SDO HMI 2011-10-21 23:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 201.84 | 865.32 | 115.20 | 492.14 | 12.10 | 304.90 | -28.67 | 74.69 | 0.4872 | -132.1 | -0.4 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-21 23:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.96 | 0.00 | 0.51 | 9.88 | 313.57 | -20.00 | 75.96 | 0.3488 | -781.0 | -619.7 | |
| 0.00 | 4.35 | 0.00 | 2.31 | 9.42 | 313.05 | -20.52 | 77.53 | 0.3557 | -817.0 | -715.2 | |
| 14.71 | 120.20 | 7.89 | 64.55 | 9.41 | 311.20 | -22.37 | 78.34 | 0.3850 | -1238.6 | -523.9 | |
| 0.00 | 1.04 | 0.00 | 0.56 | 11.08 | 311.01 | -22.56 | 74.18 | 0.3930 | -764.0 | -500.3 | |
| 1.57 | -3.00 | 0.84 | -3.00 | 9.25 | 310.88 | -22.69 | 78.87 | 0.3896 | -1007.2 | 999999 | |
| 0.00 | 1.39 | 0.00 | 0.77 | 18.71 | 309.52 | -24.04 | 58.29 | 0.4555 | -674.0 | -560.8 | |
| 13.58 | 64.76 | 7.36 | 35.06 | 11.81 | 310.28 | -23.28 | 72.81 | 0.4067 | -1133.5 | -409.9 | |
| 10.62 | -3.00 | 5.73 | -3.00 | 9.48 | 310.44 | -23.13 | 78.47 | 0.3971 | -948.8 | 999999 | |
| 0.00 | 1.31 | 0.00 | 0.73 | 18.33 | 309.34 | -24.23 | 59.21 | 0.4554 | -943.0 | -728.3 | |
| 10.44 | 26.55 | 5.66 | 14.37 | 11.11 | 310.08 | -23.49 | 74.60 | 0.4074 | -1055.9 | -726.2 | |
| 0.00 | 1.22 | 0.00 | 0.68 | 18.47 | 308.90 | -24.67 | 59.33 | 0.4621 | -579.0 | -489.1 | |
| 0.00 | 1.91 | 0.00 | 1.04 | 11.57 | 309.54 | -24.03 | 73.78 | 0.4172 | -675.0 | -538.2 | |
| 7.14 | 57.45 | 3.88 | 31.31 | 10.76 | 309.58 | -23.99 | 75.68 | 0.4140 | -1063.4 | -483.7 | |
| 2.09 | 7.57 | 1.14 | 4.12 | 11.33 | 309.53 | -24.04 | 74.35 | 0.4166 | -925.2 | -825.3 | |
| 3.22 | -13.00 | 1.75 | -13.00 | 10.75 | 309.28 | -24.29 | 75.84 | 0.4186 | -948.9 | 999999 | |
| 5.74 | 6.27 | 3.14 | 3.42 | 11.53 | 309.11 | -24.46 | 74.11 | 0.4236 | -807.9 | -800.5 | |
| 0.00 | 1.13 | 0.00 | 0.62 | 13.57 | 308.90 | -24.67 | 69.59 | 0.4347 | -684.0 | -585.5 | |
| 4.18 | -13.00 | 2.28 | -13.00 | 10.59 | 309.03 | -24.54 | 76.32 | 0.4220 | -795.9 | 999999 | |
| 0.00 | 1.04 | 0.00 | 0.57 | 10.88 | 308.83 | -24.73 | 75.72 | 0.4258 | -635.0 | -528.7 | |
| 2.00 | 2.61 | 1.10 | 1.43 | 11.72 | 308.72 | -24.85 | 73.85 | 0.4301 | -856.3 | -543.7 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 13.58 | 308.53 | -25.04 | 69.79 | 0.4403 | -602.0 | -499.9 | |
| 1.74 | -13.00 | 0.95 | -13.00 | 10.43 | 308.74 | -24.83 | 76.81 | 0.4260 | -668.3 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.06 | 13.51 | 308.33 | -25.24 | 70.06 | 0.4429 | -730.0 | -602.5 | |
