SDO HMI 2011-10-14 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 120.54 | 726.01 | 66.11 | 399.64 | 27.01 | 57.22 | -15.30 | 32.71 | 0.4356 | -783.8 | -363.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-14 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.79 | 0.00 | 0.43 | 28.89 | 59.41 | -13.10 | 26.82 | 0.4417 | 692.0 | 569.4 | |
| 0.00 | 2.27 | 0.00 | 1.25 | 28.86 | 59.14 | -13.38 | 27.34 | 0.4431 | 596.0 | 609.8 | |
| 3.23 | 651.45 | 1.76 | 357.34 | 26.98 | 59.03 | -13.49 | 29.88 | 0.4190 | -1076.1 | -394.9 | |
| 1.40 | -3.00 | 0.76 | -3.00 | 26.75 | 58.81 | -13.70 | 30.57 | 0.4176 | -1158.5 | 999999 | |
| 109.96 | -3.00 | 60.28 | -3.00 | 27.14 | 57.90 | -14.62 | 31.61 | 0.4302 | -1303.7 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.78 | 18.61 | 58.78 | -13.74 | 45.34 | 0.3178 | -806.0 | -606.8 | |
| 0.00 | 3.50 | 0.00 | 1.84 | 19.93 | 58.60 | -13.92 | 42.72 | 0.3347 | -783.0 | -691.2 | |
| 1.66 | -3.00 | 0.92 | -3.00 | 27.81 | 57.39 | -15.13 | 31.56 | 0.4429 | -751.4 | 999999 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 19.83 | 58.08 | -14.43 | 43.94 | 0.3393 | -829.0 | -631.1 | |
| 1.05 | -3.00 | 0.58 | -3.00 | 26.74 | 57.22 | -15.29 | 33.30 | 0.4308 | -1076.0 | 999999 | |
| 0.00 | 0.52 | 0.00 | 0.28 | 24.71 | 57.49 | -15.03 | 35.91 | 0.4032 | 790.0 | 592.7 | |
| 0.00 | 0.79 | 0.00 | 0.42 | 20.46 | 57.66 | -14.85 | 43.38 | 0.3512 | -830.0 | -682.0 | |
| 0.00 | 0.96 | 0.00 | 0.54 | 28.13 | 55.93 | -16.58 | 33.41 | 0.4590 | -611.0 | -524.7 | |
| 0.00 | 0.52 | 0.00 | 0.30 | 31.05 | 55.24 | -17.27 | 30.69 | 0.5004 | -513.0 | -516.0 | |
| 1.14 | 4.20 | 0.63 | 2.33 | 27.80 | 55.74 | -16.78 | 34.16 | 0.4567 | -727.2 | -673.1 | |
| 0.00 | 4.28 | 0.00 | 2.38 | 27.37 | 55.59 | -16.92 | 34.97 | 0.4529 | -774.0 | -680.8 | |
| 0.00 | 4.81 | 0.00 | 2.67 | 26.81 | 54.98 | -17.54 | 36.71 | 0.4518 | -1115.0 | -876.2 | |
| 0.00 | 4.20 | 0.00 | 2.34 | 27.51 | 54.72 | -17.79 | 36.06 | 0.4623 | -924.0 | -732.6 | |
| 0.00 | 2.71 | 0.00 | 1.51 | 26.89 | 54.44 | -18.08 | 37.38 | 0.4578 | -834.0 | -618.5 | |
| 0.00 | 0.96 | 0.00 | 0.55 | 29.13 | 53.64 | -18.87 | 35.31 | 0.4908 | -675.0 | -510.7 | |
| 0.00 | 2.36 | 0.00 | 1.32 | 27.39 | 53.93 | -18.59 | 37.37 | 0.4683 | -993.0 | -827.2 | |
| 0.00 | 1.14 | 0.00 | 0.64 | 27.81 | 53.82 | -18.70 | 36.92 | 0.4740 | -691.0 | -645.3 | |
| 2.10 | 2.88 | 1.18 | 1.62 | 27.64 | 53.63 | -18.88 | 37.41 | 0.4738 | -754.3 | -593.2 | |
