SDO HMI 2011-10-17 18:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 108.13 | 564.49 | 59.98 | 313.04 | -12.34 | 48.72 | 19.63 | 226.87 | 0.4503 | -236.0 | -125.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-17 18:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.13 | 0.00 | 0.65 | -9.60 | 55.45 | 26.36 | 239.90 | 0.5081 | 668.0 | 503.5 | |
| 11.95 | 168.02 | 6.82 | 95.71 | -11.87 | 53.23 | 24.14 | 233.76 | 0.4983 | 1130.0 | 388.2 | |
| 1.31 | -2.00 | 0.75 | -2.00 | -12.18 | 53.03 | 23.94 | 233.02 | 0.4985 | 702.6 | 999999 | |
| 14.74 | -2.00 | 8.37 | -2.00 | -11.94 | 52.60 | 23.52 | 232.92 | 0.4913 | 1249.4 | 999999 | |
| 2.79 | -2.00 | 1.58 | -2.00 | -11.94 | 51.97 | 22.88 | 232.16 | 0.4837 | 1016.5 | 999999 | |
| 0.00 | 4.19 | 0.00 | 2.36 | -11.93 | 51.61 | 22.52 | 231.74 | 0.4792 | 785.0 | 701.3 | |
| 0.00 | 1.22 | 0.00 | 0.69 | -11.98 | 51.38 | 22.29 | 231.37 | 0.4770 | 976.0 | 875.1 | |
| 0.00 | 1.40 | 0.00 | 0.78 | -12.00 | 50.92 | 21.83 | 230.77 | 0.4716 | 845.0 | 640.1 | |
| 6.37 | 10.20 | 3.56 | 5.70 | -11.73 | 50.54 | 21.45 | 230.72 | 0.4645 | 972.1 | 766.2 | |
| 0.00 | 0.87 | 0.00 | 0.48 | -9.81 | 49.94 | 20.85 | 233.34 | 0.4390 | 769.0 | 566.8 | |
| 0.00 | 1.05 | 0.00 | 0.58 | -12.37 | 50.06 | 20.98 | 229.02 | 0.4652 | 839.0 | 643.8 | |
| 0.00 | 0.78 | 0.00 | 0.44 | -12.32 | 49.57 | 20.48 | 228.42 | 0.4589 | 582.0 | 539.8 | |
| 6.54 | 372.06 | 3.58 | 203.72 | -11.99 | 47.18 | 18.09 | 225.45 | 0.4281 | -1131.3 | -407.9 | |
| 2.53 | -13.00 | 1.39 | -13.00 | -12.27 | 47.10 | 18.02 | 224.85 | 0.4303 | -764.6 | 999999 | |
| 15.08 | -13.00 | 8.32 | -13.00 | -13.25 | 47.11 | 18.02 | 223.27 | 0.4413 | -968.2 | 999999 | |
| 1.83 | -13.00 | 1.00 | -13.00 | -11.92 | 46.95 | 17.86 | 225.20 | 0.4248 | -1273.6 | 999999 | |
| 8.72 | -13.00 | 4.77 | -13.00 | -12.13 | 46.77 | 17.69 | 224.55 | 0.4252 | -1332.7 | 999999 | |
| 36.27 | -13.00 | 19.84 | -13.00 | -12.56 | 46.39 | 17.30 | 223.21 | 0.4257 | -1202.7 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.66 | -11.65 | 45.27 | 16.19 | 222.84 | 0.4032 | 620.0 | 363.9 | |
| 0.00 | 1.13 | 0.00 | 0.61 | -12.24 | 44.10 | 15.02 | 219.72 | 0.3980 | -859.0 | -653.2 | |
| 0.00 | 1.22 | 0.00 | 0.66 | -11.95 | 43.68 | 14.59 | 219.39 | 0.3900 | -837.0 | -631.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