| 0.00 | 2.79 | 0.00 | 1.53 | 11.89 | 308.47 | -25.10 | 73.58 | 0.4345 | -754.0 | -701.3 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 11.62 | 308.36 | -25.21 | 74.26 | 0.4352 | -915.0 | -702.3 | |
| 0.00 | 4.53 | 0.00 | 2.49 | 12.15 | 308.24 | -25.33 | 73.11 | 0.4389 | -1081.0 | -882.9 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 12.66 | 308.15 | -25.41 | 72.03 | 0.4421 | -761.0 | -614.0 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 12.51 | 308.17 | -25.40 | 72.35 | 0.4413 | -865.0 | -655.2 | |
| 0.00 | 1.91 | 0.00 | 1.05 | 11.40 | 308.25 | -25.32 | 74.79 | 0.4363 | -909.0 | -721.9 | |
| 0.00 | 1.13 | 0.00 | 0.62 | 11.88 | 308.17 | -25.40 | 73.76 | 0.4391 | -895.0 | -670.1 | |
| 3.48 | 6.79 | 1.92 | 3.75 | 12.29 | 307.92 | -25.65 | 72.96 | 0.4442 | -823.0 | -658.2 | |
| 0.00 | 1.22 | 0.00 | 0.67 | 8.58 | 308.15 | -25.42 | 81.29 | 0.4312 | -785.0 | -647.9 | |
| 0.00 | 1.04 | 0.00 | 0.57 | 8.87 | 307.96 | -25.61 | 80.66 | 0.4346 | -713.0 | -533.2 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 12.79 | 306.88 | -26.69 | 72.40 | 0.4614 | -637.0 | -566.6 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 11.14 | 307.02 | -26.55 | 75.88 | 0.4541 | -853.0 | -620.6 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 11.53 | 306.95 | -26.62 | 75.07 | 0.4563 | -465.0 | -285.5 | |
| 0.00 | 2.70 | 0.00 | 1.49 | 8.06 | 307.11 | -26.46 | 82.68 | 0.4466 | -735.0 | -542.3 | |
| 1.39 | 1.91 | 0.77 | 1.07 | 11.01 | 306.80 | -26.77 | 76.25 | 0.4571 | -780.2 | -564.7 | |
| 0.00 | 2.44 | 0.00 | 1.36 | 12.02 | 306.45 | -27.12 | 74.23 | 0.4652 | -848.0 | -656.7 | |
| 0.00 | 1.39 | 0.00 | 0.78 | 12.38 | 306.27 | -27.29 | 73.56 | 0.4689 | -882.0 | -640.2 | |
| 1.13 | 22.28 | 0.63 | 12.46 | 11.26 | 306.33 | -27.24 | 75.88 | 0.4649 | 923.5 | 358.5 | |
| 0.00 | 4.09 | 0.00 | 2.30 | 12.85 | 306.08 | -27.49 | 72.66 | 0.4734 | -946.0 | -628.5 | |
| 0.00 | 1.13 | 0.00 | 0.63 | 8.48 | 306.51 | -27.06 | 81.84 | 0.4565 | -528.0 | -413.2 | |
| 0.00 | 4.96 | 0.00 | 2.78 | 12.01 | 306.11 | -27.46 | 74.40 | 0.4702 | -694.0 | -589.2 | |
| 5.14 | -41.00 | 2.87 | -41.00 | 11.02 | 306.18 | -27.39 | 76.46 | 0.4664 | -676.0 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.44 | 10.66 | 306.18 | -27.39 | 77.22 | 0.4655 | -740.0 | -648.4 | |
| 0.00 | 1.31 | 0.00 | 0.74 | 13.65 | 305.74 | -27.83 | 71.18 | 0.4812 | -720.0 | -566.5 | |
| 0.44 | 1.31 | 0.25 | 0.74 | 13.22 | 305.52 | -28.05 | 72.16 | 0.4829 | -904.2 | -776.1 | |
