SDO HMI 2011-10-21 00:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 12.89 | 38.94 | 15.26 | 46.52 | -12.11 | 49.71 | 63.50 | 254.01 | 0.9108 | -82.1 | -153.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-21 00:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 4.79 | 10.63 | 6.49 | 14.43 | -12.04 | 52.89 | 66.68 | 254.78 | 0.9323 | 380.2 | 115.2 | |
| 0.00 | 4.01 | 0.00 | 5.46 | -12.38 | 52.90 | 66.70 | 254.42 | 0.9329 | 119.0 | 19.7 | |
| 0.00 | 0.96 | 0.00 | 1.20 | -9.29 | 51.41 | 65.20 | 257.41 | 0.9196 | 396.0 | 377.4 | |
| 0.00 | 0.70 | 0.00 | 0.92 | -12.29 | 52.16 | 65.96 | 254.37 | 0.9282 | 396.0 | 369.9 | |
| 0.00 | 1.65 | 0.00 | 1.87 | -12.08 | 48.07 | 61.86 | 253.70 | 0.9002 | -451.0 | -353.8 | |
| 0.00 | 1.05 | 0.00 | 1.15 | -12.63 | 47.20 | 60.99 | 252.90 | 0.8947 | -266.0 | -162.8 | |
| 8.10 | 19.07 | 8.77 | 20.56 | -12.23 | 46.85 | 60.64 | 253.25 | 0.8914 | -452.1 | -453.0 | |
| 0.00 | 0.87 | 0.00 | 0.93 | -11.63 | 46.44 | 60.23 | 253.80 | 0.8872 | -442.0 | -441.9 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
