SDO HMI 2011-10-16 02:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 253.66 | 796.03 | 126.25 | 396.35 | 10.63 | 51.07 | 0.01 | 335.67 | 0.0990 | -216.7 | -6.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-16 02:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.58 | 25.07 | 1.78 | 12.48 | 8.66 | 55.83 | 4.77 | 301.13 | 0.0965 | -1187.8 | -704.4 | |
| 0.00 | 2.88 | 0.00 | 1.43 | 8.09 | 55.76 | 4.70 | 296.09 | 0.0908 | -899.0 | -777.6 | |
| 0.52 | -1.00 | 0.26 | -1.00 | 8.84 | 55.53 | 4.47 | 304.43 | 0.0938 | -1088.2 | 999999 | |
| 7.51 | 12.49 | 3.74 | 6.21 | 8.33 | 55.49 | 4.43 | 299.87 | 0.0886 | -1190.8 | -1007.6 | |
| 0.00 | 1.40 | 0.00 | 0.70 | 8.96 | 55.26 | 4.20 | 307.19 | 0.0912 | -956.0 | -808.5 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 10.97 | 54.98 | 3.92 | 323.23 | 0.1127 | 962.0 | 672.6 | |
| 0.00 | 1.40 | 0.00 | 0.70 | 9.65 | 54.90 | 3.84 | 315.35 | 0.0945 | -862.0 | -759.4 | |
| 0.00 | 0.96 | 0.00 | 0.48 | 9.38 | 54.87 | 3.81 | 313.49 | 0.0908 | -669.0 | -518.1 | |
| 0.00 | 1.75 | 0.00 | 0.87 | 10.31 | 54.70 | 3.64 | 321.45 | 0.1007 | -301.0 | -100.3 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 7.71 | 54.52 | 3.46 | 298.88 | 0.0686 | -860.0 | -680.7 | |
| 16.07 | 32.76 | 7.99 | 16.28 | 9.24 | 54.38 | 3.32 | 316.16 | 0.0830 | -1211.1 | -704.7 | |
| 1.66 | 263.38 | 0.83 | 130.93 | 10.35 | 54.24 | 3.18 | 325.30 | 0.0964 | -764.6 | -607.8 | |
| 1.75 | -12.00 | 0.87 | -12.00 | 9.96 | 54.21 | 3.15 | 323.12 | 0.0906 | -944.5 | 999999 | |
| 0.00 | 0.52 | 0.00 | 0.26 | 8.79 | 54.17 | 3.11 | 314.02 | 0.0748 | -828.0 | -611.5 | |
| 0.87 | -12.00 | 0.43 | -12.00 | 10.41 | 54.00 | 2.94 | 327.75 | 0.0949 | 139.4 | 999999 | |
| 4.37 | -12.00 | 2.17 | -12.00 | 10.17 | 53.81 | 2.75 | 328.01 | 0.0897 | -971.4 | 999999 | |
| 13.10 | -12.00 | 6.52 | -12.00 | 10.53 | 53.79 | 2.73 | 330.29 | 0.0949 | -834.9 | 999999 | |
| 0.00 | 2.01 | 0.00 | 1.00 | 8.55 | 53.74 | 2.68 | 315.81 | 0.0667 | -903.0 | -715.8 | |
| 45.51 | -12.00 | 22.62 | -12.00 | 9.87 | 53.72 | 2.66 | 327.04 | 0.0845 | -1270.0 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.56 | 8.97 | 53.59 | 2.53 | 321.50 | 0.0705 | -812.0 | -667.8 | |
| 2.10 | -12.00 | 1.04 | -12.00 | 10.56 | 53.48 | 2.42 | 333.26 | 0.0928 | -764.0 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 9.12 | 53.32 | 2.26 | 325.88 | 0.0698 | -900.0 | -727.9 | |
