SDO HMI 2011-10-21 14:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 63.01 | 327.99 | 61.15 | 319.96 | 15.49 | 279.03 | -59.51 | 75.14 | 0.8602 | -239.7 | -18.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-21 14:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.22 | 0.00 | 0.96 | 17.50 | 287.72 | -50.82 | 71.81 | 0.7804 | -422.0 | -346.4 | |
| 0.00 | 0.96 | 0.00 | 0.76 | 14.10 | 287.33 | -51.21 | 76.21 | 0.7807 | -514.0 | -442.4 | |
| 14.53 | 248.63 | 13.34 | 233.47 | 15.67 | 280.97 | -57.56 | 74.81 | 0.8441 | -873.8 | -88.6 | |
| 5.40 | -3.00 | 5.03 | -3.00 | 16.03 | 280.40 | -58.14 | 74.44 | 0.8495 | -421.0 | 999999 | |
| 4.35 | -3.00 | 4.05 | -3.00 | 15.64 | 280.52 | -58.02 | 74.89 | 0.8482 | -576.1 | 999999 | |
| 9.49 | -3.00 | 8.88 | -3.00 | 15.22 | 280.23 | -58.30 | 75.40 | 0.8505 | -641.7 | 999999 | |
| 15.06 | -3.00 | 14.16 | -3.00 | 14.71 | 279.98 | -58.55 | 76.02 | 0.8525 | -616.6 | 999999 | |
| 0.00 | 1.39 | 0.00 | 1.38 | 17.69 | 278.26 | -60.27 | 72.67 | 0.8687 | 606.0 | 520.7 | |
| 0.00 | 1.04 | 0.00 | 1.04 | 17.61 | 278.05 | -60.49 | 72.78 | 0.8704 | 365.0 | 336.0 | |
| 2.00 | 27.41 | 1.98 | 27.27 | 16.73 | 278.28 | -60.26 | 73.77 | 0.8681 | -157.2 | 227.6 | |
| 3.57 | -10.00 | 3.56 | -10.00 | 16.96 | 278.09 | -60.45 | 73.52 | 0.8697 | 471.3 | 999999 | |
| 0.00 | 0.96 | 0.00 | 0.98 | 17.04 | 277.14 | -61.40 | 73.49 | 0.8775 | 662.0 | 536.5 | |
| 0.00 | 0.35 | 0.00 | 0.35 | 14.08 | 277.54 | -60.99 | 76.85 | 0.8731 | 516.0 | 504.5 | |
| 0.00 | 0.96 | 0.00 | 1.04 | 16.09 | 275.32 | -63.22 | 74.66 | 0.8914 | 487.0 | 433.2 | |
| 0.00 | 1.04 | 0.00 | 1.15 | 16.55 | 274.90 | -63.63 | 74.16 | 0.8946 | 448.0 | 429.7 | |
| 0.00 | 2.87 | 0.00 | 3.21 | 16.85 | 274.43 | -64.10 | 73.85 | 0.8982 | 506.0 | 393.3 | |
| 0.00 | 2.00 | 0.00 | 2.22 | 16.49 | 274.58 | -63.95 | 74.24 | 0.8970 | 567.0 | 508.0 | |
| 0.00 | 0.87 | 0.00 | 0.97 | 16.29 | 274.48 | -64.05 | 74.46 | 0.8977 | 491.0 | 467.0 | |
| 0.00 | 0.78 | 0.00 | 0.88 | 16.40 | 274.28 | -64.26 | 74.35 | 0.8992 | 321.0 | 380.8 | |
| 0.00 | 0.87 | 0.00 | 0.98 | 16.15 | 274.21 | -64.32 | 74.63 | 0.8996 | 359.0 | 351.9 | |
| 0.00 | 2.09 | 0.00 | 2.37 | 16.44 | 273.96 | -64.57 | 74.32 | 0.9015 | 305.0 | 238.3 | |
| 0.00 | 0.96 | 0.00 | 1.08 | 15.23 | 273.96 | -64.58 | 75.66 | 0.9013 | 339.0 | 344.3 | |
| 0.00 | 1.39 | 0.00 | 1.64 | 15.57 | 272.86 | -65.67 | 75.31 | 0.9092 | 472.0 | 447.9 | |
| 8.09 | 29.33 | 9.53 | 34.79 | 14.96 | 272.86 | -65.68 | 75.99 | 0.9091 | 533.4 | -30.0 | |
| 0.52 | 2.87 | 0.62 | 3.42 | 15.45 | 272.55 | -65.98 | 75.45 | 0.9113 | 143.8 | 147.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
