SDO HMI 2011-10-16 14:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.92 | 184.39 | 15.33 | 109.25 | -26.71 | 37.05 | -7.43 | 167.86 | 0.5510 | 1013.2 | 396.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-16 14:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 25.92 | 171.65 | 15.33 | 101.50 | -26.62 | 37.34 | -7.14 | 168.26 | 0.5487 | 1183.9 | 379.3 | |
| 0.00 | 1.66 | 0.00 | 1.00 | -27.75 | 33.68 | -10.81 | 163.23 | 0.5774 | 738.0 | 540.7 | |
| 0.00 | 0.87 | 0.00 | 0.53 | -27.29 | 33.59 | -10.90 | 162.84 | 0.5715 | 595.0 | 513.3 | |
| 0.00 | 1.66 | 0.00 | 1.01 | -27.97 | 33.41 | -11.07 | 162.98 | 0.5815 | 777.0 | 680.4 | |
| 0.00 | 1.13 | 0.00 | 0.70 | -28.66 | 33.17 | -11.32 | 163.02 | 0.5918 | 796.0 | 657.4 | |
| 0.00 | 4.63 | 0.00 | 2.80 | -27.72 | 33.27 | -11.22 | 162.62 | 0.5788 | 716.0 | 590.8 | |
| 0.00 | 0.35 | 0.00 | 0.20 | -22.69 | 33.73 | -10.75 | 160.08 | 0.5073 | 590.0 | 591.2 | |
| 0.00 | 1.83 | 0.00 | 1.12 | -28.01 | 33.13 | -11.35 | 162.60 | 0.5832 | 673.0 | 580.5 | |
| 0.00 | 0.61 | 0.00 | 0.39 | -31.87 | 30.54 | -13.94 | 161.41 | 0.6441 | 604.0 | 513.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
