SDO HMI 2011-10-19 16:02:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 159.25 | 736.71 | 118.70 | 556.77 | 9.43 | 53.37 | 49.03 | 277.86 | 0.7529 | -86.5 | -109.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-19 16:02:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.96 | 0.00 | 0.79 | 6.71 | 57.66 | 53.32 | 274.23 | 0.8009 | -268.0 | -257.7 | |
| 0.00 | 1.57 | 0.00 | 1.26 | 5.29 | 56.61 | 52.27 | 272.39 | 0.7905 | 486.0 | 467.3 | |
| 3.31 | 403.84 | 2.68 | 322.71 | 8.11 | 56.99 | 52.66 | 275.98 | 0.7936 | -235.0 | -220.1 | |
| 9.41 | -3.00 | 7.56 | -3.00 | 7.42 | 56.62 | 52.29 | 275.09 | 0.7898 | -728.1 | 999999 | |
| 2.18 | -3.00 | 1.74 | -3.00 | 7.44 | 56.33 | 51.99 | 275.11 | 0.7867 | -789.0 | 999999 | |
| 50.96 | -3.00 | 40.55 | -3.00 | 8.20 | 56.17 | 51.83 | 276.08 | 0.7849 | -938.5 | 999999 | |
| 1.66 | -3.00 | 1.30 | -3.00 | 9.04 | 55.50 | 51.16 | 277.15 | 0.7776 | -394.1 | 999999 | |
| 10.89 | -3.00 | 8.49 | -3.00 | 9.03 | 55.21 | 50.87 | 277.14 | 0.7744 | -935.4 | 999999 | |
| 0.00 | 6.27 | 0.00 | 4.90 | 10.28 | 55.33 | 50.99 | 278.76 | 0.7759 | -100.0 | -135.6 | |
| 0.00 | 1.13 | 0.00 | 0.88 | 9.69 | 55.15 | 50.81 | 278.00 | 0.7738 | -94.0 | -142.5 | |
| 0.00 | 1.05 | 0.00 | 0.81 | 7.09 | 54.63 | 50.30 | 274.61 | 0.7683 | -714.0 | -590.2 | |
| 0.00 | 0.96 | 0.00 | 0.74 | 7.78 | 54.60 | 50.26 | 275.51 | 0.7678 | -675.0 | -579.9 | |
| 0.00 | 3.05 | 0.00 | 2.38 | 10.93 | 55.19 | 50.85 | 279.60 | 0.7745 | -82.0 | -179.3 | |
| 0.00 | 0.70 | 0.00 | 0.54 | 10.10 | 55.00 | 50.66 | 278.53 | 0.7722 | -479.0 | -384.4 | |
| 0.00 | 3.40 | 0.00 | 2.62 | 8.85 | 54.69 | 50.36 | 276.92 | 0.7688 | -784.0 | -690.6 | |
| 2.26 | 21.86 | 1.74 | 16.76 | 9.25 | 54.63 | 50.29 | 277.43 | 0.7681 | -830.2 | -751.6 | |
| 0.00 | 1.39 | 0.00 | 1.07 | 7.17 | 54.27 | 49.93 | 274.71 | 0.7642 | -766.0 | -650.4 | |
| 0.00 | 0.96 | 0.00 | 0.74 | 9.70 | 54.72 | 50.38 | 278.01 | 0.7691 | -453.0 | -500.1 | |
| 0.00 | 3.92 | 0.00 | 3.02 | 9.97 | 54.68 | 50.35 | 278.37 | 0.7687 | -618.0 | -605.9 | |
| 0.00 | 1.57 | 0.00 | 1.20 | 7.80 | 54.27 | 49.94 | 275.54 | 0.7641 | -651.0 | -613.9 | |
| 2.70 | -16.00 | 2.08 | -16.00 | 9.53 | 54.54 | 50.21 | 277.80 | 0.7671 | -858.2 | 999999 | |
