SDO HMI 2011-10-16 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.24 | 191.74 | 16.18 | 114.03 | -26.71 | 37.03 | -9.10 | 165.26 | 0.5567 | 931.5 | 381.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-16 11:59:02 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 27.24 | 176.71 | 16.18 | 104.91 | -26.64 | 37.36 | -8.77 | 165.71 | 0.5544 | 1112.6 | 363.9 | |
| 0.00 | 1.75 | 0.00 | 1.06 | -28.02 | 34.39 | -11.74 | 162.05 | 0.5851 | 657.0 | 445.4 | |
| 0.00 | 0.96 | 0.00 | 0.57 | -25.83 | 33.94 | -12.19 | 160.00 | 0.5578 | 612.0 | 421.1 | |
| 0.00 | 1.31 | 0.00 | 0.80 | -27.61 | 33.71 | -12.42 | 160.83 | 0.5826 | 626.0 | 537.7 | |
| 0.00 | 0.70 | 0.00 | 0.41 | -25.52 | 33.91 | -12.22 | 159.73 | 0.5537 | 698.0 | 584.1 | |
| 0.00 | 1.31 | 0.00 | 0.80 | -27.98 | 33.39 | -12.74 | 160.61 | 0.5890 | 793.0 | 711.1 | |
| 0.00 | 1.66 | 0.00 | 1.02 | -28.59 | 33.14 | -12.99 | 160.66 | 0.5982 | 731.0 | 554.4 | |
| 0.00 | 1.14 | 0.00 | 0.69 | -27.66 | 33.19 | -12.94 | 160.12 | 0.5858 | 735.0 | 637.2 | |
| 0.00 | 1.40 | 0.00 | 0.86 | -28.60 | 33.00 | -13.13 | 160.47 | 0.5989 | 632.0 | 500.4 | |
| 0.00 | 2.88 | 0.00 | 1.76 | -27.95 | 33.05 | -13.08 | 160.12 | 0.5902 | 657.0 | 586.8 | |
| 0.00 | 0.87 | 0.00 | 0.50 | -22.53 | 33.60 | -12.53 | 156.99 | 0.5148 | 614.0 | 545.2 | |
| 0.00 | 1.05 | 0.00 | 0.65 | -27.37 | 30.48 | -15.66 | 156.21 | 0.5963 | 561.0 | 463.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
