SDO HMI 2011-10-15 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 147.14 | 507.50 | 74.16 | 256.05 | 10.32 | 49.95 | -9.37 | 62.35 | 0.1809 | -6.5 | 34.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.87 | 72.51 | 0.43 | 36.05 | 9.20 | 55.49 | -3.83 | 48.41 | 0.0885 | -728.9 | -597.3 | |
| 16.25 | -1.00 | 8.08 | -1.00 | 8.72 | 55.38 | -3.95 | 53.59 | 0.0849 | -1227.5 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.56 | 8.27 | 55.20 | -4.12 | 59.24 | 0.0832 | -162.0 | -213.6 | |
| 0.00 | 0.87 | 0.00 | 0.43 | 7.96 | 54.08 | -5.24 | 67.68 | 0.0982 | -730.0 | -584.0 | |
| 1.92 | 3.06 | 0.96 | 1.52 | 9.27 | 53.94 | -5.38 | 57.00 | 0.1108 | -1093.7 | -998.2 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 8.73 | 53.68 | -5.64 | 62.46 | 0.1101 | -903.0 | -755.1 | |
| 0.00 | 2.45 | 0.00 | 1.22 | 9.15 | 53.61 | -5.71 | 59.45 | 0.1146 | -1044.0 | -874.9 | |
| 10.92 | 37.39 | 5.45 | 18.66 | 9.48 | 53.45 | -5.87 | 57.72 | 0.1199 | -1092.6 | -849.1 | |
| 0.00 | 0.96 | 0.00 | 0.48 | 8.91 | 53.40 | -5.92 | 62.16 | 0.1158 | -870.0 | -698.2 | |
| 6.12 | -8.00 | 3.05 | -8.00 | 9.78 | 53.30 | -6.03 | 56.33 | 0.1249 | -1058.8 | 999999 | |
| 6.90 | 10.57 | 3.45 | 5.28 | 9.95 | 52.81 | -6.52 | 57.20 | 0.1336 | -1069.5 | -800.6 | |
| 0.00 | 1.75 | 0.00 | 0.87 | 9.74 | 52.60 | -6.73 | 59.35 | 0.1348 | -868.0 | -724.6 | |
| 4.54 | 6.20 | 2.27 | 3.11 | 10.45 | 52.27 | -7.05 | 56.15 | 0.1460 | -973.2 | -774.7 | |
| 1.57 | 12.40 | 0.79 | 6.21 | 9.98 | 52.29 | -7.04 | 58.97 | 0.1415 | -862.8 | -711.4 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 9.62 | 52.26 | -7.06 | 61.31 | 0.1388 | -849.0 | -511.7 | |
| 0.00 | 1.14 | 0.00 | 0.58 | 18.90 | 51.93 | -7.39 | 28.26 | 0.2583 | -788.0 | -654.1 | |
| 0.79 | -14.00 | 0.39 | -14.00 | 10.09 | 52.10 | -7.22 | 58.90 | 0.1452 | -770.9 | 999999 | |
| 0.00 | 1.83 | 0.00 | 0.92 | 10.39 | 51.79 | -7.54 | 58.23 | 0.1525 | -131.0 | -216.3 | |
| 1.40 | 4.37 | 0.70 | 2.19 | 9.88 | 51.74 | -7.59 | 61.36 | 0.1489 | -795.2 | -650.2 | |
| 0.00 | 1.05 | 0.00 | 0.53 | 10.54 | 51.66 | -7.66 | 57.82 | 0.1556 | -666.0 | -378.8 | |
| 2.45 | 62.99 | 1.22 | 31.58 | 9.46 | 51.66 | -7.67 | 64.17 | 0.1469 | -977.7 | -15.7 | |
| 0.00 | 1.57 | 0.00 | 0.79 | 12.01 | 51.59 | -7.73 | 50.62 | 0.1711 | -947.0 | -688.8 | |
| 0.00 | 1.57 | 0.00 | 0.81 | 18.80 | 51.30 | -8.03 | 30.44 | 0.2620 | -788.0 | -578.8 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 10.71 | 51.50 | -7.82 | 57.37 | 0.1595 | -746.0 | -580.4 | |
| 0.00 | 2.80 | 0.00 | 1.41 | 12.03 | 51.37 | -7.95 | 51.25 | 0.1743 | -757.0 | -645.7 | |
