SDO HMI 2011-10-15 19:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 112.43 | 715.82 | 59.92 | 381.40 | 27.17 | 56.62 | 1.70 | 355.88 | 0.3687 | -937.1 | -402.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-15 19:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.22 | 0.00 | 0.66 | 28.45 | 58.95 | 4.04 | 350.85 | 0.3910 | -573.0 | -421.3 | |
| 0.00 | 5.59 | 0.00 | 3.02 | 29.26 | 58.85 | 3.93 | 351.44 | 0.4037 | 872.0 | 672.0 | |
| 0.00 | 10.56 | 0.00 | 5.70 | 29.07 | 58.57 | 3.65 | 351.97 | 0.3999 | 443.0 | 381.3 | |
| 0.00 | 2.18 | 0.00 | 1.18 | 28.81 | 58.42 | 3.50 | 352.18 | 0.3955 | -266.0 | -154.7 | |
| 0.00 | 1.48 | 0.00 | 0.80 | 29.26 | 58.16 | 3.25 | 352.92 | 0.4022 | 872.0 | 743.5 | |
| 0.00 | 1.40 | 0.00 | 0.72 | 20.56 | 57.62 | 2.70 | 350.14 | 0.2590 | -860.0 | -721.8 | |
| 0.00 | 1.40 | 0.00 | 0.71 | 20.10 | 57.61 | 2.70 | 349.83 | 0.2512 | -1040.0 | -882.1 | |
| 0.00 | 3.40 | 0.00 | 1.74 | 19.88 | 57.51 | 2.60 | 350.04 | 0.2474 | -1126.0 | -914.5 | |
| 109.90 | 626.95 | 58.52 | 333.95 | 27.26 | 57.29 | 2.38 | 354.23 | 0.3686 | -1619.4 | -468.6 | |
| 0.00 | 2.36 | 0.00 | 1.21 | 20.32 | 54.65 | -0.26 | 0.99 | 0.2510 | -924.0 | -620.6 | |
| 0.87 | 4.19 | 0.47 | 2.25 | 28.27 | 54.30 | -0.62 | 1.43 | 0.3831 | -925.7 | -739.8 | |
| 0.00 | 1.57 | 0.00 | 0.84 | 28.14 | 53.72 | -1.20 | 2.78 | 0.3813 | -832.0 | -729.3 | |
| 0.00 | 6.98 | 0.00 | 3.73 | 27.88 | 53.69 | -1.23 | 2.89 | 0.3771 | -744.0 | -737.4 | |
| 0.00 | 1.05 | 0.00 | 0.55 | 26.50 | 53.57 | -1.34 | 3.41 | 0.3548 | -885.0 | -711.8 | |
| 0.00 | 1.92 | 0.00 | 1.02 | 26.82 | 53.50 | -1.42 | 3.53 | 0.3600 | -783.0 | -676.8 | |
| 0.00 | 0.70 | 0.00 | 0.38 | 29.56 | 53.26 | -1.66 | 3.58 | 0.4047 | -825.0 | -694.8 | |
| 0.00 | 1.31 | 0.00 | 0.70 | 27.72 | 53.25 | -1.66 | 3.95 | 0.3749 | -1023.0 | -842.9 | |
| 0.00 | 1.31 | 0.00 | 0.70 | 28.07 | 53.21 | -1.70 | 3.97 | 0.3807 | -759.0 | -621.9 | |
| 0.00 | 0.70 | 0.00 | 0.37 | 27.78 | 52.98 | -1.93 | 4.57 | 0.3763 | -715.0 | -611.8 | |
| 0.00 | 1.05 | 0.00 | 0.56 | 28.65 | 52.86 | -2.05 | 4.64 | 0.3905 | -956.0 | -855.2 | |