| 0.00 | 2.79 | 0.00 | 1.58 | 13.97 | 305.38 | -28.18 | 70.72 | 0.4876 | -903.0 | -722.4 | |
| 0.00 | 0.52 | 0.00 | 0.29 | 11.56 | 305.57 | -28.00 | 75.53 | 0.4769 | 554.0 | 497.7 | |
| 0.00 | 0.44 | 0.00 | 0.25 | 13.33 | 305.36 | -28.21 | 72.01 | 0.4855 | -758.0 | -598.4 | |
| 0.00 | 1.22 | 0.00 | 0.68 | 9.52 | 305.50 | -28.07 | 79.83 | 0.4734 | -711.0 | -569.0 | |
| 0.00 | 1.48 | 0.00 | 0.87 | 21.22 | 303.71 | -29.86 | 58.46 | 0.5467 | -754.0 | -626.0 | |
| 0.00 | 1.83 | 0.00 | 1.03 | 12.36 | 305.13 | -28.43 | 74.07 | 0.4857 | -600.0 | -531.0 | |
| 16.19 | 139.52 | 9.23 | 79.67 | 13.54 | 304.64 | -28.93 | 71.92 | 0.4968 | -1016.4 | 94.3 | |
| 0.00 | 1.48 | 0.00 | 0.84 | 11.83 | 304.85 | -28.72 | 75.25 | 0.4884 | -679.0 | -508.2 | |
| 0.00 | 1.57 | 0.00 | 0.90 | 14.72 | 304.47 | -29.10 | 69.71 | 0.5035 | -704.0 | -574.2 | |
| 0.00 | 1.13 | 0.00 | 0.66 | 19.36 | 303.63 | -29.94 | 61.70 | 0.5370 | -606.0 | -560.2 | |
| 0.00 | 1.13 | 0.00 | 0.64 | 11.65 | 304.80 | -28.77 | 75.63 | 0.4886 | -552.0 | -413.9 | |
| 1.57 | 6.27 | 0.90 | 3.60 | 14.57 | 303.96 | -29.61 | 70.24 | 0.5101 | -707.9 | -660.9 | |
| 0.00 | 1.22 | 0.00 | 0.70 | 14.93 | 303.91 | -29.66 | 69.58 | 0.5123 | -716.0 | -528.4 | |
| 0.00 | 0.96 | 0.00 | 0.55 | 11.48 | 304.26 | -29.31 | 76.16 | 0.4961 | 723.0 | 599.4 | |
| 0.00 | 0.96 | 0.00 | 0.55 | 11.59 | 304.04 | -29.53 | 76.02 | 0.4996 | 736.0 | 561.5 | |
| 1.57 | -55.00 | 0.90 | -55.00 | 12.27 | 303.89 | -29.68 | 74.72 | 0.5037 | 1062.2 | 999999 | |
| 0.00 | 5.92 | 0.00 | 3.40 | 12.68 | 303.62 | -29.95 | 74.02 | 0.5086 | 989.0 | 808.8 | |
| 1.48 | 15.67 | 0.85 | 8.99 | 12.19 | 303.40 | -30.17 | 75.05 | 0.5104 | 920.9 | 285.8 | |
| 1.22 | 17.76 | 0.70 | 10.26 | 12.87 | 303.07 | -30.50 | 73.87 | 0.5172 | 862.1 | 835.4 | |
| 7.40 | -67.00 | 4.27 | -67.00 | 12.41 | 303.02 | -30.55 | 74.75 | 0.5166 | 961.9 | 999999 | |
| 0.00 | 1.57 | 0.00 | 0.90 | 10.25 | 303.06 | -30.51 | 78.92 | 0.5111 | 828.0 | 614.8 | |
| 0.00 | 1.22 | 0.00 | 0.71 | 12.49 | 302.80 | -30.77 | 74.67 | 0.5200 | 544.0 | 369.1 | |
| 0.00 | 2.61 | 0.00 | 1.51 | 11.35 | 302.87 | -30.70 | 76.83 | 0.5161 | 521.0 | 518.6 | |
| 1.39 | 3.74 | 0.81 | 2.17 | 12.16 | 302.73 | -30.84 | 75.33 | 0.5201 | 869.2 | 640.6 | |
| 0.00 | 1.22 | 0.00 | 0.72 | 15.68 | 302.20 | -31.36 | 69.02 | 0.5388 | -815.0 | -595.9 | |
| 0.00 | 2.52 | 0.00 | 1.46 | 11.02 | 302.80 | -30.77 | 77.49 | 0.5164 | 796.0 | 649.2 | |
| 0.00 | 1.91 | 0.00 | 1.10 | 9.58 | 302.92 | -30.65 | 80.25 | 0.5121 | 831.0 | 722.2 | |