| 11.97 | -21.00 | 6.00 | -21.00 | 9.48 | 51.23 | -8.10 | 65.18 | 0.1538 | -931.0 | 999999 | |
| 0.00 | 1.83 | 0.00 | 0.92 | 10.59 | 51.20 | -8.13 | 58.98 | 0.1629 | -725.0 | -663.1 | |
| 2.01 | -21.00 | 1.01 | -21.00 | 9.18 | 50.99 | -8.33 | 67.58 | 0.1555 | 667.2 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.75 | 10.20 | 50.96 | -8.36 | 61.79 | 0.1631 | -817.0 | -572.7 | |
| 0.00 | 2.53 | 0.00 | 1.27 | 10.61 | 50.68 | -8.65 | 60.37 | 0.1708 | -888.0 | -681.9 | |
| 0.00 | 1.40 | 0.00 | 0.71 | 15.95 | 50.42 | -8.91 | 40.16 | 0.2318 | 946.0 | 654.4 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 12.59 | 50.30 | -9.02 | 52.25 | 0.1944 | -686.0 | -599.2 | |
| 1.31 | 7.43 | 0.66 | 3.75 | 11.86 | 50.11 | -9.21 | 55.93 | 0.1900 | 976.2 | 787.0 | |
| 0.00 | 2.71 | 0.00 | 1.36 | 8.57 | 50.15 | -9.18 | 72.87 | 0.1658 | -988.0 | -775.1 | |
| 1.40 | 5.50 | 0.70 | 2.77 | 11.26 | 49.95 | -9.38 | 59.13 | 0.1870 | 555.5 | 348.1 | |
| 4.46 | 6.03 | 2.25 | 3.04 | 11.83 | 49.71 | -9.61 | 57.17 | 0.1954 | 891.9 | 836.0 | |
| 16.60 | 57.57 | 8.36 | 29.03 | 10.36 | 49.64 | -9.69 | 64.24 | 0.1846 | 1105.7 | 310.0 | |
| 0.00 | 2.88 | 0.00 | 1.45 | 9.55 | 49.66 | -9.66 | 68.32 | 0.1789 | -823.0 | -695.2 | |
| 2.80 | -37.00 | 1.41 | -37.00 | 10.35 | 49.33 | -10.00 | 64.93 | 0.1894 | 836.8 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.62 | 11.88 | 49.24 | -10.08 | 58.13 | 0.2026 | 882.0 | 724.1 | |
| 0.00 | 2.36 | 0.00 | 1.23 | 20.23 | 48.81 | -10.52 | 34.42 | 0.3043 | 736.0 | 681.4 | |
| 0.00 | 1.31 | 0.00 | 0.67 | 15.62 | 49.02 | -10.31 | 45.19 | 0.2440 | 810.0 | 654.6 | |
| 0.00 | 1.14 | 0.00 | 0.59 | 19.74 | 48.52 | -10.81 | 36.15 | 0.3005 | 819.0 | 647.0 | |
| 8.04 | -37.00 | 4.06 | -37.00 | 10.67 | 48.95 | -10.38 | 64.18 | 0.1975 | -917.5 | 999999 | |
| 0.00 | 3.06 | 0.00 | 1.54 | 10.28 | 48.87 | -10.46 | 66.18 | 0.1961 | -969.0 | -617.1 | |
| 0.00 | 1.40 | 0.00 | 0.70 | 7.44 | 48.86 | -10.47 | 80.76 | 0.1833 | -929.0 | -753.2 | |
| 0.00 | 0.87 | 0.00 | 0.44 | 10.43 | 48.65 | -10.68 | 65.91 | 0.2005 | -699.0 | -562.1 | |
| 0.00 | 1.66 | 0.00 | 0.84 | 7.26 | 48.62 | -10.71 | 81.92 | 0.1870 | -835.0 | -645.4 | |
| 2.27 | 4.54 | 1.15 | 2.29 | 8.78 | 48.51 | -10.81 | 74.11 | 0.1936 | -828.2 | -711.3 | |
| 0.00 | 1.14 | 0.00 | 0.60 | 21.51 | 47.44 | -11.89 | 35.18 | 0.3341 | 942.0 | 740.9 | |
| 0.00 | 1.22 | 0.00 | 0.64 | 21.29 | 47.29 | -12.03 | 35.91 | 0.3326 | 751.0 | 571.6 | |
| 0.00 | 3.93 | 0.00 | 1.99 | 8.37 | 47.76 | -11.57 | 76.95 | 0.2046 | 527.0 | 623.0 | |
| 0.00 | 1.31 | 0.00 | 0.66 | 8.76 | 47.62 | -11.70 | 75.25 | 0.2082 | 859.0 | 675.7 | |
