SDO HMI 2011-10-21 17:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 1.83 | 19.75 | 1.09 | 11.91 | -15.39 | 5.07 | 28.19 | 232.89 | 0.5731 | 188.9 | 288.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-21 17:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.57 | 0.00 | 0.96 | -14.86 | 7.42 | 30.54 | 235.83 | 0.5958 | 622.0 | 522.4 | |
| 0.70 | 4.96 | 0.42 | 3.02 | -14.82 | 6.52 | 29.64 | 235.11 | 0.5851 | 798.1 | 630.6 | |
| 0.00 | 3.39 | 0.00 | 2.07 | -15.81 | 6.00 | 29.12 | 233.21 | 0.5868 | 665.0 | 632.6 | |
| 0.00 | 1.22 | 0.00 | 0.73 | -15.19 | 4.88 | 28.00 | 233.06 | 0.5690 | 758.0 | 605.4 | |
| 0.00 | 1.13 | 0.00 | 0.68 | -15.21 | 4.67 | 27.79 | 232.83 | 0.5668 | 855.0 | 631.7 | |
| 0.00 | 1.65 | 0.00 | 0.99 | -15.36 | 4.41 | 27.53 | 232.36 | 0.5651 | 643.0 | 428.6 | |
| 0.00 | 1.83 | 0.00 | 1.10 | -16.78 | 4.17 | 27.29 | 230.09 | 0.5745 | -860.0 | -542.0 | |
| 1.13 | 1.48 | 0.67 | 0.88 | -16.19 | 3.00 | 26.12 | 229.72 | 0.5564 | -636.8 | -581.0 | |
| 0.00 | 1.65 | 0.00 | 0.97 | -14.87 | 1.97 | 25.08 | 230.52 | 0.5330 | -819.0 | -655.9 | |
| 0.00 | 0.87 | 0.00 | 0.51 | -15.21 | 1.87 | 24.99 | 229.91 | 0.5350 | -665.0 | -542.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
