SDO HMI 2011-10-17 08:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.97 | 181.66 | 15.83 | 106.70 | -26.67 | 37.07 | 2.49 | 184.15 | 0.5393 | 1070.1 | 366.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-17 08:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 26.97 | 176.08 | 15.83 | 103.37 | -26.64 | 37.25 | 2.67 | 184.45 | 0.5388 | 1198.0 | 360.7 | |
| 0.00 | 1.22 | 0.00 | 0.73 | -28.24 | 33.56 | -1.03 | 178.38 | 0.5610 | 615.0 | 534.8 | |
| 0.00 | 1.57 | 0.00 | 0.90 | -24.40 | 31.72 | -2.86 | 174.82 | 0.5057 | 849.0 | 615.1 | |
| 0.00 | 0.87 | 0.00 | 0.53 | -29.20 | 30.46 | -4.12 | 173.74 | 0.5778 | 440.0 | 287.3 | |
| 0.00 | 1.05 | 0.00 | 0.64 | -29.24 | 30.09 | -4.50 | 173.18 | 0.5790 | 737.0 | 557.1 | |
| 0.00 | 0.87 | 0.00 | 0.53 | -29.06 | 29.96 | -4.63 | 172.95 | 0.5766 | 684.0 | 496.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
