 309.5 | |
| 0.00 | 0.87 | 0.00 | 0.53 | -13.35 | 49.37 | -29.17 | 123.86 | 0.5733 | 437.0 | 361.8 | |
| 0.00 | 1.14 | 0.00 | 0.70 | -13.74 | 47.96 | -30.58 | 123.21 | 0.5928 | -831.0 | -698.1 | |
| 0.00 | 1.40 | 0.00 | 0.86 | -13.95 | 47.68 | -30.86 | 123.27 | 0.5976 | -889.0 | -582.4 | |
| 3.58 | 449.33 | 2.17 | 278.85 | -11.27 | 47.69 | -30.86 | 119.29 | 0.5789 | 856.1 | -421.2 | |
| 0.00 | 2.27 | 0.00 | 1.41 | -13.91 | 47.15 | -31.39 | 122.78 | 0.6036 | -704.0 | -619.0 | |
| 0.00 | 0.52 | 0.00 | 0.32 | -10.74 | 47.21 | -31.33 | 118.10 | 0.5813 | 473.0 | 353.0 | |
| 3.50 | -16.00 | 2.16 | -16.00 | -12.27 | 46.63 | -31.92 | 119.97 | 0.5986 | -1168.2 | 999999 | |
| 20.72 | -16.00 | 12.86 | -16.00 | -12.91 | 46.50 | -32.04 | 120.80 | 0.6043 | -1120.0 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.72 | -14.23 | 45.97 | -32.57 | 122.29 | 0.6196 | -687.0 | -617.2 | |
| 5.51 | -16.00 | 3.43 | -16.00 | -13.02 | 46.12 | -32.42 | 120.68 | 0.6096 | -890.3 | 999999 | |
| 5.68 | -16.00 | 3.52 | -16.00 | -12.27 | 46.16 | -32.39 | 119.60 | 0.6042 | -1036.6 | 999999 | |
| 2.54 | -16.00 | 1.57 | -16.00 | -11.73 | 46.16 | -32.39 | 118.81 | 0.6008 | -1114.0 | 999999 | |
| 7.43 | -16.00 | 4.64 | -16.00 | -12.91 | 45.92 | -32.62 | 120.36 | 0.6113 | -776.4 | 999999 | |
| 0.00 | 2.01 | 0.00 | 1.27 | -14.16 | 45.65 | -32.89 | 121.93 | 0.6227 | -720.0 | -531.1 | |
| 2.62 | -16.00 | 1.62 | -16.00 | -11.62 | 45.92 | -32.63 | 118.47 | 0.6030 | -1177.0 | 999999 | |
| 9.18 | -16.00 | 5.73 | -16.00 | -12.54 | 45.79 | -32.75 | 119.73 | 0.6104 | -902.6 | 999999 | |
| 0.87 | -16.00 | 0.54 | -16.00 | -11.73 | 45.72 | -32.82 | 118.48 | 0.6061 | -808.1 | 999999 | |
| 13.55 | -16.00 | 8.45 | -16.00 | -12.05 | 45.64 | -32.90 | 118.89 | 0.6090 | -882.3 | 999999 | |
| 1.66 | -16.00 | 1.03 | -16.00 | -11.52 | 45.57 | -32.98 | 118.06 | 0.6066 | -730.0 | 999999 | |
| 1.57 | -16.00 | 0.99 | -16.00 | -11.91 | 45.22 | -33.32 | 118.40 | 0.6133 | -511.9 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
