SDO HMI 2011-10-14 02:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 71.19 | 457.81 | 49.23 | 317.07 | 23.23 | 119.82 | 42.38 | 297.44 | 0.7003 | -993.0 | -362.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-14 02:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.05 | 0.00 | 0.75 | 22.77 | 122.25 | 44.80 | 295.99 | 0.7252 | 495.0 | 359.3 | |
| 0.00 | 2.19 | 0.00 | 1.56 | 22.50 | 122.09 | 44.65 | 295.68 | 0.7227 | 614.0 | 433.8 | |
| 0.00 | 1.05 | 0.00 | 0.75 | 22.40 | 121.73 | 44.29 | 295.65 | 0.7185 | 610.0 | 462.5 | |
| 0.00 | 1.05 | 0.00 | 0.74 | 23.11 | 121.48 | 44.03 | 296.70 | 0.7179 | 198.0 | 136.5 | |
| 0.79 | 447.50 | 0.55 | 309.90 | 22.53 | 120.21 | 42.77 | 296.34 | 0.7022 | -816.1 | -379.8 | |
| 0.00 | 1.57 | 0.00 | 1.11 | 24.46 | 120.78 | 43.34 | 298.77 | 0.7149 | 261.0 | 278.4 | |
| 70.40 | -5.00 | 48.68 | -5.00 | 23.22 | 119.82 | 42.38 | 297.43 | 0.7002 | -1215.9 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.84 | 25.52 | 118.37 | 40.93 | 301.16 | 0.6932 | -665.0 | -540.2 | |
| 0.00 | 0.61 | 0.00 | 0.40 | 25.75 | 114.27 | 36.82 | 303.47 | 0.6495 | 466.0 | 340.6 | |
| 0.00 | 1.57 | 0.00 | 1.02 | 25.80 | 113.87 | 36.43 | 303.77 | 0.6454 | 829.0 | 577.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
