SDO HMI 2011-10-15 07:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 116.95 | 761.19 | 62.38 | 406.24 | 26.99 | 56.81 | -4.71 | 11.43 | 0.3722 | -718.7 | -395.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 07:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 6.73 | 0.00 | 3.60 | 27.79 | 59.51 | -2.01 | 4.74 | 0.3762 | 273.0 | 68.7 | |
| 0.00 | 0.96 | 0.00 | 0.52 | 29.08 | 58.90 | -2.61 | 5.77 | 0.3979 | 932.0 | 800.5 | |
| 0.00 | 2.27 | 0.00 | 1.23 | 29.24 | 58.79 | -2.72 | 5.96 | 0.4006 | 898.0 | 757.8 | |
| 0.00 | 2.62 | 0.00 | 1.35 | 21.12 | 58.97 | -2.54 | 8.94 | 0.2676 | -948.0 | -757.3 | |
| 0.00 | 0.96 | 0.00 | 0.49 | 20.26 | 58.86 | -2.66 | 9.92 | 0.2534 | -683.0 | -560.0 | |
| 0.00 | 2.62 | 0.00 | 1.41 | 29.08 | 58.56 | -2.96 | 6.52 | 0.3984 | 1036.0 | 840.8 | |
| 0.00 | 1.92 | 0.00 | 1.04 | 29.27 | 58.48 | -3.03 | 6.62 | 0.4017 | 690.0 | 383.9 | |
| 0.00 | 2.62 | 0.00 | 1.34 | 19.94 | 57.88 | -3.64 | 13.78 | 0.2516 | -1045.0 | -896.9 | |
| 113.10 | 662.45 | 60.29 | 353.20 | 27.23 | 57.57 | -3.95 | 9.54 | 0.3711 | -1505.4 | -462.9 | |
| 0.00 | 1.75 | 0.00 | 0.90 | 20.25 | 57.61 | -3.90 | 14.40 | 0.2577 | -774.0 | -651.0 | |
| 0.00 | 0.87 | 0.00 | 0.45 | 19.85 | 57.59 | -3.92 | 14.91 | 0.2513 | -867.0 | -686.0 | |
| 0.00 | 1.40 | 0.00 | 0.74 | 25.19 | 57.24 | -4.28 | 11.52 | 0.3393 | 747.0 | 668.3 | |
| 0.00 | 1.66 | 0.00 | 0.85 | 19.48 | 57.35 | -4.17 | 16.22 | 0.2464 | -997.0 | -867.9 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 19.69 | 57.21 | -4.30 | 16.45 | 0.2505 | -910.0 | -653.2 | |
| 0.35 | -9.00 | 0.19 | -9.00 | 26.71 | 56.81 | -4.70 | 11.62 | 0.3651 | -888.0 | 999999 | |
| 0.00 | 1.66 | 0.00 | 0.91 | 30.79 | 54.87 | -6.64 | 13.25 | 0.4352 | -914.0 | -744.3 | |
| 0.00 | 0.96 | 0.00 | 0.52 | 28.08 | 54.91 | -6.60 | 15.00 | 0.3935 | -887.0 | -758.1 | |
| 2.19 | 2.62 | 1.18 | 1.41 | 27.98 | 54.72 | -6.80 | 15.50 | 0.3928 | -973.6 | -849.8 | |
| 0.00 | 2.62 | 0.00 | 1.44 | 30.85 | 54.41 | -7.10 | 14.09 | 0.4378 | -581.0 | -551.2 | |
| 0.00 | 1.31 | 0.00 | 0.68 | 20.47 | 54.88 | -6.63 | 23.17 | 0.2761 | -729.0 | -687.3 | |
| 0.00 | 1.92 | 0.00 | 0.99 | 20.23 | 54.89 | -6.62 | 23.52 | 0.2723 | -869.0 | -688.9 | |
| 0.00 | 3.23 | 0.00 | 1.78 | 30.65 | 54.11 | -7.40 | 14.79 | 0.4360 | -494.0 | -531.6 | |
| 0.00 | 1.14 | 0.00 | 0.61 | 27.62 | 54.30 | -7.22 | 16.69 | 0.3892 | -727.0 | -600.8 | |
| 0.00 | 0.61 | 0.00 | 0.33 | 27.74 | 54.15 | -7.36 | 16.90 | 0.3918 | -809.0 | -669.7 | |
| 0.00 | 2.45 | 0.00 | 1.31 | 27.16 | 53.95 | -7.56 | 17.83 | 0.3839 | -1132.0 | -795.9 | |
| 0.00 | 0.79 | 0.00 | 0.42 | 28.06 | 53.55 | -7.96 | 17.90 | 0.3995 | -854.0 | -733.6 | |
| 0.00 | 5.51 | 0.00 | 2.97 | 27.83 | 53.33 | -8.19 | 18.57 | 0.3971 | -953.0 | -773.5 | |
| 0.00 | 1.84 | 0.00 | 1.00 | 28.54 | 53.13 | -8.38 | 18.33 | 0.4087 | -837.0 | -634.6 | |
| 0.00 | 1.57 | 0.00 | 0.85 | 28.28 | 53.05 | -8.46 | 18.73 | 0.4053 | -906.0 | -764.2 | |
| 0.00 | 1.40 | 0.00 | 0.76 | 29.61 | 52.87 | -8.64 | 17.94 | 0.4260 | -688.0 | -500.0 | |
