SDO HMI 2011-10-16 07:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 146.32 | 703.48 | 76.28 | 366.78 | -12.11 | 49.18 | 0.86 | 182.80 | 0.3135 | -48.7 | -45.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-16 07:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.31 | 0.00 | 0.70 | -15.60 | 53.63 | 5.31 | 193.73 | 0.3769 | 668.0 | 504.1 | |
| 0.96 | 277.79 | 0.50 | 144.79 | -11.64 | 53.36 | 5.03 | 196.02 | 0.3127 | 921.7 | 388.5 | |
| 19.04 | -2.00 | 9.92 | -2.00 | -11.67 | 53.05 | 4.73 | 195.07 | 0.3118 | 1381.5 | 999999 | |
| 23.76 | -2.00 | 12.38 | -2.00 | -11.82 | 52.50 | 4.18 | 193.28 | 0.3121 | 1298.6 | 999999 | |
| 0.44 | -2.00 | 0.23 | -2.00 | -11.41 | 52.19 | 3.87 | 192.61 | 0.3043 | 1104.6 | 999999 | |
| 2.97 | -2.00 | 1.55 | -2.00 | -11.78 | 52.17 | 3.84 | 192.26 | 0.3103 | 1124.2 | 999999 | |
| 2.10 | -2.00 | 1.09 | -2.00 | -11.78 | 51.95 | 3.63 | 191.60 | 0.3095 | 1045.0 | 999999 | |
| 0.00 | 1.14 | 0.00 | 0.60 | -15.43 | 51.39 | 3.06 | 188.10 | 0.3671 | 761.0 | 651.8 | |
| 14.76 | 36.51 | 7.68 | 19.00 | -11.81 | 50.88 | 2.56 | 188.22 | 0.3069 | 1129.6 | 503.6 | |
| 0.00 | 1.22 | 0.00 | 0.63 | -11.37 | 50.54 | 2.22 | 187.33 | 0.2988 | 910.0 | 729.1 | |
| 0.00 | 1.75 | 0.00 | 0.91 | -11.24 | 50.36 | 2.04 | 186.78 | 0.2964 | 769.0 | 645.5 | |
| 0.00 | 1.14 | 0.00 | 0.59 | -10.71 | 49.96 | 1.64 | 185.64 | 0.2868 | 921.0 | 669.5 | |
| 0.00 | 0.87 | 0.00 | 0.45 | -10.21 | 49.77 | 1.45 | 185.16 | 0.2782 | 783.0 | 599.9 | |
| 0.00 | 1.05 | 0.00 | 0.55 | -12.24 | 49.33 | 1.00 | 183.16 | 0.3115 | -720.0 | -535.7 | |
| 1.57 | 375.11 | 0.82 | 195.61 | -13.25 | 47.15 | -1.17 | 176.51 | 0.3284 | -837.9 | -431.4 | |
| 3.49 | -15.00 | 1.82 | -15.00 | -11.93 | 47.06 | -1.26 | 175.96 | 0.3066 | -905.5 | 999999 | |
| 0.00 | 1.05 | 0.00 | 0.55 | -14.49 | 46.99 | -1.33 | 176.28 | 0.3490 | -654.0 | -595.2 | |
| 13.80 | -15.00 | 7.23 | -15.00 | -13.13 | 46.81 | -1.51 | 175.48 | 0.3268 | -1084.8 | 999999 | |
| 15.03 | -15.00 | 7.82 | -15.00 | -11.87 | 46.51 | -1.81 | 174.19 | 0.3064 | -1434.6 | 999999 | |
| 3.93 | -15.00 | 2.05 | -15.00 | -12.12 | 46.51 | -1.81 | 174.27 | 0.3105 | -1209.0 | 999999 | |
| 23.06 | -15.00 | 12.04 | -15.00 | -12.53 | 46.48 | -1.84 | 174.30 | 0.3174 | -1032.3 | 999999 | |
| 19.66 | -15.00 | 10.24 | -15.00 | -12.15 | 46.02 | -2.30 | 172.75 | 0.3120 | -1186.9 | 999999 | |
| 1.75 | -15.00 | 0.91 | -15.00 | -12.40 | 45.99 | -2.33 | 172.75 | 0.3162 | -934.2 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.50 | -11.31 | 45.54 | -2.78 | 170.81 | 0.2992 | -97.0 | -81.3 | |
| 0.00 | 2.27 | 0.00 | 1.20 | -13.58 | 44.47 | -3.85 | 168.86 | 0.3395 | -646.0 | -484.3 | |
| 0.00 | 1.31 | 0.00 | 0.70 | -14.80 | 43.52 | -4.80 | 167.03 | 0.3622 | -843.0 | -660.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