| 0.00 | 1.13 | 0.00 | 0.65 | 10.59 | 302.71 | -30.86 | 78.34 | 0.5169 | 590.0 | 352.4 | |
| 0.00 | 1.22 | 0.00 | 0.71 | 12.14 | 302.45 | -31.12 | 75.45 | 0.5241 | -433.0 | -379.8 | |
| 0.00 | 1.13 | 0.00 | 0.67 | 16.02 | 301.82 | -31.75 | 68.59 | 0.5455 | -717.0 | -558.2 | |
| 0.00 | 1.22 | 0.00 | 0.70 | 9.59 | 302.53 | -31.04 | 80.30 | 0.5178 | 672.0 | 552.6 | |
| 3.39 | 4.44 | 1.97 | 2.58 | 11.38 | 302.22 | -31.34 | 76.96 | 0.5256 | -729.2 | -531.2 | |
| 0.70 | 7.66 | 0.41 | 4.45 | 10.92 | 302.10 | -31.47 | 77.85 | 0.5264 | -1027.5 | -711.2 | |
| 0.00 | 0.87 | 0.00 | 0.51 | 11.64 | 301.91 | -31.66 | 76.56 | 0.5307 | -626.0 | -416.9 | |
| 0.00 | 1.39 | 0.00 | 0.82 | 12.98 | 301.58 | -31.99 | 74.18 | 0.5387 | 882.0 | 701.8 | |
| 0.70 | 2.79 | 0.41 | 1.63 | 11.02 | 301.70 | -31.87 | 77.76 | 0.5325 | -887.0 | -666.2 | |
| 0.00 | 1.74 | 0.00 | 1.02 | 13.00 | 301.36 | -32.21 | 74.22 | 0.5418 | 938.0 | 797.2 | |
| 0.00 | 0.96 | 0.00 | 0.56 | 11.71 | 301.47 | -32.10 | 76.56 | 0.5372 | -465.0 | -373.2 | |
| 0.00 | 7.57 | 0.00 | 4.46 | 13.29 | 301.24 | -32.33 | 73.72 | 0.5443 | 659.0 | 747.8 | |
| 0.00 | 0.87 | 0.00 | 0.52 | 17.06 | 300.44 | -33.13 | 67.43 | 0.5680 | 733.0 | 561.9 | |
| 0.00 | 1.13 | 0.00 | 0.66 | 10.83 | 301.32 | -32.24 | 78.22 | 0.5374 | -587.0 | -482.5 | |
| 4.87 | 53.01 | 2.88 | 31.40 | 12.53 | 301.03 | -32.54 | 75.17 | 0.5453 | 1039.4 | 670.8 | |
| 1.91 | -90.00 | 1.13 | -90.00 | 12.73 | 300.93 | -32.64 | 74.83 | 0.5473 | 1019.7 | 999999 | |
| 3.48 | -90.00 | 2.06 | -90.00 | 12.94 | 300.86 | -32.71 | 74.48 | 0.5487 | 971.5 | 999999 | |
| 0.00 | 2.18 | 0.00 | 1.31 | 17.16 | 300.12 | -33.45 | 67.40 | 0.5727 | 450.0 | 302.1 | |
| 0.00 | 1.04 | 0.00 | 0.62 | 13.51 | 300.74 | -32.83 | 73.50 | 0.5520 | 599.0 | 546.9 | |
| 3.13 | -90.00 | 1.86 | -90.00 | 13.18 | 300.71 | -32.85 | 74.10 | 0.5514 | 820.0 | 999999 | |
| 0.00 | 1.13 | 0.00 | 0.68 | 16.94 | 300.05 | -33.52 | 67.80 | 0.5728 | 734.0 | 527.6 | |
| 0.00 | 1.04 | 0.00 | 0.62 | 11.91 | 300.79 | -32.78 | 76.36 | 0.5473 | 817.0 | 609.2 | |
| 0.70 | -90.00 | 0.41 | -90.00 | 13.17 | 300.57 | -33.00 | 74.16 | 0.5534 | 695.6 | 999999 | |
| 3.74 | -90.00 | 2.22 | -90.00 | 12.68 | 300.50 | -33.07 | 75.05 | 0.5532 | 902.6 | 999999 | |
| 0.00 | 5.83 | 0.00 | 3.49 | 13.90 | 300.12 | -33.45 | 73.01 | 0.5616 | 510.0 | 689.1 | |
| 0.00 | 1.39 | 0.00 | 0.84 | 14.53 | 299.98 | -33.59 | 71.96 | 0.5654 | 610.0 | 634.7 | |
