SDO HMI 2011-10-15 03:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 120.36 | 429.63 | 61.74 | 220.22 | 10.39 | 49.88 | -13.82 | 70.83 | 0.2504 | 39.8 | -57.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 03:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.41 | 71.76 | 6.22 | 35.98 | 8.86 | 55.13 | -8.57 | 70.27 | 0.1572 | -1390.7 | -629.4 | |
| 3.23 | -1.00 | 1.62 | -1.00 | 9.37 | 54.96 | -8.74 | 67.63 | 0.1629 | -979.6 | 999999 | |
| 0.00 | 2.88 | 0.00 | 1.45 | 8.65 | 54.89 | -8.81 | 72.02 | 0.1600 | -269.0 | -257.2 | |
| 5.51 | 5.68 | 2.78 | 2.86 | 9.31 | 53.40 | -10.30 | 70.89 | 0.1877 | -1077.7 | -1030.5 | |
| 0.00 | 0.79 | 0.00 | 0.40 | 8.71 | 53.42 | -10.29 | 73.96 | 0.1845 | -760.0 | -498.6 | |
| 3.58 | 58.65 | 1.81 | 29.68 | 9.76 | 53.08 | -10.63 | 69.21 | 0.1953 | -1157.7 | -649.7 | |
| 0.00 | 0.79 | 0.00 | 0.40 | 8.98 | 53.04 | -10.66 | 73.13 | 0.1919 | -965.0 | -776.9 | |
| 0.00 | 1.66 | 0.00 | 0.84 | 8.91 | 52.86 | -10.85 | 73.69 | 0.1946 | -1004.0 | -811.9 | |
| 0.00 | 4.72 | 0.00 | 2.38 | 9.18 | 52.85 | -10.85 | 72.37 | 0.1960 | -1014.0 | -884.5 | |
| 1.05 | -6.00 | 0.53 | -6.00 | 10.02 | 52.79 | -10.91 | 68.43 | 0.2014 | -956.6 | 999999 | |
| 11.36 | -6.00 | 5.75 | -6.00 | 9.78 | 52.67 | -11.03 | 69.76 | 0.2018 | -1163.3 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.49 | 9.48 | 52.62 | -11.08 | 71.26 | 0.2011 | -881.0 | -676.3 | |
| 0.00 | 2.10 | 0.00 | 1.09 | 18.42 | 52.14 | -11.56 | 40.99 | 0.2911 | -998.0 | -795.9 | |
| 0.00 | 1.31 | 0.00 | 0.66 | 9.18 | 52.54 | -11.16 | 72.82 | 0.2010 | -804.0 | -573.4 | |
| 0.00 | 2.62 | 0.00 | 1.33 | 9.35 | 52.44 | -11.26 | 72.11 | 0.2034 | -669.0 | -718.2 | |
| 0.00 | 0.87 | 0.00 | 0.44 | 8.90 | 52.39 | -11.31 | 74.32 | 0.2021 | -710.0 | -595.8 | |
| 2.88 | -6.00 | 1.46 | -6.00 | 9.98 | 52.30 | -11.41 | 69.41 | 0.2090 | -1026.5 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.58 | 9.40 | 52.01 | -11.70 | 72.45 | 0.2107 | -646.0 | -478.8 | |
| 0.00 | 2.71 | 0.00 | 1.37 | 9.49 | 51.60 | -12.10 | 72.59 | 0.2177 | -293.0 | -202.7 | |
| 0.00 | 4.98 | 0.00 | 2.53 | 10.23 | 51.54 | -12.16 | 69.41 | 0.2224 | -981.0 | -749.8 | |
| 2.53 | 8.83 | 1.29 | 4.49 | 10.68 | 51.34 | -12.36 | 67.84 | 0.2282 | -905.0 | -823.7 | |
| 0.00 | 1.57 | 0.00 | 0.80 | 11.88 | 51.25 | -12.45 | 63.20 | 0.2374 | -923.0 | -801.0 | |
| 1.75 | 32.78 | 0.89 | 16.68 | 9.54 | 51.20 | -12.51 | 72.86 | 0.2245 | -796.7 | 131.6 | |
| 0.00 | 1.22 | 0.00 | 0.62 | 10.41 | 51.16 | -12.54 | 69.23 | 0.2294 | -699.0 | -405.1 | |
| 0.00 | 1.49 | 0.00 | 0.76 | 10.46 | 50.97 | -12.73 | 69.26 | 0.2328 | -703.0 | -499.6 | |
| 1.49 | 5.94 | 0.76 | 3.02 | 10.04 | 50.93 | -12.77 | 71.06 | 0.2312 | -813.8 | -873.5 | |
