SDO HMI 2011-10-15 00:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 68.85 | 377.34 | 59.51 | 326.00 | 23.25 | 119.71 | 54.36 | 294.32 | 0.8215 | -680.8 | -309.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 00:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.05 | 0.00 | 0.96 | 22.91 | 122.14 | 56.79 | 293.51 | 0.8425 | 390.0 | 312.8 | |
| 2.53 | 3.06 | 2.22 | 2.68 | 21.35 | 120.61 | 55.26 | 291.89 | 0.8270 | 295.5 | 140.0 | |
| 0.00 | 1.84 | 0.00 | 1.61 | 21.60 | 120.69 | 55.34 | 292.17 | 0.8281 | 129.0 | 34.2 | |
| 1.66 | 366.23 | 1.49 | 316.24 | 23.21 | 121.21 | 55.86 | 294.01 | 0.8349 | -347.7 | -313.7 | |
| 0.00 | 5.16 | 0.00 | 4.51 | 22.00 | 120.42 | 55.07 | 292.70 | 0.8261 | -402.0 | -340.7 | |
| 5.59 | -4.00 | 5.00 | -4.00 | 23.40 | 121.16 | 55.81 | 294.25 | 0.8347 | 508.0 | 999999 | |
| 59.07 | -4.00 | 50.80 | -4.00 | 23.29 | 119.49 | 54.14 | 294.40 | 0.8196 | -892.8 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
