SDO HMI 2011-10-21 16:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 38.37 | 244.76 | 74.25 | 507.71 | 9.29 | 53.93 | 76.50 | 278.29 | 0.9691 | 51.7 | -26.7 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-21 16:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 2.18 | 144.17 | 5.64 | 350.83 | 7.75 | 57.06 | 79.63 | 276.87 | 0.9826 | 572.7 | 18.4 | |
| 0.00 | 1.31 | 0.00 | 3.11 | 6.73 | 55.89 | 78.46 | 275.76 | 0.9789 | -285.0 | -245.4 | |
| 5.74 | -1.00 | 13.78 | -1.00 | 8.47 | 56.12 | 78.69 | 277.54 | 0.9793 | 367.3 | 999999 | |
| 12.70 | -1.00 | 29.22 | -1.00 | 8.48 | 55.67 | 78.24 | 277.52 | 0.9777 | -505.7 | 999999 | |
| 0.44 | -1.00 | 0.95 | -1.00 | 8.81 | 55.02 | 77.59 | 277.82 | 0.9752 | -677.0 | 999999 | |
| 0.00 | 1.74 | 0.00 | 3.65 | 8.98 | 54.44 | 77.01 | 277.97 | 0.9729 | -445.0 | -349.5 | |
| 0.00 | 0.70 | 0.00 | 1.45 | 9.28 | 54.24 | 76.81 | 278.25 | 0.9720 | -552.0 | -506.8 | |
| 0.00 | 14.18 | 0.00 | 29.16 | 9.86 | 54.13 | 76.69 | 278.85 | 0.9714 | -660.0 | -514.2 | |
| 1.74 | 12.62 | 2.77 | 20.38 | 9.63 | 49.92 | 72.49 | 278.40 | 0.9518 | 154.1 | -284.5 | |
| 0.00 | 1.22 | 0.00 | 1.91 | 10.18 | 49.61 | 72.18 | 278.96 | 0.9500 | 117.0 | 71.9 | |
| 0.87 | 1.74 | 1.31 | 2.62 | 10.67 | 48.81 | 71.37 | 279.45 | 0.9455 | 221.6 | -10.6 | |
| 0.00 | 2.35 | 0.00 | 3.45 | 10.42 | 48.28 | 70.85 | 279.16 | 0.9426 | 302.0 | 337.2 | |
| 12.18 | 49.94 | 17.04 | 70.21 | 12.17 | 47.35 | 69.92 | 281.00 | 0.9368 | 564.7 | 54.5 | |
| 0.00 | 0.52 | 0.00 | 0.74 | 12.67 | 47.56 | 70.13 | 281.54 | 0.9380 | 309.0 | 286.8 | |
| 0.00 | 0.87 | 0.00 | 1.22 | 13.08 | 47.46 | 70.03 | 281.97 | 0.9374 | 412.0 | 322.4 | |
| 2.52 | 13.40 | 3.54 | 18.98 | 13.39 | 47.39 | 69.96 | 282.30 | 0.9369 | 521.1 | 54.0 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