| 2.09 | 2.52 | 1.23 | 1.49 | 9.23 | 300.64 | -32.93 | 81.29 | 0.5449 | 827.0 | 785.8 | |
| 7.22 | -90.00 | 4.30 | -90.00 | 12.43 | 300.20 | -33.37 | 75.59 | 0.5567 | 925.4 | 999999 | |
| 0.00 | 3.05 | 0.00 | 1.83 | 14.67 | 299.62 | -33.95 | 71.86 | 0.5707 | 799.0 | 765.9 | |
| 2.00 | 6.61 | 1.21 | 3.98 | 14.32 | 299.42 | -34.15 | 72.52 | 0.5724 | 968.0 | 747.2 | |
| 0.00 | 1.13 | 0.00 | 0.68 | 14.71 | 299.28 | -34.29 | 71.90 | 0.5755 | 628.0 | 442.2 | |
| 2.44 | 102.62 | 1.46 | 61.89 | 12.78 | 299.52 | -34.04 | 75.15 | 0.5670 | 872.9 | 638.8 | |
| 0.00 | 0.96 | 0.00 | 0.57 | 9.38 | 299.97 | -33.60 | 81.12 | 0.5547 | 899.0 | 655.1 | |
| 0.87 | -107.00 | 0.52 | -107.00 | 12.54 | 299.49 | -34.08 | 75.59 | 0.5670 | 973.9 | 999999 | |
| 2.18 | -107.00 | 1.31 | -107.00 | 12.74 | 299.27 | -34.30 | 75.30 | 0.5704 | 939.9 | 999999 | |
| 3.83 | 43.17 | 2.32 | 26.26 | 14.18 | 298.96 | -34.61 | 72.92 | 0.5783 | 998.3 | 605.4 | |
| 3.31 | -107.00 | 1.99 | -107.00 | 12.01 | 299.23 | -34.34 | 76.57 | 0.5694 | 872.4 | 999999 | |
| 6.96 | -107.00 | 4.20 | -107.00 | 12.37 | 299.11 | -34.46 | 75.99 | 0.5719 | 910.7 | 999999 | |
| 0.00 | 1.13 | 0.00 | 0.68 | 11.56 | 299.15 | -34.42 | 77.39 | 0.5697 | 842.0 | 708.7 | |
| 14.01 | -107.00 | 8.47 | -107.00 | 12.81 | 298.93 | -34.64 | 75.27 | 0.5754 | 879.4 | 999999 | |
| 2.00 | 6.35 | 1.22 | 3.87 | 14.55 | 298.52 | -35.05 | 72.43 | 0.5853 | 453.0 | 192.9 | |
| 1.91 | -111.00 | 1.16 | -111.00 | 13.70 | 298.59 | -34.98 | 73.84 | 0.5821 | 842.2 | 999999 | |
| 6.44 | -107.00 | 3.89 | -107.00 | 11.75 | 298.83 | -34.74 | 77.12 | 0.5745 | 824.9 | 999999 | |
| 2.18 | -107.00 | 1.32 | -107.00 | 13.00 | 298.52 | -35.05 | 75.05 | 0.5814 | 591.5 | 999999 | |
| 2.35 | -111.00 | 1.43 | -111.00 | 13.78 | 298.35 | -35.22 | 73.78 | 0.5855 | 709.1 | 999999 | |
| 0.00 | 1.83 | 0.00 | 1.10 | 11.45 | 298.72 | -34.85 | 77.68 | 0.5754 | 389.0 | 479.7 | |
| 0.00 | 0.78 | 0.00 | 0.48 | 13.21 | 298.45 | -35.12 | 74.71 | 0.5828 | 428.0 | 352.2 | |
| 0.00 | 0.87 | 0.00 | 0.53 | 11.47 | 298.04 | -35.52 | 77.77 | 0.5849 | 520.0 | 332.7 | |
| 0.00 | 1.13 | 0.00 | 0.69 | 13.17 | 297.70 | -35.87 | 74.98 | 0.5929 | 211.0 | 247.8 | |
| 0.00 | 1.22 | 0.00 | 0.75 | 12.87 | 297.75 | -35.82 | 75.47 | 0.5916 | 620.0 | 377.1 | |
| 0.00 | 1.13 | 0.00 | 0.69 | 12.18 | 297.82 | -35.74 | 76.61 | 0.5892 | 553.0 | 448.4 | |
| 0.00 | 2.00 | 0.00 | 1.23 | 12.39 | 297.72 | -35.85 | 76.29 | 0.5911 | 568.0 | 480.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
