SDO HMI 2011-10-20 03:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 211.46 | 773.58 | 173.62 | 624.83 | 11.47 | 305.36 | -52.39 | 79.76 | 0.7892 | -25.4 | 41.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-20 03:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 5.49 | 0.00 | 3.90 | 10.41 | 311.72 | -46.03 | 80.83 | 0.7194 | -637.0 | -697.5 | |
| 16.56 | 71.30 | 12.04 | 51.68 | 11.81 | 310.53 | -47.21 | 78.98 | 0.7342 | -876.7 | -445.7 | |
| 0.00 | 1.57 | 0.00 | 1.15 | 10.91 | 310.19 | -47.56 | 80.23 | 0.7376 | -784.0 | -716.6 | |
| 0.00 | 1.22 | 0.00 | 0.90 | 11.34 | 309.91 | -47.84 | 79.66 | 0.7411 | -707.0 | -599.4 | |
| 0.00 | 2.62 | 0.00 | 1.92 | 10.74 | 309.95 | -47.80 | 80.48 | 0.7403 | -732.0 | -667.1 | |
| 25.54 | 127.79 | 18.69 | 93.36 | 9.27 | 310.06 | -47.69 | 82.46 | 0.7386 | -1019.8 | -399.6 | |
| 2.96 | 14.99 | 2.19 | 11.10 | 11.20 | 309.67 | -48.08 | 79.87 | 0.7438 | -753.4 | -501.1 | |
| 0.00 | 0.52 | 0.00 | 0.39 | 11.16 | 309.04 | -48.71 | 79.96 | 0.7510 | -404.0 | -307.2 | |
| 9.76 | 89.61 | 7.27 | 67.62 | 10.32 | 309.13 | -48.62 | 81.08 | 0.7496 | -908.4 | -54.9 | |
| 1.83 | -9.00 | 1.37 | -9.00 | 10.21 | 308.87 | -48.88 | 81.24 | 0.7525 | -720.2 | 999999 | |
| 0.00 | 1.22 | 0.00 | 0.92 | 11.66 | 308.50 | -49.25 | 79.32 | 0.7573 | -528.0 | -455.4 | |
| 0.00 | 0.96 | 0.00 | 0.72 | 9.46 | 308.93 | -48.82 | 82.23 | 0.7516 | -498.0 | -453.3 | |
| 0.00 | 0.78 | 0.00 | 0.60 | 13.30 | 308.03 | -49.72 | 77.21 | 0.7637 | -451.0 | -435.8 | |
| 13.69 | -9.00 | 10.30 | -9.00 | 10.53 | 308.66 | -49.09 | 80.82 | 0.7549 | -576.7 | 999999 | |
| 4.27 | 15.86 | 3.26 | 12.06 | 12.09 | 308.06 | -49.69 | 78.80 | 0.7624 | -646.8 | 56.4 | |
| 4.36 | 18.92 | 3.31 | 14.42 | 11.37 | 308.24 | -49.51 | 79.73 | 0.7601 | -533.6 | 109.2 | |
| 2.96 | -9.00 | 2.24 | -9.00 | 9.94 | 308.51 | -49.24 | 81.60 | 0.7565 | -376.8 | 999999 | |
| 0.00 | 2.00 | 0.00 | 1.54 | 11.90 | 307.59 | -50.16 | 79.07 | 0.7676 | -504.0 | -389.6 | |
| 2.27 | 3.14 | 1.76 | 2.43 | 12.12 | 307.24 | -50.51 | 78.81 | 0.7714 | -614.7 | -539.2 | |
| 0.00 | 1.74 | 0.00 | 1.35 | 10.95 | 307.39 | -50.36 | 80.32 | 0.7693 | 285.0 | 199.4 | |
| 2.00 | 2.70 | 1.56 | 2.11 | 12.25 | 306.96 | -50.79 | 78.66 | 0.7745 | -371.1 | -317.8 | |
| 0.00 | 1.05 | 0.00 | 0.80 | 8.58 | 307.55 | -50.20 | 83.42 | 0.7671 | -584.0 | -508.2 | |
| 5.23 | 32.08 | 4.10 | 25.20 | 11.38 | 306.65 | -51.10 | 79.80 | 0.7774 | 725.9 | 389.7 | |
| 11.16 | -23.00 | 8.77 | -23.00 | 11.73 | 306.52 | -51.23 | 79.35 | 0.7791 | 653.0 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.62 | 12.36 | 306.05 | -51.70 | 78.57 | 0.7844 | -336.0 | -265.3 | |
