SDO HMI 2011-10-14 09:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 29.99 | 147.29 | 23.09 | 112.73 | -14.78 | 119.08 | 45.47 | 244.80 | 0.7638 | 302.8 | 126.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-14 09:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.27 | 119.52 | 1.75 | 92.70 | -14.04 | 119.88 | 46.27 | 246.10 | 0.7691 | 696.9 | 253.6 | |
| 24.74 | -1.00 | 19.20 | -1.00 | -14.65 | 119.91 | 46.30 | 245.37 | 0.7718 | 878.2 | 999999 | |
| 0.00 | 1.40 | 0.00 | 1.12 | -17.17 | 120.68 | 47.07 | 242.71 | 0.7894 | 425.0 | 346.4 | |
| 0.79 | 1.75 | 0.61 | 1.36 | -17.60 | 118.78 | 45.17 | 241.29 | 0.7730 | -644.1 | -444.1 | |
| 0.00 | 1.40 | 0.00 | 1.03 | -15.00 | 116.64 | 43.03 | 243.37 | 0.7397 | -599.0 | -502.8 | |
| 0.00 | 0.96 | 0.00 | 0.69 | -14.57 | 115.86 | 42.25 | 243.51 | 0.7294 | -553.0 | -530.6 | |
| 0.00 | 1.22 | 0.00 | 0.88 | -15.55 | 115.43 | 41.82 | 242.04 | 0.7296 | -684.0 | -520.1 | |
| 2.19 | 2.97 | 1.53 | 2.08 | -12.81 | 114.69 | 41.08 | 245.17 | 0.7084 | 720.5 | 631.3 | |
| 0.00 | 1.22 | 0.00 | 0.89 | -16.37 | 115.22 | 41.61 | 240.91 | 0.7315 | -407.0 | -356.0 | |
| 0.00 | 0.87 | 0.00 | 0.63 | -16.62 | 115.17 | 41.55 | 240.56 | 0.7322 | -461.0 | -379.5 | |
| 0.00 | 1.31 | 0.00 | 0.94 | -16.06 | 114.89 | 41.28 | 241.11 | 0.7265 | -692.0 | -578.0 | |
| 0.00 | 3.32 | 0.00 | 2.39 | -16.38 | 114.93 | 41.32 | 240.73 | 0.7285 | -733.0 | -597.8 | |
| 0.00 | 3.67 | 0.00 | 2.63 | -16.29 | 114.58 | 40.97 | 240.64 | 0.7244 | -758.0 | -659.6 | |
| 0.00 | 1.22 | 0.00 | 0.88 | -16.65 | 114.59 | 40.98 | 240.20 | 0.7263 | -711.0 | -612.7 | |
| 0.00 | 1.05 | 0.00 | 0.76 | -17.27 | 114.67 | 41.06 | 239.49 | 0.7304 | -535.0 | -430.0 | |
| 0.00 | 0.26 | 0.00 | 0.19 | -16.60 | 114.41 | 40.80 | 240.16 | 0.7242 | -662.0 | -608.7 | |
| 0.00 | 0.87 | 0.00 | 0.62 | -16.42 | 114.03 | 40.42 | 240.17 | 0.7193 | -465.0 | -403.4 | |
| 0.00 | 2.71 | 0.00 | 1.88 | -14.27 | 113.45 | 39.84 | 242.58 | 0.7018 | -708.0 | -417.9 | |
| 0.00 | 1.57 | 0.00 | 1.06 | -12.59 | 112.40 | 38.79 | 244.21 | 0.6814 | 287.0 | 359.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
