SDO HMI 2011-10-15 15:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 156.35 | 536.39 | 78.28 | 269.17 | 10.33 | 50.05 | -7.08 | 53.33 | 0.1479 | -101.6 | 41.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 15:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 7.25 | 65.74 | 3.60 | 32.62 | 8.84 | 55.58 | -1.55 | 27.07 | 0.0589 | -1286.3 | -570.0 | |
| 0.00 | 1.05 | 0.00 | 0.52 | 8.16 | 55.55 | -1.57 | 34.07 | 0.0488 | -593.0 | -408.7 | |
| 9.78 | -1.00 | 4.85 | -1.00 | 8.54 | 55.34 | -1.79 | 33.28 | 0.0565 | -1235.5 | 999999 | |
| 3.14 | -1.00 | 1.56 | -1.00 | 9.08 | 55.30 | -1.82 | 29.09 | 0.0648 | -1011.3 | 999999 | |
| 0.00 | 2.62 | 0.00 | 1.30 | 8.75 | 54.82 | -2.30 | 38.10 | 0.0647 | -835.0 | -606.6 | |
| 0.00 | 1.92 | 0.00 | 0.95 | 8.72 | 54.61 | -2.51 | 40.86 | 0.0666 | -608.0 | -392.1 | |
| 1.40 | 2.53 | 0.69 | 1.26 | 9.20 | 54.18 | -2.94 | 40.91 | 0.0777 | -1160.7 | -1053.4 | |
| 0.00 | 2.53 | 0.00 | 1.26 | 9.05 | 53.91 | -3.21 | 44.74 | 0.0790 | -930.0 | -762.7 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 8.72 | 53.88 | -3.24 | 48.10 | 0.0754 | -992.0 | -824.4 | |
| 8.56 | 85.65 | 4.25 | 42.64 | 9.40 | 53.76 | -3.37 | 43.02 | 0.0854 | -1179.9 | -796.5 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 10.30 | 53.50 | -3.62 | 38.63 | 0.1000 | -797.0 | -614.7 | |
| 9.78 | -10.00 | 4.86 | -10.00 | 9.58 | 53.45 | -3.67 | 44.07 | 0.0912 | -1142.2 | 999999 | |
| 0.00 | 1.57 | 0.00 | 0.78 | 9.07 | 53.34 | -3.79 | 49.17 | 0.0866 | -682.0 | -644.3 | |
| 0.00 | 0.87 | 0.00 | 0.43 | 9.01 | 53.06 | -4.06 | 51.65 | 0.0896 | -831.0 | -678.4 | |
| 7.42 | -10.00 | 3.69 | -10.00 | 9.94 | 52.99 | -4.13 | 44.79 | 0.1012 | -1186.3 | 999999 | |
| 2.88 | -10.00 | 1.44 | -10.00 | 9.97 | 52.69 | -4.44 | 46.62 | 0.1053 | -1042.4 | 999999 | |
| 5.67 | -10.00 | 2.83 | -10.00 | 10.41 | 52.62 | -4.50 | 44.05 | 0.1116 | -1034.3 | 999999 | |
| 0.00 | 1.40 | 0.00 | 0.70 | 9.64 | 52.57 | -4.55 | 49.74 | 0.1031 | -1120.0 | -908.4 | |
| 6.20 | -10.00 | 3.09 | -10.00 | 10.11 | 52.35 | -4.77 | 47.67 | 0.1113 | -1008.4 | 999999 | |
| 1.48 | -10.00 | 0.74 | -10.00 | 10.35 | 52.13 | -4.99 | 47.36 | 0.1169 | -705.9 | 999999 | |
| 0.00 | 3.75 | 0.00 | 1.87 | 9.90 | 52.02 | -5.11 | 51.01 | 0.1133 | -982.0 | -763.7 | |
| 5.76 | 45.14 | 2.87 | 22.51 | 9.48 | 51.96 | -5.16 | 54.33 | 0.1097 | -1117.9 | -79.1 | |
| 0.61 | 5.06 | 0.31 | 2.53 | 10.50 | 51.73 | -5.39 | 48.61 | 0.1237 | -837.9 | -765.1 | |
| 0.00 | 2.10 | 0.00 | 1.05 | 12.54 | 51.63 | -5.49 | 38.64 | 0.1503 | -845.0 | -622.0 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 10.71 | 51.61 | -5.52 | 48.00 | 0.1277 | -608.0 | -484.5 | |