| 0.00 | 4.10 | 0.00 | 2.19 | 27.62 | 52.65 | -2.27 | 5.40 | 0.3741 | -602.0 | -620.4 | |
| 0.00 | 1.31 | 0.00 | 0.70 | 28.65 | 52.56 | -2.36 | 5.33 | 0.3909 | -787.0 | -673.4 | |
| 0.00 | 0.70 | 0.00 | 0.36 | 18.65 | 51.94 | -2.97 | 12.50 | 0.2281 | -834.0 | -614.9 | |
| 0.00 | 1.92 | 0.00 | 0.98 | 18.86 | 51.37 | -3.55 | 14.56 | 0.2339 | -781.0 | -600.5 | |
| 0.00 | 1.13 | 0.00 | 0.58 | 20.47 | 48.81 | -6.11 | 21.51 | 0.2731 | 786.0 | 550.8 | |
| 0.00 | 1.75 | 0.00 | 0.95 | 28.71 | 47.63 | -7.28 | 15.95 | 0.4064 | 801.0 | 648.5 | |
| 0.00 | 1.13 | 0.00 | 0.58 | 19.32 | 47.80 | -7.12 | 26.58 | 0.2625 | 832.0 | 609.8 | |
| 0.00 | 1.31 | 0.00 | 0.71 | 28.01 | 46.21 | -8.71 | 19.46 | 0.4028 | 640.0 | 474.9 | |
| 0.00 | 1.22 | 0.00 | 0.66 | 26.72 | 46.24 | -8.67 | 20.65 | 0.3835 | 802.0 | 631.4 | |
| 0.00 | 0.96 | 0.00 | 0.52 | 27.17 | 46.11 | -8.81 | 20.49 | 0.3909 | 759.0 | 603.7 | |
| 0.00 | 1.92 | 0.00 | 1.04 | 27.49 | 45.91 | -9.00 | 20.58 | 0.3967 | 301.0 | 319.2 | |
| 0.00 | 2.36 | 0.00 | 1.24 | 23.65 | 46.03 | -8.88 | 24.76 | 0.3392 | 816.0 | 588.5 | |
| 0.00 | 1.66 | 0.00 | 0.89 | 27.26 | 45.69 | -9.22 | 21.26 | 0.3946 | 935.0 | 716.2 | |
| 0.00 | 3.06 | 0.00 | 1.65 | 27.03 | 45.27 | -9.65 | 22.38 | 0.3937 | 757.0 | 677.5 | |
| 0.00 | 1.48 | 0.00 | 0.80 | 26.80 | 45.25 | -9.66 | 22.66 | 0.3906 | 872.0 | 667.9 | |
| 0.00 | 1.57 | 0.00 | 0.81 | 19.86 | 44.85 | -10.07 | 34.01 | 0.2952 | 990.0 | 765.1 | |
| 0.00 | 1.13 | 0.00 | 0.61 | 25.48 | 44.19 | -10.73 | 26.47 | 0.3786 | 885.0 | 703.9 | |
| 0.00 | 0.79 | 0.00 | 0.42 | 25.32 | 44.10 | -10.81 | 26.86 | 0.3770 | 715.0 | 532.8 | |
| 0.00 | 1.31 | 0.00 | 0.70 | 25.70 | 43.86 | -11.05 | 26.86 | 0.3840 | 757.0 | 647.0 | |
| 0.00 | 1.75 | 0.00 | 0.91 | 20.29 | 44.27 | -10.64 | 34.62 | 0.3062 | 924.0 | 630.8 | |
| 1.66 | 3.93 | 0.93 | 2.20 | 29.85 | 40.46 | -14.46 | 27.87 | 0.4652 | 740.9 | 582.2 | |
| 0.00 | 1.22 | 0.00 | 0.68 | 28.38 | 39.01 | -15.90 | 31.95 | 0.4575 | 700.0 | 506.4 | |
| 0.00 | 0.79 | 0.00 | 0.43 | 26.60 | 38.65 | -16.27 | 34.99 | 0.4386 | 719.0 | 595.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