| 4.55 | -23.00 | 2.31 | -23.00 | 9.17 | 50.87 | -12.83 | 74.79 | 0.2283 | 1099.6 | 999999 | |
| 11.71 | -23.00 | 5.96 | -23.00 | 9.50 | 50.73 | -12.97 | 73.56 | 0.2319 | -875.7 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.50 | 16.72 | 49.85 | -13.85 | 50.26 | 0.2994 | 891.0 | 669.9 | |
| 0.00 | 3.06 | 0.00 | 1.57 | 12.54 | 50.03 | -13.68 | 62.81 | 0.2606 | -970.0 | -747.7 | |
| 2.45 | 2.97 | 1.25 | 1.52 | 11.46 | 49.89 | -13.81 | 66.90 | 0.2555 | 1054.2 | 775.5 | |
| 0.00 | 1.14 | 0.00 | 0.58 | 12.45 | 49.84 | -13.86 | 63.43 | 0.2627 | -885.0 | -635.2 | |
| 0.00 | 5.42 | 0.00 | 2.77 | 9.32 | 49.74 | -13.96 | 75.24 | 0.2473 | 621.0 | 456.0 | |
| 0.00 | 1.49 | 0.00 | 0.78 | 19.11 | 49.04 | -14.66 | 45.90 | 0.3345 | 914.0 | 686.6 | |
| 0.00 | 1.66 | 0.00 | 0.85 | 10.01 | 49.49 | -14.21 | 72.82 | 0.2542 | 872.0 | 687.0 | |
| 0.00 | 1.31 | 0.00 | 0.67 | 9.47 | 49.42 | -14.28 | 74.97 | 0.2531 | -946.0 | -780.4 | |
| 0.00 | 0.96 | 0.00 | 0.51 | 20.34 | 48.66 | -15.04 | 43.92 | 0.3523 | 861.0 | 720.7 | |
| 2.62 | 35.84 | 1.34 | 18.39 | 10.21 | 49.33 | -14.38 | 72.21 | 0.2578 | 848.6 | 140.2 | |
| 0.00 | 1.40 | 0.00 | 0.73 | 15.63 | 48.97 | -14.73 | 54.87 | 0.3008 | 829.0 | 691.6 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 19.66 | 48.53 | -15.17 | 45.62 | 0.3464 | 1031.0 | 863.2 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 18.52 | 48.60 | -15.10 | 48.07 | 0.3335 | 872.0 | 575.8 | |
| 0.00 | 1.31 | 0.00 | 0.67 | 9.58 | 49.07 | -14.63 | 74.85 | 0.2592 | -881.0 | -670.9 | |
| 7.26 | -38.00 | 3.73 | -38.00 | 10.56 | 48.90 | -14.80 | 71.37 | 0.2662 | -1133.9 | 999999 | |
| 0.00 | 3.41 | 0.00 | 1.75 | 8.17 | 48.98 | -14.73 | 80.32 | 0.2564 | -1190.0 | -827.1 | |
| 0.00 | 1.05 | 0.00 | 0.56 | 20.23 | 48.08 | -15.63 | 45.19 | 0.3578 | 909.0 | 732.2 | |
| 0.00 | 2.19 | 0.00 | 1.12 | 10.17 | 48.67 | -15.03 | 73.04 | 0.2681 | -741.0 | -583.0 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 7.80 | 48.77 | -14.93 | 81.83 | 0.2591 | -887.0 | -688.4 | |
| 0.00 | 1.31 | 0.00 | 0.67 | 7.74 | 48.62 | -15.09 | 82.14 | 0.2615 | -708.0 | -582.9 | |
| 0.00 | 1.92 | 0.00 | 1.00 | 15.15 | 48.17 | -15.53 | 57.53 | 0.3077 | 869.0 | 679.5 | |
| 0.00 | 0.96 | 0.00 | 0.50 | 10.54 | 47.96 | -15.75 | 72.40 | 0.2811 | 926.0 | 670.2 | |
| 0.00 | 1.57 | 0.00 | 0.81 | 9.45 | 47.85 | -15.85 | 76.26 | 0.2786 | 808.0 | 493.0 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 8.43 | 47.59 | -16.12 | 80.06 | 0.2800 | 1021.0 | 929.5 | |
| 3.93 | 9.88 | 2.03 | 5.10 | 9.59 | 47.34 | -16.36 | 76.15 | 0.2873 | 1142.5 | 942.8 | |
| 0.00 | 2.62 | 0.00 | 1.35 | 9.05 | 47.37 | -16.33 | 77.99 | 0.2852 | 843.0 | 582.7 | |