| 2.62 | 6.99 | 1.33 | 3.55 | 10.47 | 47.47 | -11.86 | 67.79 | 0.2192 | 999.9 | 784.2 | |
| 4.02 | 23.94 | 2.04 | 12.14 | 9.68 | 47.25 | -12.07 | 71.51 | 0.2184 | 993.7 | 736.7 | |
| 2.62 | 6.29 | 1.33 | 3.20 | 10.91 | 47.05 | -12.28 | 66.61 | 0.2286 | 1001.0 | 725.8 | |
| 0.00 | 5.42 | 0.00 | 2.75 | 9.32 | 47.01 | -12.31 | 73.41 | 0.2205 | 895.0 | 804.7 | |
| 4.19 | 6.90 | 2.13 | 3.51 | 9.73 | 46.78 | -12.54 | 71.89 | 0.2262 | 947.9 | 725.5 | |
| 0.00 | 1.22 | 0.00 | 0.62 | 10.90 | 46.73 | -12.59 | 67.12 | 0.2334 | 950.0 | 657.6 | |
| 0.00 | 1.49 | 0.00 | 0.76 | 11.17 | 46.69 | -12.63 | 66.11 | 0.2357 | 1067.0 | 836.9 | |
| 0.00 | 1.40 | 0.00 | 0.71 | 11.95 | 46.53 | -12.79 | 63.38 | 0.2434 | 392.0 | 333.9 | |
| 0.00 | 5.77 | 0.00 | 2.94 | 11.65 | 46.48 | -12.84 | 64.60 | 0.2421 | 473.0 | 605.5 | |
| 0.00 | 1.22 | 0.00 | 0.62 | 11.13 | 46.47 | -12.85 | 66.58 | 0.2389 | 1018.0 | 874.5 | |
| 0.00 | 1.40 | 0.00 | 0.71 | 11.37 | 46.34 | -12.99 | 65.87 | 0.2425 | 1133.0 | 937.4 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 11.37 | 46.21 | -13.11 | 66.07 | 0.2444 | 936.0 | 729.9 | |
| 0.00 | 1.05 | 0.00 | 0.54 | 11.13 | 46.16 | -13.16 | 67.07 | 0.2437 | 943.0 | 816.7 | |
| 7.95 | 40.01 | 4.07 | 20.47 | 11.94 | 46.06 | -13.26 | 64.19 | 0.2505 | 1113.0 | 622.1 | |
| 0.00 | 1.66 | 0.00 | 0.85 | 11.39 | 45.96 | -13.36 | 66.36 | 0.2484 | 1021.0 | 829.4 | |
| 0.00 | 1.05 | 0.00 | 0.53 | 8.85 | 46.01 | -13.32 | 76.45 | 0.2352 | 829.0 | 681.0 | |
| 1.49 | -67.00 | 0.76 | -67.00 | 11.72 | 45.85 | -13.47 | 65.30 | 0.2522 | 991.6 | 999999 | |
| 1.14 | -67.00 | 0.58 | -67.00 | 12.05 | 45.80 | -13.52 | 64.17 | 0.2552 | 1159.5 | 999999 | |
| 3.84 | -67.00 | 1.97 | -67.00 | 12.29 | 45.76 | -13.56 | 63.38 | 0.2575 | 876.7 | 999999 | |
| 0.00 | 1.83 | 0.00 | 0.94 | 8.60 | 45.74 | -13.59 | 77.69 | 0.2388 | 803.0 | 573.9 | |
| 0.00 | 2.71 | 0.00 | 1.39 | 12.01 | 45.46 | -13.86 | 64.83 | 0.2601 | 640.0 | 555.9 | |
| 0.00 | 3.93 | 0.00 | 2.01 | 8.68 | 45.36 | -13.96 | 77.64 | 0.2453 | 674.0 | 640.6 | |
| 0.00 | 0.79 | 0.00 | 0.41 | 19.40 | 44.57 | -14.75 | 45.33 | 0.3392 | 770.0 | 608.4 | |
| 0.00 | 1.57 | 0.00 | 0.81 | 11.13 | 44.84 | -14.48 | 68.83 | 0.2643 | 799.0 | 752.5 | |
| 0.00 | 2.18 | 0.00 | 1.12 | 11.59 | 44.32 | -15.01 | 67.83 | 0.2752 | 962.0 | 706.4 | |
| 10.92 | 34.07 | 5.62 | 17.55 | 11.02 | 44.19 | -15.14 | 69.97 | 0.2740 | 1070.5 | 453.3 | |
| 3.76 | 6.12 | 1.94 | 3.15 | 11.41 | 44.14 | -15.19 | 68.68 | 0.2769 | 875.8 | 681.0 | |
| 0.00 | 1.57 | 0.00 | 0.81 | 9.41 | 43.58 | -15.75 | 76.19 | 0.2770 | 821.0 | 599.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