| 16.34 | -12.00 | 8.12 | -12.00 | 9.81 | 53.23 | 2.18 | 331.71 | 0.0793 | -1238.0 | 999999 | |
| 6.11 | 56.26 | 3.05 | 28.03 | 11.67 | 53.10 | 2.04 | 341.13 | 0.1081 | 1217.0 | 415.8 | |
| 1.83 | -12.00 | 0.91 | -12.00 | 10.32 | 53.06 | 2.00 | 336.38 | 0.0859 | -1156.6 | 999999 | |
| 10.74 | -24.00 | 5.36 | -24.00 | 12.03 | 52.91 | 1.86 | 343.67 | 0.1131 | 1169.1 | 999999 | |
| 1.31 | -12.00 | 0.65 | -12.00 | 10.29 | 52.87 | 1.81 | 338.19 | 0.0842 | -941.6 | 999999 | |
| 5.33 | -12.00 | 2.65 | -12.00 | 9.51 | 52.81 | 1.75 | 334.91 | 0.0713 | -1123.5 | 999999 | |
| 0.00 | 3.06 | 0.00 | 1.52 | 11.28 | 52.67 | 1.61 | 343.87 | 0.0994 | -275.0 | -49.8 | |
| 6.90 | -12.00 | 3.43 | -12.00 | 10.53 | 52.60 | 1.54 | 342.12 | 0.0866 | -989.0 | 999999 | |
| 4.28 | -12.00 | 2.13 | -12.00 | 10.17 | 52.54 | 1.48 | 341.46 | 0.0803 | -1035.4 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 11.46 | 52.48 | 1.42 | 346.06 | 0.1016 | 837.0 | 504.6 | |
| 11.88 | -12.00 | 5.90 | -12.00 | 9.45 | 52.38 | 1.32 | 340.17 | 0.0675 | -1059.2 | 999999 | |
| 1.49 | -12.00 | 0.74 | -12.00 | 10.38 | 52.39 | 1.33 | 343.98 | 0.0830 | -862.5 | 999999 | |
| 0.61 | -12.00 | 0.30 | -12.00 | 10.59 | 52.30 | 1.24 | 345.66 | 0.0861 | -904.1 | 999999 | |
| 0.00 | 5.07 | 0.00 | 2.53 | 12.39 | 52.18 | 1.12 | 350.49 | 0.1165 | 1158.0 | 856.7 | |
| 0.00 | 2.36 | 0.00 | 1.17 | 11.79 | 52.12 | 1.06 | 350.11 | 0.1060 | 188.0 | 186.1 | |
| 5.59 | 12.84 | 2.78 | 6.38 | 10.32 | 51.99 | 0.93 | 348.44 | 0.0803 | -911.7 | -657.7 | |
| 0.00 | 0.96 | 0.00 | 0.49 | 18.58 | 52.00 | 0.94 | 355.98 | 0.2223 | -962.0 | -679.2 | |
| 0.00 | 1.40 | 0.00 | 0.69 | 9.72 | 51.93 | 0.87 | 347.57 | 0.0699 | -692.0 | -542.1 | |
| 0.00 | 3.06 | 0.00 | 1.52 | 9.10 | 51.90 | 0.84 | 345.76 | 0.0591 | -991.0 | -689.3 | |
| 0.00 | 1.22 | 0.00 | 0.62 | 19.10 | 51.84 | 0.78 | 356.79 | 0.2310 | -674.0 | -546.4 | |
| 0.00 | 1.66 | 0.00 | 0.83 | 11.34 | 51.75 | 0.69 | 352.97 | 0.0973 | -929.0 | -586.9 | |
| 1.49 | 4.46 | 0.74 | 2.22 | 12.40 | 51.66 | 0.60 | 354.86 | 0.1153 | 943.5 | 747.3 | |
| 0.00 | 5.07 | 0.00 | 2.52 | 9.91 | 51.51 | 0.45 | 353.83 | 0.0718 | -252.0 | -345.4 | |
| 0.00 | 1.83 | 0.00 | 0.91 | 10.17 | 51.11 | 0.05 | 359.32 | 0.0761 | -1071.0 | -747.6 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 8.47 | 50.87 | -0.19 | 4.07 | 0.0464 | -1018.0 | -715.9 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 13.12 | 50.87 | -0.19 | 1.48 | 0.1275 | -909.0 | -621.9 | |
