SDO HMI 2011-10-19 11:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 60.32 | 406.68 | 47.68 | 320.99 | 27.61 | 55.14 | 48.58 | 301.35 | 0.7801 | -876.0 | -221.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-19 11:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 60.32 | 396.32 | 47.68 | 313.61 | 27.59 | 55.30 | 48.74 | 301.26 | 0.7816 | -1061.1 | -231.8 | |
| 0.00 | 1.39 | 0.00 | 1.13 | 30.66 | 55.54 | 48.98 | 304.91 | 0.7937 | 402.0 | 430.5 | |
| 0.00 | 0.52 | 0.00 | 0.39 | 26.83 | 52.48 | 45.92 | 301.26 | 0.7523 | -561.0 | -476.8 | |
| 0.00 | 2.09 | 0.00 | 1.62 | 31.12 | 52.69 | 46.13 | 306.52 | 0.7703 | -668.0 | -566.3 | |
| 0.00 | 1.13 | 0.00 | 0.76 | 27.59 | 44.93 | 38.37 | 305.59 | 0.6788 | 470.0 | 310.2 | |
| 0.00 | 0.96 | 0.00 | 0.65 | 28.32 | 45.20 | 38.63 | 306.44 | 0.6855 | 423.0 | 350.3 | |
| 0.00 | 1.05 | 0.00 | 0.70 | 27.46 | 44.79 | 38.23 | 305.50 | 0.6768 | 528.0 | 398.3 | |
| 0.00 | 2.09 | 0.00 | 1.39 | 26.96 | 44.46 | 37.90 | 305.00 | 0.6706 | 518.0 | 484.0 | |
| 0.00 | 1.13 | 0.00 | 0.74 | 25.05 | 43.49 | 36.93 | 302.85 | 0.6502 | 705.0 | 561.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
