SDO HMI 2011-10-15 06:59:47 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 15.56 | 85.75 | 15.88 | 86.35 | -14.72 | 119.55 | 57.50 | 249.43 | 0.8730 | 318.8 | 220.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 06:59:47 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.01 | 76.14 | 2.05 | 77.57 | -14.00 | 120.16 | 58.11 | 250.41 | 0.8764 | 485.2 | 313.1 | |
| 0.61 | -1.00 | 0.62 | -1.00 | -14.28 | 120.10 | 58.04 | 250.09 | 0.8765 | 633.7 | 999999 | |
| 12.94 | -1.00 | 13.21 | -1.00 | -14.71 | 119.98 | 57.93 | 249.58 | 0.8766 | 671.1 | 999999 | |
| 0.00 | 3.76 | 0.00 | 3.50 | -15.65 | 116.23 | 54.18 | 247.34 | 0.8482 | -478.0 | -404.5 | |
| 0.00 | 0.87 | 0.00 | 0.81 | -15.90 | 116.22 | 54.17 | 247.05 | 0.8489 | -487.0 | -377.8 | |
| 0.00 | 0.96 | 0.00 | 0.90 | -16.10 | 116.30 | 54.25 | 246.85 | 0.8501 | -432.0 | -337.1 | |
| 0.00 | 1.75 | 0.00 | 1.60 | -16.95 | 115.06 | 53.01 | 245.45 | 0.8421 | -504.0 | -424.7 | |
| 0.00 | 0.52 | 0.00 | 0.47 | -16.38 | 114.78 | 52.73 | 245.99 | 0.8379 | -676.0 | -571.5 | |
| 0.00 | 1.75 | 0.00 | 1.50 | -14.17 | 113.44 | 51.39 | 248.03 | 0.8191 | -700.0 | -541.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