| 1.83 | 3.41 | 0.91 | 1.70 | 11.52 | 50.84 | -0.22 | 2.19 | 0.0997 | -938.3 | -760.9 | |
| 0.00 | 1.66 | 0.00 | 0.82 | 10.20 | 50.81 | -0.25 | 3.24 | 0.0767 | -975.0 | -750.8 | |
| 0.00 | 1.14 | 0.00 | 0.57 | 13.21 | 50.71 | -0.35 | 2.62 | 0.1291 | -941.0 | -767.2 | |
| 1.14 | 7.77 | 0.56 | 3.87 | 10.83 | 50.60 | -0.46 | 5.22 | 0.0880 | -1054.9 | -470.8 | |
| 0.00 | 5.07 | 0.00 | 2.51 | 8.32 | 50.60 | -0.46 | 10.40 | 0.0443 | -1098.0 | -880.2 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 13.30 | 50.56 | -0.50 | 3.74 | 0.1309 | -713.0 | -580.1 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 12.40 | 50.53 | -0.53 | 4.50 | 0.1152 | 917.0 | 662.9 | |
| 0.00 | 0.96 | 0.00 | 0.48 | 9.96 | 50.44 | -0.62 | 8.34 | 0.0732 | -791.0 | -554.6 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 9.58 | 50.32 | -0.74 | 10.97 | 0.0668 | 993.0 | 841.4 | |
| 0.00 | 1.05 | 0.00 | 0.52 | 7.78 | 50.33 | -0.73 | 20.40 | 0.0365 | -858.0 | -665.0 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 12.55 | 50.13 | -0.93 | 7.69 | 0.1186 | 713.0 | 454.1 | |
| 0.00 | 2.45 | 0.00 | 1.21 | 8.77 | 49.87 | -1.19 | 21.79 | 0.0554 | -887.0 | -609.2 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 12.24 | 49.74 | -1.32 | 11.42 | 0.1145 | 1013.0 | 904.5 | |
| 0.00 | 0.87 | 0.00 | 0.43 | 9.60 | 49.69 | -1.37 | 19.73 | 0.0703 | -321.0 | -217.4 | |
| 8.74 | 101.51 | 4.34 | 50.46 | 10.50 | 49.56 | -1.50 | 17.50 | 0.0858 | 1242.4 | 371.8 | |
| 0.00 | 14.94 | 0.00 | 7.44 | 11.79 | 49.46 | -1.60 | 14.70 | 0.1079 | 806.0 | 545.9 | |
| 0.00 | 2.10 | 0.00 | 1.05 | 14.68 | 49.29 | -1.77 | 10.98 | 0.1576 | 866.0 | 796.5 | |
| 4.98 | -63.00 | 2.47 | -63.00 | 10.23 | 49.29 | -1.77 | 21.59 | 0.0830 | 1354.0 | 999999 | |
| 1.83 | -63.00 | 0.91 | -63.00 | 10.44 | 49.26 | -1.80 | 21.02 | 0.0866 | 1190.3 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.61 | 9.66 | 49.02 | -2.04 | 27.68 | 0.0759 | -855.0 | -643.4 | |
| 1.31 | -63.00 | 0.65 | -63.00 | 10.17 | 48.96 | -2.10 | 25.50 | 0.0843 | -559.9 | 999999 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 11.91 | 48.88 | -2.18 | 19.32 | 0.1128 | -822.0 | -526.7 | |
| 0.00 | 0.87 | 0.00 | 0.45 | 20.05 | 48.76 | -2.30 | 8.72 | 0.2498 | 984.0 | 759.8 | |
| 7.69 | -63.00 | 3.82 | -63.00 | 10.74 | 48.83 | -2.23 | 24.04 | 0.0942 | -1096.6 | 999999 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 9.63 | 48.75 | -2.31 | 30.94 | 0.0777 | -921.0 | -756.4 | |
