SDO HMI 2011-10-22 00:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 24.19 | 174.54 | 60.92 | 657.75 | 7.36 | 250.19 | -82.83 | 83.28 | 0.9886 | -89.5 | 71.2 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-22 00:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 11.66 | 150.25 | 27.57 | 380.95 | 6.17 | 254.62 | -78.40 | 84.82 | 0.9788 | -502.3 | -88.3 | |
| 3.13 | -1.00 | 7.62 | -1.00 | 6.14 | 254.32 | -78.69 | 84.83 | 0.9799 | 126.2 | 999999 | |
| 2.26 | -1.00 | 5.86 | -1.00 | 5.90 | 253.65 | -79.37 | 85.02 | 0.9822 | -58.5 | 999999 | |
| 7.14 | -1.00 | 19.87 | -1.00 | 6.06 | 252.85 | -80.17 | 84.79 | 0.9847 | 325.1 | 999999 | |
| 0.00 | 2.35 | 0.00 | 29.69 | 10.74 | 244.92 | -88.10 | 79.47 | 0.9990 | 158.0 | 112.7 | |
| 0.00 | 6.27 | 0.00 | 81.19 | 10.23 | 245.02 | -88.00 | 79.99 | 0.9989 | 209.0 | 154.7 | |
| 0.00 | 9.84 | 0.00 | 123.26 | 8.84 | 244.58 | -88.43 | 81.33 | 0.9993 | 416.0 | 401.3 | |
| 0.00 | 5.83 | 0.00 | 42.66 | 6.42 | 246.60 | -86.42 | 83.92 | 0.9977 | 176.0 | 126.1 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