| 11.70 | -22.00 | 5.83 | -22.00 | 9.51 | 51.57 | -5.56 | 56.09 | 0.1156 | -1021.9 | 999999 | |
| 0.00 | 6.98 | 0.00 | 3.50 | 12.15 | 51.52 | -5.61 | 40.94 | 0.1464 | -594.0 | -588.9 | |
| 0.00 | 1.66 | 0.00 | 0.85 | 18.84 | 51.30 | -5.82 | 23.08 | 0.2460 | -797.0 | -689.3 | |
| 0.00 | 1.40 | 0.00 | 0.70 | 10.49 | 51.31 | -5.82 | 50.76 | 0.1293 | -697.0 | -569.3 | |
| 0.00 | 7.16 | 0.00 | 3.58 | 9.74 | 50.92 | -6.20 | 57.28 | 0.1271 | -865.0 | -596.3 | |
| 0.00 | 2.88 | 0.00 | 1.44 | 10.58 | 50.85 | -6.28 | 52.33 | 0.1364 | -852.0 | -688.9 | |
| 1.48 | -22.00 | 0.74 | -22.00 | 9.47 | 50.78 | -6.35 | 59.72 | 0.1269 | 628.5 | 999999 | |
| 0.00 | 1.57 | 0.00 | 0.79 | 12.29 | 50.69 | -6.44 | 44.20 | 0.1579 | 989.0 | 694.1 | |
| 0.00 | 0.87 | 0.00 | 0.44 | 16.12 | 50.45 | -6.67 | 31.97 | 0.2119 | 879.0 | 709.6 | |
| 0.00 | 0.87 | 0.00 | 0.44 | 12.74 | 50.49 | -6.63 | 43.08 | 0.1658 | -806.0 | -547.2 | |
| 0.00 | 1.57 | 0.00 | 0.79 | 9.52 | 50.35 | -6.77 | 60.91 | 0.1338 | 656.0 | 466.0 | |
| 0.00 | 1.57 | 0.00 | 0.78 | 8.54 | 50.28 | -6.85 | 68.05 | 0.1277 | -913.0 | -705.5 | |
| 0.00 | 2.27 | 0.00 | 1.14 | 11.38 | 50.00 | -7.12 | 51.40 | 0.1563 | 610.0 | 323.9 | |
| 3.58 | 6.29 | 1.80 | 3.16 | 11.88 | 49.68 | -7.44 | 50.12 | 0.1660 | 1123.0 | 905.7 | |
| 0.00 | 1.40 | 0.00 | 0.70 | 8.62 | 49.73 | -7.40 | 68.91 | 0.1371 | -794.0 | -559.6 | |
| 0.00 | 1.57 | 0.00 | 0.79 | 9.51 | 49.65 | -7.48 | 63.24 | 0.1444 | -921.0 | -790.4 | |
| 21.83 | 75.43 | 10.94 | 37.83 | 10.35 | 49.54 | -7.59 | 58.59 | 0.1529 | 1182.0 | 166.4 | |
| 2.27 | 2.44 | 1.14 | 1.23 | 11.34 | 49.33 | -7.80 | 54.04 | 0.1651 | -807.5 | -464.0 | |
| 1.13 | 5.50 | 0.57 | 2.77 | 12.00 | 49.22 | -7.91 | 51.26 | 0.1734 | 728.1 | 589.9 | |
| 0.00 | 2.62 | 0.00 | 1.35 | 20.35 | 48.77 | -8.35 | 28.44 | 0.2872 | 770.0 | 656.7 | |
| 7.60 | -42.00 | 3.81 | -42.00 | 10.70 | 48.94 | -8.18 | 58.53 | 0.1647 | -954.2 | 999999 | |
| 1.83 | 4.02 | 0.92 | 2.02 | 12.20 | 48.87 | -8.25 | 51.49 | 0.1801 | 982.8 | 766.8 | |
| 1.22 | -42.00 | 0.61 | -42.00 | 10.37 | 48.83 | -8.29 | 60.63 | 0.1636 | -864.4 | 999999 | |
| 0.00 | 5.59 | 0.00 | 2.80 | 7.38 | 48.87 | -8.26 | 78.99 | 0.1458 | -745.0 | -846.5 | |
| 0.00 | 1.48 | 0.00 | 0.75 | 10.43 | 48.52 | -8.60 | 61.20 | 0.1687 | -753.0 | -587.2 | |
| 0.00 | 2.62 | 0.00 | 1.31 | 8.75 | 48.47 | -8.65 | 70.83 | 0.1581 | -1013.0 | -858.8 | |
| 0.00 | 2.71 | 0.00 | 1.40 | 19.29 | 47.80 | -9.32 | 33.19 | 0.2805 | 772.0 | 628.5 | |
| 0.00 | 4.45 | 0.00 | 2.24 | 8.29 | 47.75 | -9.37 | 74.77 | 0.1678 | 911.0 | 827.5 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 8.02 | 47.42 | -9.70 | 76.79 | 0.1722 | 943.0 | 734.9 | |
