SDO HMI 2011-10-17 23:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 13.61 | 140.27 | 26.83 | 366.65 | 11.47 | 306.47 | -79.86 | 79.38 | 0.9794 | -257.1 | -2.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-17 23:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.28 | 42.13 | 11.85 | 79.46 | 11.99 | 310.73 | -75.60 | 79.10 | 0.9661 | -443.4 | -154.3 | |
| 0.00 | 3.75 | 0.00 | 7.56 | 10.77 | 309.80 | -76.53 | 80.31 | 0.9703 | -483.0 | -409.7 | |
| 0.00 | 1.92 | 0.00 | 4.08 | 10.93 | 308.97 | -77.36 | 80.09 | 0.9736 | 238.0 | 164.9 | |
| 7.33 | 50.51 | 14.98 | 103.88 | 9.75 | 309.65 | -76.68 | 81.35 | 0.9712 | -495.9 | -210.4 | |
| 0.00 | 2.44 | 0.00 | 5.85 | 12.12 | 307.33 | -79.00 | 78.78 | 0.9794 | -14.0 | -40.4 | |
| 0.00 | 1.22 | 0.00 | 2.75 | 10.61 | 308.22 | -78.10 | 80.37 | 0.9765 | 250.0 | 229.5 | |
| 0.00 | 5.50 | 0.00 | 12.34 | 10.32 | 308.34 | -77.99 | 80.68 | 0.9762 | 190.0 | 218.6 | |
| 0.00 | 9.60 | 0.00 | 25.09 | 11.60 | 306.39 | -79.94 | 79.25 | 0.9826 | 617.0 | 417.2 | |
| 0.00 | 5.15 | 0.00 | 14.80 | 11.07 | 305.33 | -81.00 | 79.72 | 0.9859 | -43.0 | -89.6 | |
| 0.00 | 5.84 | 0.00 | 47.82 | 13.67 | 298.65 | -87.68 | 76.60 | 0.9983 | 102.0 | 108.3 | |
| 0.00 | 1.22 | 0.00 | 3.58 | 10.69 | 305.20 | -81.13 | 80.10 | 0.9863 | 192.0 | 112.4 | |
| 0.00 | 1.57 | 0.00 | 6.25 | 12.21 | 302.56 | -83.77 | 78.38 | 0.9925 | 462.0 | 393.9 | |
| 0.00 | 1.83 | 0.00 | 6.01 | 11.40 | 304.00 | -82.33 | 79.30 | 0.9894 | 243.0 | 203.8 | |
| 0.00 | 6.11 | 0.00 | 39.95 | 12.77 | 299.87 | -86.46 | 77.60 | 0.9970 | 279.0 | 163.9 | |
| 0.00 | 1.48 | 0.00 | 7.23 | 11.46 | 301.25 | -85.07 | 79.02 | 0.9951 | 411.0 | 349.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