| 1.92 | 55.30 | 0.96 | 27.59 | 12.03 | 48.48 | -2.58 | 22.13 | 0.1172 | 765.1 | 326.8 | |
| 20.97 | -74.00 | 10.46 | -74.00 | 12.06 | 48.09 | -2.97 | 25.04 | 0.1204 | 1178.4 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.74 | 8.61 | 47.91 | -3.15 | 48.19 | 0.0733 | 898.0 | 677.7 | |
| 0.00 | 1.57 | 0.00 | 0.78 | 9.93 | 47.65 | -3.41 | 39.28 | 0.0929 | 887.0 | 629.4 | |
| 0.00 | 1.49 | 0.00 | 0.74 | 8.97 | 47.48 | -3.58 | 48.33 | 0.0829 | 1080.0 | 829.9 | |
| 0.00 | 2.27 | 0.00 | 1.13 | 10.82 | 47.43 | -3.63 | 35.49 | 0.1076 | 1157.0 | 928.9 | |
| 0.00 | 0.96 | 0.00 | 0.49 | 20.88 | 47.21 | -3.85 | 13.57 | 0.2685 | 746.0 | 668.3 | |
| 2.18 | 8.04 | 1.09 | 4.00 | 9.68 | 47.32 | -3.74 | 43.64 | 0.0936 | 1210.6 | 905.9 | |
| 0.00 | 2.80 | 0.00 | 1.44 | 21.84 | 47.06 | -4.00 | 13.21 | 0.2848 | 838.0 | 620.9 | |
| 4.19 | 6.99 | 2.09 | 3.49 | 11.21 | 46.84 | -4.22 | 37.49 | 0.1190 | 1194.1 | 866.1 | |
| 1.05 | 73.47 | 0.52 | 36.73 | 11.81 | 46.65 | -4.41 | 35.77 | 0.1293 | 907.7 | 761.8 | |
| 0.00 | 1.31 | 0.00 | 0.65 | 8.63 | 46.64 | -4.42 | 57.20 | 0.0912 | 985.0 | 823.4 | |
| 4.54 | -84.00 | 2.27 | -84.00 | 11.87 | 46.41 | -4.65 | 36.97 | 0.1326 | 1118.0 | 999999 | |
| 0.00 | 1.92 | 0.00 | 0.96 | 8.90 | 46.45 | -4.61 | 55.86 | 0.0964 | 1061.0 | 779.6 | |
| 0.87 | -84.00 | 0.44 | -84.00 | 11.57 | 46.38 | -4.68 | 38.56 | 0.1288 | 1174.4 | 999999 | |
| 0.00 | 2.10 | 0.00 | 1.05 | 11.30 | 46.38 | -4.67 | 39.91 | 0.1252 | 835.0 | 639.4 | |
| 4.54 | -84.00 | 2.27 | -84.00 | 11.89 | 46.01 | -5.05 | 39.11 | 0.1372 | 1146.0 | 999999 | |
| 0.00 | 1.49 | 0.00 | 0.74 | 8.83 | 45.78 | -5.28 | 59.84 | 0.1056 | 970.0 | 682.8 | |
| 0.00 | 1.49 | 0.00 | 0.74 | 11.62 | 45.68 | -5.38 | 42.22 | 0.1374 | 987.0 | 819.6 | |
| 1.57 | 1.75 | 0.79 | 0.87 | 11.62 | 45.40 | -5.66 | 43.64 | 0.1406 | 954.1 | 808.0 | |
| 0.00 | 2.10 | 0.00 | 1.05 | 11.49 | 45.16 | -5.90 | 45.45 | 0.1421 | 933.0 | 672.9 | |
| 0.00 | 1.92 | 0.00 | 0.96 | 11.16 | 44.95 | -6.11 | 48.17 | 0.1408 | 738.0 | 640.1 | |
| 0.00 | 2.53 | 0.00 | 1.27 | 11.33 | 44.21 | -6.85 | 50.44 | 0.1524 | 1080.0 | 881.7 | |
| 13.37 | 17.12 | 6.69 | 8.57 | 10.58 | 44.17 | -6.89 | 54.69 | 0.1453 | 1208.3 | 757.2 | |
| 0.00 | 1.40 | 0.00 | 0.70 | 9.91 | 42.80 | -8.26 | 62.99 | 0.1595 | 1055.0 | 856.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
