SDO HMI 2011-10-21 03:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 97.05 | 309.55 | 54.33 | 174.26 | -21.04 | 334.42 | -10.14 | 159.81 | 0.4759 | 61.2 | -198.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-21 03:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 2.00 | 0.00 | 1.10 | -18.98 | 337.44 | -7.12 | 164.13 | 0.4307 | 808.0 | 610.1 | |
| 25.87 | 46.61 | 14.29 | 25.75 | -19.75 | 336.99 | -7.57 | 163.71 | 0.4442 | 1081.0 | 523.3 | |
| 4.70 | 24.39 | 2.62 | 13.59 | -20.41 | 336.60 | -7.96 | 163.39 | 0.4559 | 727.3 | 668.7 | |
| 4.97 | -3.00 | 2.77 | -3.00 | -20.85 | 336.51 | -8.05 | 163.50 | 0.4627 | 835.6 | 999999 | |
| 1.92 | -2.00 | 1.06 | -2.00 | -19.69 | 336.48 | -8.08 | 162.64 | 0.4456 | 801.9 | 999999 | |
| 0.00 | 0.61 | 0.00 | 0.34 | -20.28 | 336.25 | -8.31 | 162.62 | 0.4555 | 485.0 | 370.3 | |
| 0.00 | 1.05 | 0.00 | 0.58 | -19.52 | 336.26 | -8.30 | 162.09 | 0.4442 | 893.0 | 742.5 | |
| 6.27 | 8.10 | 3.45 | 4.46 | -19.16 | 336.25 | -8.31 | 161.80 | 0.4389 | 1113.9 | 829.7 | |
| 0.00 | 1.92 | 0.00 | 1.08 | -21.52 | 335.99 | -8.57 | 162.96 | 0.4749 | 288.0 | 321.6 | |
| 0.00 | 2.00 | 0.00 | 1.12 | -21.29 | 335.97 | -8.59 | 162.76 | 0.4716 | 839.0 | 541.0 | |
| 2.44 | 3.14 | 1.35 | 1.73 | -19.40 | 335.98 | -8.58 | 161.43 | 0.4437 | 874.8 | 729.6 | |
| 0.00 | 1.13 | 0.00 | 0.62 | -18.81 | 335.82 | -8.74 | 160.64 | 0.4358 | 766.0 | 587.6 | |
| 0.00 | 1.22 | 0.00 | 0.68 | -19.60 | 335.71 | -8.85 | 161.05 | 0.4480 | 666.0 | 529.1 | |
| 0.00 | 1.22 | 0.00 | 0.67 | -19.27 | 335.73 | -8.83 | 160.83 | 0.4431 | 854.0 | 701.4 | |
| 0.00 | 1.05 | 0.00 | 0.57 | -18.71 | 335.70 | -8.86 | 160.32 | 0.4350 | 680.0 | 534.8 | |
| 3.92 | 10.37 | 2.17 | 5.75 | -19.58 | 335.01 | -9.55 | 159.65 | 0.4514 | 940.5 | 638.0 | |
| 0.87 | 2.18 | 0.49 | 1.23 | -21.54 | 334.88 | -9.68 | 160.93 | 0.4805 | -702.3 | -507.4 | |
| 0.00 | 4.62 | 0.00 | 2.62 | -21.98 | 334.72 | -9.84 | 160.96 | 0.4876 | -951.0 | -671.8 | |
| 1.57 | 4.27 | 0.87 | 2.38 | -20.11 | 334.81 | -9.75 | 159.70 | 0.4602 | 854.4 | 795.9 | |
| 0.00 | 4.27 | 0.00 | 2.41 | -21.68 | 334.61 | -9.95 | 160.54 | 0.4838 | -956.0 | -893.9 | |
| 1.31 | -19.00 | 0.73 | -19.00 | -20.18 | 334.62 | -9.94 | 159.38 | 0.4622 | 592.4 | 999999 | |
| 2.09 | 184.95 | 1.19 | 105.09 | -21.82 | 334.05 | -10.51 | 159.64 | 0.4888 | -824.2 | -456.9 | |
| 0.00 | 3.14 | 0.00 | 1.76 | -20.85 | 334.12 | -10.44 | 159.00 | 0.4746 | -587.0 | -544.4 | |
| 0.00 | 1.31 | 0.00 | 0.73 | -20.59 | 333.78 | -10.78 | 158.17 | 0.4728 | -496.0 | -440.2 | |
| 0.96 | -22.00 | 0.54 | -22.00 | -21.80 | 333.52 | -11.04 | 158.70 | 0.4913 | -891.3 | 999999 | |
| 1.13 | -22.00 | 0.64 | -22.00 | -22.10 | 333.50 | -11.06 | 158.90 | 0.4957 | -774.1 | 999999 | |
| 2.09 | -22.00 | 1.19 | -22.00 | -22.24 | 333.33 | -11.23 | 158.71 | 0.4986 | -478.6 | 999999 | |
| 32.93 | -22.00 | 18.71 | -22.00 | -21.67 | 333.21 | -11.35 | 158.04 | 0.4913 | -1171.6 | 999999 | |
| 2.79 | -22.00 | 1.57 | -22.00 | -20.67 | 333.29 | -11.27 | 157.34 | 0.4768 | -1082.0 | 999999 | |
| 1.22 | -22.00 | 0.69 | -22.00 | -21.41 | 332.84 | -11.72 | 157.18 | 0.4898 | -976.1 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