| 1.57 | 36.32 | 0.79 | 18.29 | 9.54 | 47.35 | -9.78 | 68.56 | 0.1807 | 1092.3 | 687.2 | |
| 3.75 | -55.00 | 1.89 | -55.00 | 9.75 | 47.25 | -9.87 | 67.67 | 0.1835 | 1040.9 | 999999 | |
| 2.18 | 9.17 | 1.10 | 4.63 | 10.79 | 47.03 | -10.09 | 63.01 | 0.1941 | 1104.3 | 1054.5 | |
| 1.05 | 4.63 | 0.53 | 2.34 | 11.03 | 47.02 | -10.10 | 61.92 | 0.1960 | 1169.3 | 811.0 | |
| 0.00 | 1.13 | 0.00 | 0.57 | 11.51 | 46.82 | -10.30 | 60.25 | 0.2028 | 735.0 | 468.5 | |
| 2.18 | 3.58 | 1.10 | 1.81 | 9.71 | 46.70 | -10.43 | 68.88 | 0.1921 | 977.2 | 848.4 | |
| 0.00 | 4.10 | 0.00 | 2.08 | 11.29 | 46.52 | -10.60 | 61.86 | 0.2056 | 710.0 | 877.7 | |
| 0.00 | 3.67 | 0.00 | 1.86 | 11.11 | 46.49 | -10.63 | 62.70 | 0.2046 | 1155.0 | 889.1 | |
| 0.00 | 11.09 | 0.00 | 5.62 | 11.56 | 46.35 | -10.77 | 61.06 | 0.2102 | 832.0 | 816.7 | |
| 0.00 | 2.97 | 0.00 | 1.50 | 11.11 | 46.09 | -11.03 | 63.55 | 0.2107 | 837.0 | 673.1 | |
| 0.00 | 1.31 | 0.00 | 0.66 | 10.93 | 46.07 | -11.06 | 64.39 | 0.2098 | 688.0 | 487.4 | |
| 7.16 | 28.11 | 3.63 | 14.27 | 11.91 | 45.97 | -11.16 | 60.42 | 0.2187 | 1165.5 | 787.6 | |
| 0.00 | 2.71 | 0.00 | 1.37 | 11.43 | 45.92 | -11.20 | 62.49 | 0.2156 | 804.0 | 806.9 | |
| 1.31 | -66.00 | 0.66 | -66.00 | 11.70 | 45.88 | -11.24 | 61.46 | 0.2183 | 1045.1 | 999999 | |
| 0.00 | 3.32 | 0.00 | 1.69 | 12.39 | 45.82 | -11.30 | 58.82 | 0.2248 | 871.0 | 674.3 | |
| 0.00 | 1.13 | 0.00 | 0.57 | 8.77 | 45.93 | -11.20 | 74.64 | 0.2000 | 836.0 | 681.8 | |
| 0.00 | 1.31 | 0.00 | 0.66 | 11.37 | 45.68 | -11.45 | 63.24 | 0.2189 | 875.0 | 646.1 | |
| 0.00 | 1.13 | 0.00 | 0.58 | 11.96 | 45.43 | -11.69 | 61.30 | 0.2270 | 770.0 | 693.1 | |
| 0.35 | 3.32 | 0.18 | 1.68 | 8.70 | 45.50 | -11.63 | 75.45 | 0.2068 | 1004.8 | 774.0 | |
| 0.00 | 0.70 | 0.00 | 0.36 | 11.69 | 45.38 | -11.74 | 62.48 | 0.2257 | 762.0 | 659.9 | |
| 0.00 | 1.75 | 0.00 | 0.89 | 11.48 | 45.33 | -11.79 | 63.43 | 0.2250 | 936.0 | 723.3 | |
| 0.00 | 0.87 | 0.00 | 0.46 | 20.03 | 44.49 | -12.64 | 39.74 | 0.3229 | 811.0 | 648.2 | |
| 0.00 | 2.18 | 0.00 | 1.11 | 11.14 | 44.85 | -12.28 | 65.64 | 0.2301 | 906.0 | 762.2 | |
| 0.00 | 1.92 | 0.00 | 1.01 | 20.58 | 44.18 | -12.94 | 39.25 | 0.3329 | 376.0 | 380.7 | |
| 11.87 | 29.16 | 6.06 | 14.88 | 10.94 | 44.14 | -12.99 | 67.51 | 0.2399 | 1129.7 | 519.8 | |
| 2.36 | 6.11 | 1.20 | 3.12 | 11.39 | 44.12 | -13.01 | 65.80 | 0.2430 | 996.1 | 582.8 | |
| 0.00 | 1.05 | 0.00 | 0.53 | 9.35 | 43.71 | -13.42 | 74.46 | 0.2387 | 885.0 | 727.0 | |
| 0.00 | 1.83 | 0.00 | 0.93 | 9.05 | 43.69 | -13.44 | 75.71 | 0.2379 | 755.0 | 622.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
