SDO HMI 2011-10-17 17:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.58 | 44.91 | 23.88 | 52.22 | 20.16 | 94.73 | 65.09 | 289.64 | 0.9055 | 263.0 | -143.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-17 17:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.27 | 3.66 | 2.91 | 4.69 | 19.59 | 97.55 | 67.91 | 288.87 | 0.9242 | -412.7 | -460.0 | |
| 1.66 | 8.02 | 2.08 | 10.05 | 18.92 | 96.97 | 67.33 | 288.16 | 0.9204 | -442.3 | -522.1 | |
| 1.57 | -2.00 | 1.96 | -2.00 | 19.18 | 96.86 | 67.22 | 288.45 | 0.9197 | -627.8 | 999999 | |
| 0.00 | 1.92 | 0.00 | 2.21 | 20.77 | 94.60 | 64.96 | 290.31 | 0.9051 | -326.0 | -217.3 | |
| 12.29 | 30.26 | 13.75 | 34.14 | 20.37 | 93.69 | 64.05 | 289.93 | 0.8985 | 639.5 | -12.7 | |
| 2.79 | -5.00 | 3.18 | -5.00 | 20.96 | 94.16 | 64.52 | 290.55 | 0.9021 | 367.1 | 999999 | |
| 0.00 | 1.05 | 0.00 | 1.13 | 21.35 | 92.57 | 62.93 | 291.11 | 0.8909 | 524.0 | 509.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