| 0.00 | 1.66 | 0.00 | 0.94 | 27.93 | 53.55 | -18.97 | 37.12 | 0.4779 | -715.0 | -630.1 | |
| 0.00 | 1.05 | 0.00 | 0.59 | 28.46 | 53.09 | -19.43 | 36.98 | 0.4882 | -708.0 | -595.5 | |
| 0.00 | 1.31 | 0.00 | 0.74 | 27.30 | 53.23 | -19.28 | 38.45 | 0.4739 | -685.0 | -594.0 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 26.69 | 53.13 | -19.39 | 39.51 | 0.4681 | -807.0 | -612.9 | |
| 0.00 | 0.87 | 0.00 | 0.49 | 27.68 | 52.84 | -19.68 | 38.43 | 0.4817 | -665.0 | -530.9 | |
| 0.00 | 1.05 | 0.00 | 0.59 | 26.23 | 51.79 | -20.73 | 41.98 | 0.4766 | -720.0 | -566.4 | |
| 0.00 | 2.19 | 0.00 | 1.24 | 26.78 | 51.22 | -21.30 | 41.83 | 0.4882 | -664.0 | -544.8 | |
| 0.00 | 1.49 | 0.00 | 0.84 | 22.12 | 47.83 | -24.69 | 53.37 | 0.4841 | 881.0 | 762.0 | |
| 0.00 | 0.87 | 0.00 | 0.49 | 19.31 | 48.11 | -24.41 | 58.38 | 0.4599 | 844.0 | 707.0 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 22.20 | 47.49 | -25.02 | 53.55 | 0.4888 | 650.0 | 583.5 | |
| 0.00 | 1.14 | 0.00 | 0.64 | 19.48 | 47.80 | -24.72 | 58.32 | 0.4651 | 756.0 | 637.9 | |
| 0.00 | 0.79 | 0.00 | 0.47 | 27.58 | 45.27 | -27.24 | 46.95 | 0.5574 | 489.0 | 433.6 | |
| 0.00 | 1.22 | 0.00 | 0.73 | 27.18 | 45.11 | -27.40 | 47.68 | 0.5559 | 645.0 | 596.9 | |
| 0.00 | 0.96 | 0.00 | 0.57 | 27.34 | 45.07 | -27.45 | 47.48 | 0.5576 | 476.0 | 410.6 | |
| 0.00 | 1.05 | 0.00 | 0.62 | 25.80 | 45.17 | -27.35 | 49.73 | 0.5442 | 797.0 | 660.3 | |
| 0.00 | 1.49 | 0.00 | 0.89 | 26.82 | 44.33 | -28.18 | 48.90 | 0.5614 | 559.0 | 540.2 | |
| 0.00 | 0.96 | 0.00 | 0.57 | 25.69 | 44.18 | -28.33 | 50.76 | 0.5544 | 733.0 | 576.1 | |
| 0.00 | 0.87 | 0.00 | 0.52 | 26.23 | 43.93 | -28.59 | 50.16 | 0.5612 | 707.0 | 569.0 | |
| 0.00 | 5.07 | 0.00 | 3.04 | 26.41 | 43.80 | -28.72 | 49.98 | 0.5641 | 646.0 | 637.5 | |
| 0.00 | 2.19 | 0.00 | 1.31 | 26.76 | 43.55 | -28.96 | 49.67 | 0.5694 | 588.0 | 493.2 | |
| 0.00 | 1.14 | 0.00 | 0.68 | 26.24 | 43.50 | -29.01 | 50.49 | 0.5660 | 529.0 | 465.4 | |
| 0.00 | 1.05 | 0.00 | 0.63 | 26.65 | 43.28 | -29.24 | 50.06 | 0.5716 | 574.0 | 489.9 | |
| 0.00 | 1.14 | 0.00 | 0.71 | 29.57 | 41.86 | -30.65 | 46.99 | 0.6086 | 667.0 | 547.3 | |
| 0.00 | 1.57 | 0.00 | 0.91 | 19.39 | 44.30 | -28.21 | 61.28 | 0.5105 | 743.0 | 571.8 | |
| 0.00 | 1.22 | 0.00 | 0.73 | 22.60 | 42.37 | -30.15 | 57.12 | 0.5543 | 704.0 | 609.6 | |
| 0.00 | 0.52 | 0.00 | 0.32 | 24.02 | 39.34 | -33.17 | 56.89 | 0.5989 | 562.0 | 617.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
