SDO HMI 2011-10-17 21:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 3.14 | 25.70 | 2.90 | 22.69 | 23.83 | 332.45 | -54.98 | 64.97 | 0.8271 | -351.8 | -336.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-17 21:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.48 | 0.00 | 1.16 | 21.19 | 337.50 | -49.93 | 67.19 | 0.7764 | -593.0 | -488.9 | |
| 0.00 | 1.57 | 0.00 | 1.23 | 20.72 | 337.46 | -49.97 | 67.80 | 0.7758 | -547.0 | -467.8 | |
| 0.00 | 0.87 | 0.00 | 0.73 | 24.08 | 334.85 | -52.58 | 64.18 | 0.8078 | -581.0 | -506.2 | |
| 2.01 | 6.80 | 1.70 | 5.79 | 23.40 | 333.93 | -53.50 | 65.20 | 0.8149 | -881.7 | -552.0 | |
| 0.00 | 1.13 | 0.00 | 0.96 | 23.05 | 334.02 | -53.41 | 65.60 | 0.8135 | -495.0 | -474.5 | |
| 0.00 | 1.13 | 0.00 | 0.97 | 23.16 | 333.80 | -53.63 | 65.51 | 0.8158 | -623.0 | -622.1 | |
| 0.00 | 1.83 | 0.00 | 1.55 | 22.89 | 333.90 | -53.53 | 65.82 | 0.8143 | -653.0 | -565.3 | |
| 0.00 | 0.35 | 0.00 | 0.30 | 23.37 | 333.51 | -53.92 | 65.32 | 0.8187 | -230.0 | -318.2 | |
| 0.00 | 0.61 | 0.00 | 0.52 | 22.69 | 333.85 | -53.58 | 66.07 | 0.8144 | -521.0 | -481.0 | |
| 0.00 | 1.13 | 0.00 | 0.97 | 23.17 | 333.51 | -53.92 | 65.55 | 0.8184 | -393.0 | -339.3 | |
| 0.00 | 1.92 | 0.00 | 1.64 | 22.82 | 333.44 | -53.99 | 65.99 | 0.8184 | -512.0 | -392.4 | |
| 0.00 | 0.78 | 0.00 | 0.68 | 22.86 | 333.20 | -54.23 | 65.99 | 0.8207 | -253.0 | -170.1 | |
| 0.00 | 0.87 | 0.00 | 0.76 | 23.20 | 332.60 | -54.83 | 65.69 | 0.8266 | -341.0 | -306.9 | |
| 0.00 | 0.96 | 0.00 | 0.90 | 24.15 | 330.09 | -57.34 | 65.00 | 0.8497 | -151.0 | -127.4 | |
| 0.00 | 0.78 | 0.00 | 0.83 | 27.84 | 326.05 | -61.38 | 61.44 | 0.8858 | 283.0 | 229.1 | |
| 0.00 | 2.18 | 0.00 | 2.32 | 27.55 | 325.83 | -61.60 | 61.79 | 0.8870 | 242.0 | 230.4 | |
| 1.13 | 1.31 | 1.20 | 1.38 | 26.74 | 325.96 | -61.47 | 62.68 | 0.8851 | 474.5 | 518.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