| 0.00 | 5.49 | 0.00 | 4.35 | 11.28 | 306.19 | -51.56 | 79.94 | 0.7824 | 635.0 | 566.7 | |
| 0.00 | 0.52 | 0.00 | 0.41 | 10.78 | 306.31 | -51.44 | 80.59 | 0.7809 | -326.0 | -276.7 | |
| 1.92 | 3.23 | 1.53 | 2.58 | 11.49 | 305.74 | -52.01 | 79.70 | 0.7873 | 575.2 | 509.7 | |
| 0.00 | 1.22 | 0.00 | 1.05 | 18.56 | 303.07 | -54.68 | 71.15 | 0.8196 | -302.0 | -308.2 | |
| 0.00 | 0.96 | 0.00 | 0.77 | 11.22 | 305.71 | -52.04 | 80.05 | 0.7875 | 479.0 | 320.1 | |
| 0.00 | 2.70 | 0.00 | 2.16 | 10.58 | 305.62 | -52.13 | 80.87 | 0.7882 | -548.0 | -318.1 | |
| 4.62 | 5.75 | 3.79 | 4.71 | 13.42 | 304.72 | -53.02 | 77.32 | 0.7988 | -607.0 | -415.8 | |
| 0.00 | 0.87 | 0.00 | 0.70 | 10.53 | 305.38 | -52.37 | 80.93 | 0.7907 | 79.0 | 91.7 | |
| 4.01 | 11.24 | 3.32 | 9.32 | 13.45 | 304.30 | -53.45 | 77.31 | 0.8031 | -497.4 | -106.1 | |
| 0.00 | 0.61 | 0.00 | 0.50 | 11.04 | 304.95 | -52.80 | 80.30 | 0.7954 | -453.0 | -366.7 | |
| 1.31 | 169.71 | 1.07 | 143.19 | 11.27 | 304.84 | -52.91 | 80.01 | 0.7966 | -620.1 | 404.0 | |
| 0.00 | 1.48 | 0.00 | 1.22 | 12.49 | 304.45 | -53.30 | 78.50 | 0.8011 | -297.0 | -178.8 | |
| 6.54 | -36.00 | 5.35 | -36.00 | 11.47 | 304.69 | -53.06 | 79.76 | 0.7983 | -666.7 | 999999 | |
| 0.00 | 2.62 | 0.00 | 2.17 | 12.68 | 304.23 | -53.52 | 78.27 | 0.8034 | -224.0 | -117.3 | |
| 3.66 | -36.00 | 3.03 | -36.00 | 11.58 | 304.14 | -53.61 | 79.65 | 0.8039 | 586.5 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.66 | 13.93 | 303.35 | -54.40 | 76.79 | 0.8128 | -479.0 | -415.9 | |
| 0.00 | 0.96 | 0.00 | 0.82 | 14.33 | 303.00 | -54.75 | 76.32 | 0.8166 | -261.0 | -221.1 | |
| 0.00 | 1.57 | 0.00 | 1.30 | 10.64 | 304.08 | -53.67 | 80.82 | 0.8042 | 693.0 | 606.6 | |
| 3.31 | -36.00 | 2.80 | -36.00 | 11.91 | 303.26 | -54.49 | 79.27 | 0.8128 | 763.3 | 999999 | |
| 6.54 | -36.00 | 5.55 | -36.00 | 12.14 | 303.14 | -54.61 | 78.99 | 0.8141 | 608.4 | 999999 | |
| 0.35 | 4.18 | 0.29 | 3.52 | 11.42 | 303.25 | -54.50 | 79.87 | 0.8129 | 640.8 | 699.5 | |
| 3.14 | 32.43 | 2.70 | 28.05 | 13.32 | 302.60 | -55.15 | 77.58 | 0.8199 | -474.4 | 256.4 | |
| 1.74 | -36.00 | 1.49 | -36.00 | 11.61 | 302.87 | -54.88 | 79.66 | 0.8166 | -368.8 | 999999 | |
| 1.31 | -47.00 | 1.13 | -47.00 | 13.15 | 302.39 | -55.36 | 77.79 | 0.8219 | -219.4 | 999999 | |
| 0.00 | 1.48 | 0.00 | 1.29 | 12.62 | 302.18 | -55.57 | 78.45 | 0.8237 | 636.0 | 604.5 | |
| 5.84 | -36.00 | 5.05 | -36.00 | 11.99 | 302.33 | -55.42 | 79.21 | 0.8221 | 757.6 | 999999 | |
| 0.00 | 0.87 | 0.00 | 0.77 | 13.37 | 301.65 | -56.10 | 77.57 | 0.8291 | 141.0 | 196.2 | |
