SDO HMI 2011-10-22 10:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 49.25 | 314.62 | 103.88 | 767.55 | 7.98 | 249.14 | -78.40 | 82.97 | 0.9750 | -141.1 | -63.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-22 10:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 20.10 | 215.49 | 32.78 | 365.04 | 6.18 | 254.82 | -72.72 | 85.19 | 0.9540 | -571.8 | -110.7 | |
| 14.62 | -1.00 | 25.16 | -1.00 | 6.12 | 253.89 | -73.66 | 85.19 | 0.9588 | -218.1 | 999999 | |
| 4.00 | -1.00 | 7.15 | -1.00 | 6.04 | 253.25 | -74.29 | 85.23 | 0.9619 | 190.8 | 999999 | |
| 0.00 | 0.87 | 0.00 | 1.68 | 4.55 | 252.13 | -75.41 | 86.69 | 0.9675 | 291.0 | 298.8 | |
| 4.61 | 95.30 | 16.21 | 392.40 | 10.22 | 244.83 | -82.71 | 80.40 | 0.9907 | 294.0 | -32.0 | |
| 0.44 | 1.57 | 1.15 | 4.13 | 6.57 | 247.80 | -79.74 | 84.30 | 0.9833 | 331.2 | 283.2 | |
| 3.39 | -5.00 | 12.85 | -5.00 | 9.34 | 244.29 | -83.26 | 81.24 | 0.9921 | 331.2 | 999999 | |
| 2.09 | -5.00 | 8.58 | -5.00 | 9.38 | 243.67 | -83.87 | 81.16 | 0.9933 | -243.3 | 999999 | |
| 0.00 | 1.39 | 0.00 | 4.30 | 6.47 | 246.37 | -81.17 | 84.29 | 0.9875 | 323.0 | 322.8 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