| 1.31 | 6.27 | 1.01 | 4.83 | 10.48 | 54.70 | 50.36 | 279.04 | 0.7691 | -635.7 | -715.6 | |
| 0.00 | 2.44 | 0.00 | 1.86 | 9.74 | 54.11 | 49.78 | 278.09 | 0.7624 | -704.0 | -669.4 | |
| 0.00 | 2.00 | 0.00 | 1.51 | 9.72 | 53.54 | 49.21 | 278.07 | 0.7560 | -805.0 | -692.5 | |
| 0.00 | 1.13 | 0.00 | 0.85 | 8.44 | 53.31 | 48.97 | 276.38 | 0.7532 | -710.0 | -531.8 | |
| 0.00 | 0.70 | 0.00 | 0.52 | 9.22 | 53.45 | 49.11 | 277.41 | 0.7548 | -539.0 | -571.4 | |
| 8.62 | 11.76 | 6.57 | 8.96 | 12.38 | 53.97 | 49.63 | 281.56 | 0.7619 | 616.5 | 433.4 | |
| 0.00 | 1.83 | 0.00 | 1.37 | 9.38 | 53.20 | 48.87 | 277.63 | 0.7520 | -869.0 | -757.0 | |
| 0.00 | 0.61 | 0.00 | 0.45 | 8.11 | 52.93 | 48.59 | 275.93 | 0.7489 | -513.0 | -593.7 | |
| 0.00 | 2.35 | 0.00 | 1.76 | 10.46 | 53.28 | 48.94 | 279.07 | 0.7532 | -845.0 | -709.8 | |
| 0.00 | 1.39 | 0.00 | 1.04 | 10.54 | 53.02 | 48.68 | 279.19 | 0.7503 | -691.0 | -716.0 | |
| 0.00 | 0.96 | 0.00 | 0.71 | 10.16 | 52.48 | 48.14 | 278.69 | 0.7440 | -742.0 | -640.9 | |
| 0.00 | 0.96 | 0.00 | 0.71 | 10.41 | 52.35 | 48.01 | 279.04 | 0.7426 | -841.0 | -693.2 | |
| 0.00 | 2.18 | 0.00 | 1.61 | 10.65 | 52.35 | 48.02 | 279.36 | 0.7427 | -810.0 | -638.5 | |
| 0.00 | 1.22 | 0.00 | 0.88 | 9.07 | 51.28 | 46.95 | 277.25 | 0.7298 | 187.0 | 203.2 | |
| 0.00 | 0.96 | 0.00 | 0.69 | 10.00 | 51.28 | 46.94 | 278.53 | 0.7299 | -355.0 | -285.5 | |
| 0.00 | 3.22 | 0.00 | 2.33 | 10.24 | 51.28 | 46.94 | 278.86 | 0.7300 | -367.0 | -345.0 | |
| 0.00 | 2.18 | 0.00 | 1.57 | 10.32 | 51.02 | 46.69 | 278.98 | 0.7271 | 464.0 | 365.0 | |
| 0.00 | 1.39 | 0.00 | 1.00 | 10.14 | 50.99 | 46.66 | 278.74 | 0.7266 | 478.0 | 347.1 | |
| 0.00 | 1.13 | 0.00 | 0.81 | 10.93 | 50.44 | 46.10 | 279.87 | 0.7205 | 529.0 | 372.5 | |
| 0.00 | 2.18 | 0.00 | 1.53 | 8.65 | 49.94 | 45.61 | 276.69 | 0.7136 | 531.0 | 356.0 | |
| 0.00 | 1.31 | 0.00 | 0.92 | 10.87 | 50.12 | 45.78 | 279.79 | 0.7166 | -550.0 | -422.6 | |
| 0.61 | 1.92 | 0.43 | 1.34 | 8.67 | 49.69 | 45.35 | 276.72 | 0.7105 | 715.6 | 553.9 | |
| 0.00 | 1.22 | 0.00 | 0.86 | 8.43 | 49.65 | 45.31 | 276.39 | 0.7100 | 482.0 | 433.9 | |
| 0.00 | 1.05 | 0.00 | 0.73 | 11.19 | 48.97 | 44.63 | 280.33 | 0.7029 | 338.0 | 303.3 | |
| 16.20 | 33.71 | 11.19 | 23.37 | 10.69 | 48.70 | 44.37 | 279.65 | 0.6993 | 680.8 | -111.1 | |