| 0.00 | 2.27 | 0.00 | 1.17 | 18.47 | 52.26 | -9.25 | 34.82 | 0.2683 | -989.0 | -627.7 | |
| 0.00 | 1.22 | 0.00 | 0.66 | 26.35 | 51.31 | -10.21 | 24.32 | 0.3872 | -653.0 | -526.3 | |
| 0.00 | 0.87 | 0.00 | 0.45 | 18.98 | 51.59 | -9.92 | 35.53 | 0.2816 | -741.0 | -590.4 | |
| 0.00 | 1.05 | 0.00 | 0.57 | 26.80 | 50.96 | -10.55 | 24.51 | 0.3959 | -786.0 | -626.0 | |
| 0.00 | 1.22 | 0.00 | 0.64 | 19.70 | 48.89 | -12.62 | 40.46 | 0.3185 | 792.0 | 623.5 | |
| 0.00 | 1.31 | 0.00 | 0.69 | 20.31 | 48.71 | -12.80 | 39.55 | 0.3278 | 940.0 | 756.2 | |
| 0.00 | 1.66 | 0.00 | 0.92 | 28.96 | 47.56 | -13.95 | 28.13 | 0.4494 | 499.0 | 414.0 | |
| 0.00 | 1.22 | 0.00 | 0.64 | 19.69 | 48.53 | -12.98 | 41.24 | 0.3222 | 980.0 | 772.1 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 20.14 | 48.04 | -13.48 | 41.30 | 0.3330 | 922.0 | 792.8 | |
| 0.00 | 0.70 | 0.00 | 0.37 | 20.60 | 47.73 | -13.78 | 40.95 | 0.3417 | 904.0 | 743.9 | |
| 0.00 | 2.19 | 0.00 | 1.15 | 20.43 | 47.42 | -14.09 | 41.90 | 0.3432 | 866.0 | 717.6 | |
| 0.00 | 1.57 | 0.00 | 0.83 | 19.79 | 47.45 | -14.07 | 43.22 | 0.3354 | 973.0 | 727.3 | |
| 0.00 | 1.75 | 0.00 | 0.95 | 26.22 | 46.36 | -15.15 | 33.75 | 0.4238 | 707.0 | 504.5 | |
| 0.00 | 1.05 | 0.00 | 0.56 | 22.59 | 46.70 | -14.81 | 39.06 | 0.3762 | 784.0 | 633.1 | |
| 0.00 | 5.24 | 0.00 | 2.88 | 26.85 | 45.96 | -15.55 | 33.50 | 0.4351 | 688.0 | 655.5 | |
| 0.00 | 1.05 | 0.00 | 0.58 | 27.07 | 45.79 | -15.72 | 33.47 | 0.4393 | 784.0 | 552.1 | |
| 1.31 | 1.84 | 0.72 | 1.01 | 27.26 | 45.70 | -15.82 | 33.36 | 0.4425 | 808.5 | 757.2 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 26.43 | 45.75 | -15.77 | 34.47 | 0.4318 | 885.0 | 712.9 | |
| 0.00 | 0.61 | 0.00 | 0.34 | 25.75 | 44.21 | -17.30 | 37.90 | 0.4379 | 975.0 | 757.7 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 26.03 | 44.17 | -17.34 | 37.53 | 0.4416 | 766.0 | 665.0 | |
| 0.00 | 1.05 | 0.00 | 0.58 | 25.84 | 44.06 | -17.45 | 37.99 | 0.4404 | 861.0 | 750.2 | |
| 0.00 | 0.26 | 0.00 | 0.14 | 26.12 | 43.95 | -17.57 | 37.72 | 0.4448 | 732.0 | 696.7 | |
| 0.00 | 1.05 | 0.00 | 0.58 | 26.02 | 43.72 | -17.80 | 38.22 | 0.4458 | 689.0 | 564.3 | |
| 0.00 | 0.87 | 0.00 | 0.47 | 19.98 | 44.29 | -17.22 | 48.29 | 0.3744 | 847.0 | 674.2 | |
| 0.00 | 1.31 | 0.00 | 0.70 | 19.79 | 44.24 | -17.27 | 48.76 | 0.3731 | 768.0 | 645.0 | |
| 0.00 | 1.14 | 0.00 | 0.61 | 20.16 | 44.17 | -17.34 | 48.09 | 0.3777 | 646.0 | 526.4 | |
| 0.00 | 1.05 | 0.00 | 0.61 | 29.81 | 40.90 | -20.62 | 36.59 | 0.5146 | 635.0 | 483.4 | |
| 0.00 | 1.49 | 0.00 | 0.81 | 22.87 | 42.12 | -19.39 | 45.79 | 0.4287 | 834.0 | 581.2 | |
| 0.00 | 0.87 | 0.00 | 0.48 | 23.24 | 41.89 | -19.62 | 45.44 | 0.4349 | 779.0 | 610.1 | |
| 0.00 | 0.70 | 0.00 | 0.40 | 28.04 | 40.58 | -20.94 | 39.45 | 0.4984 | 649.0 | 528.5 | |
| 0.00 | 1.05 | 0.00 | 0.60 | 26.22 | 39.28 | -22.23 | 43.75 | 0.4928 | 763.0 | 429.7 | |
| 0.00 | 1.22 | 0.00 | 0.70 | 26.61 | 38.44 | -23.07 | 44.12 | 0.5054 | 681.0 | 580.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
