SDO HMI 2011-10-20 02:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.41 | 26.92 | 5.84 | 16.79 | 19.23 | 322.56 | -35.74 | 65.29 | 0.6100 | 740.6 | 601.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-20 02:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.48 | 0.00 | 0.95 | 23.94 | 321.78 | -36.52 | 58.50 | 0.6401 | 451.0 | 311.7 | |
| 7.32 | 19.96 | 4.54 | 12.38 | 19.34 | 323.03 | -35.27 | 64.88 | 0.6040 | 930.2 | 678.1 | |
| 2.09 | -2.00 | 1.30 | -2.00 | 19.17 | 322.76 | -35.54 | 65.27 | 0.6067 | 786.1 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.49 | 18.48 | 322.66 | -35.64 | 66.40 | 0.6053 | 619.0 | 524.1 | |
| 0.00 | 0.78 | 0.00 | 0.49 | 19.85 | 322.19 | -36.10 | 64.45 | 0.6166 | 591.0 | 529.6 | |
| 0.00 | 0.44 | 0.00 | 0.27 | 19.44 | 322.03 | -36.27 | 65.17 | 0.6170 | 539.0 | 584.4 | |
| 0.00 | 0.35 | 0.00 | 0.22 | 16.14 | 321.41 | -36.89 | 70.62 | 0.6136 | 610.0 | 530.5 | |
| 0.00 | 1.39 | 0.00 | 0.91 | 21.74 | 319.83 | -38.47 | 62.65 | 0.6528 | 688.0 | 541.6 | |
| 0.00 | 1.74 | 0.00 | 1.08 | 12.80 | 321.40 | -36.90 | 76.04 | 0.6056 | 766.0 | 530.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