| 0.00 | 1.66 | 0.00 | 1.14 | 11.16 | 48.41 | 44.07 | 280.35 | 0.6960 | 726.0 | 580.7 | |
| 11.85 | 32.58 | 8.10 | 22.27 | 10.22 | 48.07 | 43.73 | 279.01 | 0.6911 | 888.3 | 393.8 | |
| 1.05 | -48.00 | 0.71 | -48.00 | 10.64 | 48.10 | 43.76 | 279.62 | 0.6918 | 791.1 | 999999 | |
| 0.00 | 1.57 | 0.00 | 1.06 | 7.03 | 47.27 | 42.94 | 274.36 | 0.6804 | 759.0 | 585.2 | |
| 1.39 | 128.92 | 0.96 | 87.45 | 12.51 | 48.09 | 43.75 | 282.33 | 0.6934 | -201.7 | 273.7 | |
| 0.00 | 0.96 | 0.00 | 0.65 | 10.06 | 47.33 | 42.99 | 278.83 | 0.6818 | 628.0 | 493.9 | |
| 1.66 | -51.00 | 1.13 | -51.00 | 12.87 | 47.70 | 43.36 | 282.90 | 0.6890 | 628.4 | 999999 | |
| 0.00 | 1.74 | 0.00 | 1.19 | 13.27 | 47.70 | 43.36 | 283.47 | 0.6895 | 473.0 | 302.0 | |
| 0.00 | 2.70 | 0.00 | 1.84 | 13.54 | 47.63 | 43.30 | 283.88 | 0.6891 | 519.0 | 488.3 | |
| 33.19 | -51.00 | 22.46 | -51.00 | 12.26 | 47.32 | 42.98 | 282.06 | 0.6836 | 952.9 | 999999 | |
| 0.00 | 1.48 | 0.00 | 0.99 | 10.55 | 46.62 | 42.29 | 279.62 | 0.6732 | 706.0 | 656.9 | |
| 0.00 | 3.48 | 0.00 | 2.33 | 11.37 | 46.68 | 42.35 | 280.81 | 0.6747 | 573.0 | 569.8 | |
| 0.00 | 1.31 | 0.00 | 0.87 | 10.95 | 46.61 | 42.27 | 280.20 | 0.6734 | 739.0 | 526.5 | |
| 0.00 | 0.96 | 0.00 | 0.64 | 11.11 | 46.39 | 42.06 | 280.47 | 0.6708 | 827.0 | 744.1 | |
| 0.00 | 2.53 | 0.00 | 1.68 | 11.65 | 46.41 | 42.07 | 281.27 | 0.6715 | 793.0 | 669.1 | |
| 0.00 | 1.74 | 0.00 | 1.16 | 11.45 | 46.29 | 41.95 | 280.98 | 0.6698 | 749.0 | 690.0 | |
| 0.00 | 2.96 | 0.00 | 2.06 | 18.45 | 47.99 | 43.65 | 290.80 | 0.7028 | 675.0 | 501.4 | |
| 0.00 | 1.22 | 0.00 | 0.81 | 12.03 | 46.19 | 41.86 | 281.86 | 0.6692 | 671.0 | 604.3 | |
| 0.00 | 2.79 | 0.00 | 1.85 | 11.68 | 46.08 | 41.75 | 281.34 | 0.6674 | 848.0 | 768.2 | |
| 0.00 | 2.44 | 0.00 | 1.61 | 11.60 | 45.82 | 41.49 | 281.27 | 0.6640 | 771.0 | 670.8 | |
| 0.00 | 1.48 | 0.00 | 0.98 | 12.29 | 45.95 | 41.62 | 282.28 | 0.6665 | 725.0 | 554.9 | |
| 0.00 | 2.96 | 0.00 | 1.95 | 11.85 | 45.63 | 41.29 | 281.67 | 0.6618 | 823.0 | 673.3 | |
| 0.00 | 1.66 | 0.00 | 1.06 | 9.53 | 43.73 | 39.40 | 278.29 | 0.6348 | 745.0 | 480.7 | |
| 0.00 | 0.87 | 0.00 | 0.55 | 9.25 | 42.45 | 38.11 | 277.94 | 0.6174 | -640.0 | -489.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