| 0.00 | 1.49 | 0.00 | 0.77 | 10.46 | 47.20 | -16.50 | 73.34 | 0.2929 | 896.0 | 778.4 | |
| 0.00 | 1.31 | 0.00 | 0.68 | 10.63 | 47.10 | -16.61 | 72.84 | 0.2953 | 927.0 | 735.4 | |
| 0.00 | 1.31 | 0.00 | 0.68 | 10.86 | 46.83 | -16.87 | 72.31 | 0.3005 | 1186.0 | 922.4 | |
| 7.52 | 13.11 | 3.90 | 6.80 | 9.69 | 46.83 | -16.87 | 76.14 | 0.2960 | 1089.5 | 889.3 | |
| 0.00 | 0.96 | 0.00 | 0.50 | 11.43 | 46.67 | -17.03 | 70.65 | 0.3057 | 736.0 | 493.4 | |
| 0.00 | 3.32 | 0.00 | 1.73 | 12.32 | 46.29 | -17.41 | 68.28 | 0.3161 | 231.0 | 223.1 | |
| 0.00 | 1.14 | 0.00 | 0.59 | 11.21 | 46.36 | -17.34 | 71.61 | 0.3095 | 1103.0 | 921.2 | |
| 3.58 | 42.57 | 1.87 | 22.23 | 11.99 | 46.18 | -17.52 | 69.39 | 0.3160 | 1175.6 | 802.4 | |
| 0.00 | 1.31 | 0.00 | 0.68 | 11.18 | 46.17 | -17.53 | 71.89 | 0.3123 | 901.0 | 653.9 | |
| 0.00 | 2.45 | 0.00 | 1.28 | 11.26 | 46.01 | -17.69 | 71.76 | 0.3153 | 855.0 | 659.5 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 7.94 | 46.15 | -17.55 | 82.31 | 0.3027 | 828.0 | 591.6 | |
| 8.74 | -62.00 | 4.57 | -62.00 | 12.04 | 45.83 | -17.87 | 69.58 | 0.3217 | 1106.8 | 999999 | |
| 2.62 | -62.00 | 1.37 | -62.00 | 11.62 | 45.82 | -17.88 | 70.84 | 0.3198 | 911.6 | 999999 | |
| 0.00 | 1.31 | 0.00 | 0.68 | 8.91 | 45.79 | -17.91 | 79.28 | 0.3106 | 878.0 | 642.5 | |
| 0.44 | 1.14 | 0.23 | 0.60 | 11.91 | 45.48 | -18.22 | 70.27 | 0.3264 | 764.8 | 656.9 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 10.77 | 45.56 | -18.14 | 73.63 | 0.3203 | 969.0 | 714.8 | |
| 0.00 | 2.53 | 0.00 | 1.32 | 8.61 | 45.62 | -18.09 | 80.33 | 0.3128 | 785.0 | 598.9 | |
| 0.00 | 0.87 | 0.00 | 0.47 | 19.90 | 44.31 | -19.39 | 51.60 | 0.4001 | 853.0 | 665.4 | |
| 0.00 | 1.40 | 0.00 | 0.73 | 10.93 | 45.10 | -18.60 | 73.46 | 0.3282 | 1011.0 | 764.1 | |
| 0.00 | 1.49 | 0.00 | 0.80 | 19.72 | 44.26 | -19.44 | 52.05 | 0.3990 | 912.0 | 707.7 | |
| 0.00 | 1.49 | 0.00 | 0.78 | 9.13 | 44.98 | -18.72 | 78.98 | 0.3243 | 872.0 | 628.0 | |
| 1.40 | 2.36 | 0.73 | 1.24 | 11.04 | 44.80 | -18.90 | 73.35 | 0.3333 | 1050.5 | 735.7 | |
| 14.42 | 33.83 | 7.59 | 17.83 | 11.00 | 44.35 | -19.35 | 73.79 | 0.3402 | 1172.6 | 357.1 | |
| 2.19 | 6.47 | 1.15 | 3.41 | 11.44 | 44.23 | -19.48 | 72.60 | 0.3440 | 948.8 | 555.2 | |
| 1.14 | -78.00 | 0.60 | -78.00 | 11.47 | 44.03 | -19.67 | 72.68 | 0.3471 | 637.9 | 999999 | |
| 0.00 | 1.40 | 0.00 | 0.74 | 13.22 | 43.17 | -20.53 | 68.61 | 0.3683 | 815.0 | 639.1 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 9.22 | 43.37 | -20.33 | 79.38 | 0.3505 | 396.0 | 476.6 | |
| 0.00 | 0.96 | 0.00 | 0.51 | 13.86 | 42.52 | -21.18 | 67.52 | 0.3813 | 694.0 | 501.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
