SDO HMI 2011-10-15 15:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.89 | 172.87 | 16.82 | 108.32 | -26.68 | 37.29 | -19.84 | 150.35 | 0.6149 | 996.2 | 367.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 15:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.89 | 166.84 | 16.82 | 104.36 | -26.62 | 37.44 | -19.69 | 150.47 | 0.6133 | 1127.9 | 360.7 | |
| 0.00 | 0.70 | 0.00 | 0.46 | -28.04 | 34.04 | -23.09 | 147.84 | 0.6525 | 776.0 | 693.8 | |
| 0.00 | 1.05 | 0.00 | 0.68 | -27.44 | 33.95 | -23.17 | 147.19 | 0.6467 | 739.0 | 644.6 | |
| 0.00 | 0.87 | 0.00 | 0.57 | -28.02 | 33.82 | -23.30 | 147.58 | 0.6538 | 709.0 | 568.6 | |
| 0.00 | 1.40 | 0.00 | 0.92 | -27.93 | 33.25 | -23.87 | 146.89 | 0.6570 | 549.0 | 436.2 | |
| 0.00 | 1.05 | 0.00 | 0.68 | -27.76 | 33.25 | -23.87 | 146.73 | 0.6551 | 452.0 | 408.8 | |
| 0.00 | 0.96 | 0.00 | 0.65 | -29.75 | 32.34 | -24.78 | 147.63 | 0.6820 | 538.0 | 421.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