| 7.06 | -36.00 | 6.14 | -36.00 | 11.76 | 302.07 | -55.68 | 79.50 | 0.8245 | 695.2 | 999999 | |
| 0.00 | 1.22 | 0.00 | 1.08 | 12.91 | 301.59 | -56.16 | 78.13 | 0.8295 | 431.0 | 422.9 | |
| 2.70 | -36.00 | 2.37 | -36.00 | 11.64 | 301.73 | -56.02 | 79.65 | 0.8278 | 518.7 | 999999 | |
| 0.00 | 1.83 | 0.00 | 1.67 | 14.51 | 300.31 | -57.44 | 76.26 | 0.8421 | 620.0 | 603.7 | |
| 2.00 | 21.53 | 1.83 | 19.69 | 14.21 | 300.32 | -57.43 | 76.63 | 0.8419 | 692.9 | 656.9 | |
| 9.07 | -57.00 | 8.27 | -57.00 | 13.44 | 300.27 | -57.48 | 77.54 | 0.8420 | 730.0 | 999999 | |
| 3.57 | 6.10 | 3.24 | 5.53 | 11.90 | 300.47 | -57.28 | 79.37 | 0.8397 | 716.3 | 608.7 | |
| 0.00 | 1.92 | 0.00 | 1.73 | 10.59 | 300.71 | -57.04 | 80.94 | 0.8374 | -436.0 | -248.2 | |
| 0.00 | 1.31 | 0.00 | 1.20 | 12.39 | 300.08 | -57.67 | 78.80 | 0.8435 | 645.0 | 526.1 | |
| 0.00 | 1.39 | 0.00 | 1.26 | 10.37 | 300.60 | -57.15 | 81.20 | 0.8383 | -233.0 | -212.3 | |
| 0.00 | 1.05 | 0.00 | 0.99 | 14.62 | 298.97 | -58.78 | 76.21 | 0.8541 | 435.0 | 387.9 | |
| 9.07 | 13.08 | 8.34 | 12.04 | 11.92 | 299.95 | -57.80 | 79.36 | 0.8446 | 661.4 | 506.9 | |
| 2.35 | 4.88 | 2.15 | 4.47 | 11.45 | 300.10 | -57.65 | 79.92 | 0.8431 | 617.2 | 660.1 | |
| 0.00 | 1.83 | 0.00 | 1.73 | 13.92 | 299.03 | -58.72 | 77.03 | 0.8534 | 587.0 | 504.2 | |
| 0.00 | 1.31 | 0.00 | 1.22 | 12.29 | 299.53 | -58.22 | 78.94 | 0.8484 | 484.0 | 399.1 | |
| 0.00 | 1.13 | 0.00 | 1.04 | 11.01 | 299.95 | -57.80 | 80.44 | 0.8444 | 598.0 | 563.9 | |
| 0.00 | 0.61 | 0.00 | 0.56 | 10.81 | 299.73 | -58.02 | 80.68 | 0.8465 | 216.0 | 233.0 | |
| 0.00 | 2.27 | 0.00 | 2.11 | 11.58 | 299.42 | -58.33 | 79.78 | 0.8493 | 382.0 | 308.8 | |
| 0.00 | 1.13 | 0.00 | 1.09 | 14.00 | 298.45 | -59.30 | 76.96 | 0.8584 | 125.0 | 176.0 | |
| 21.44 | 42.80 | 20.32 | 40.66 | 12.72 | 298.84 | -58.91 | 78.45 | 0.8547 | 577.1 | 127.6 | |
| 0.00 | 1.48 | 0.00 | 1.39 | 10.62 | 299.26 | -58.49 | 80.90 | 0.8507 | 554.0 | 444.2 | |
| 4.36 | 7.67 | 4.13 | 7.27 | 11.71 | 298.79 | -58.96 | 79.63 | 0.8550 | 266.6 | 259.1 | |
| 0.78 | -74.00 | 0.74 | -74.00 | 11.53 | 298.85 | -58.90 | 79.84 | 0.8544 | -174.6 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.77 | 14.29 | 297.58 | -60.17 | 76.65 | 0.8660 | 486.0 | 389.1 | |
| 0.70 | 3.66 | 0.68 | 3.56 | 12.18 | 297.89 | -59.86 | 79.09 | 0.8629 | 320.6 | 241.4 | |
| 1.48 | 8.89 | 1.45 | 8.73 | 11.69 | 297.77 | -59.98 | 79.67 | 0.8639 | 383.4 | -105.9 | |
| 0.00 | 0.70 | 0.00 | 0.71 | 13.84 | 296.19 | -61.56 | 77.21 | 0.8774 | 208.0 | 196.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
