SDO HMI 2011-10-16 06:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.97 | 28.22 | 5.09 | 47.08 | -14.64 | 119.29 | 70.42 | 252.68 | 0.9560 | 190.6 | 304.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-16 06:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 9.78 | 0.00 | 16.60 | -14.09 | 119.67 | 70.80 | 253.32 | 0.9575 | 591.0 | 467.8 | |
| 2.97 | 15.38 | 5.09 | 26.23 | -14.70 | 119.74 | 70.87 | 252.71 | 0.9584 | 398.3 | 289.2 | |
| 0.00 | 0.79 | 0.00 | 1.10 | -15.55 | 115.49 | 66.62 | 250.95 | 0.9371 | -289.0 | -207.0 | |
| 0.00 | 0.87 | 0.00 | 1.20 | -16.24 | 114.77 | 65.90 | 250.07 | 0.9339 | -434.0 | -361.6 | |
| 0.00 | 1.40 | 0.00 | 1.95 | -17.02 | 115.00 | 66.13 | 249.30 | 0.9363 | -163.0 | -227.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
