SDO HMI 2011-10-18 15:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 47.75 | 107.22 | 26.10 | 58.66 | -14.58 | 2.58 | -14.97 | 143.95 | 0.4265 | -22.2 | -199.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-18 15:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 10.20 | 11.51 | 5.51 | 6.22 | -14.96 | 5.79 | -11.77 | 150.60 | 0.4030 | 964.8 | 535.9 | |
| 0.00 | 0.96 | 0.00 | 0.53 | -17.05 | 5.66 | -11.89 | 152.81 | 0.4330 | 640.0 | 523.2 | |
| 6.01 | 6.71 | 3.26 | 3.64 | -15.01 | 5.12 | -12.43 | 149.29 | 0.4090 | 1006.1 | 816.2 | |
| 0.00 | 1.05 | 0.00 | 0.57 | -15.43 | 4.90 | -12.65 | 149.40 | 0.4165 | 676.0 | 571.4 | |
| 1.74 | 2.96 | 0.95 | 1.61 | -14.92 | 4.81 | -12.74 | 148.55 | 0.4104 | 900.0 | 732.5 | |
| 0.00 | 7.15 | 0.00 | 3.89 | -15.21 | 4.73 | -12.83 | 148.77 | 0.4149 | 745.0 | 691.9 | |
| 1.74 | 1.92 | 0.94 | 1.04 | -14.64 | 4.76 | -12.79 | 148.08 | 0.4069 | 916.2 | 932.0 | |
| 0.00 | 2.79 | 0.00 | 1.53 | -16.41 | 4.01 | -13.54 | 148.91 | 0.4369 | 842.0 | 676.5 | |
| 0.00 | 1.13 | 0.00 | 0.61 | -13.58 | 3.97 | -13.58 | 145.02 | 0.3998 | -650.0 | -492.2 | |
| 2.35 | 2.79 | 1.28 | 1.52 | -14.75 | 3.87 | -13.69 | 146.48 | 0.4161 | 792.9 | 519.6 | |
| 0.00 | 0.96 | 0.00 | 0.52 | -15.11 | 3.52 | -14.03 | 146.32 | 0.4238 | 779.0 | 682.5 | |
| 0.00 | 5.49 | 0.00 | 3.01 | -14.51 | 2.00 | -15.55 | 142.71 | 0.4302 | -692.0 | -585.6 | |
| 0.00 | 0.96 | 0.00 | 0.52 | -14.07 | 1.90 | -15.65 | 141.89 | 0.4257 | -738.0 | -684.5 | |
| 0.00 | 1.92 | 0.00 | 1.06 | -16.19 | 1.65 | -15.91 | 144.42 | 0.4543 | -787.0 | -668.8 | |
| 0.00 | 6.19 | 0.00 | 3.38 | -13.79 | 1.73 | -15.82 | 141.16 | 0.4239 | -1052.0 | -863.3 | |
| 0.00 | 1.22 | 0.00 | 0.67 | -14.43 | 1.53 | -16.03 | 141.76 | 0.4338 | -644.0 | -537.2 | |
| 0.00 | 2.70 | 0.00 | 1.47 | -13.01 | 1.47 | -16.09 | 139.47 | 0.4172 | -777.0 | -618.1 | |
| 6.62 | 8.28 | 3.63 | 4.54 | -14.09 | 1.36 | -16.19 | 140.96 | 0.4312 | -951.8 | -750.7 | |
| 3.75 | 6.36 | 2.09 | 3.54 | -15.95 | 1.02 | -16.53 | 143.05 | 0.4571 | 924.3 | 759.5 | |
| 0.00 | 4.71 | 0.00 | 2.58 | -13.50 | 1.02 | -16.54 | 139.46 | 0.4276 | -859.0 | -701.3 | |
| 15.34 | 29.46 | 8.44 | 16.21 | -14.10 | 0.84 | -16.71 | 140.10 | 0.4366 | -966.4 | -495.5 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
