SDO HMI 2011-10-22 21:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 66.17 | 480.43 | 100.48 | 766.81 | 7.63 | 249.29 | -72.19 | 83.71 | 0.9469 | -251.7 | -65.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-22 21:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.04 | 0.00 | 1.24 | 10.92 | 255.57 | -65.91 | 80.40 | 0.9109 | -270.0 | -265.3 | |
| 25.92 | 294.92 | 31.68 | 369.58 | 6.22 | 255.00 | -66.49 | 85.52 | 0.9161 | -927.5 | -198.8 | |
| 17.13 | -2.00 | 21.74 | -2.00 | 6.09 | 254.10 | -67.38 | 85.62 | 0.9222 | -426.4 | 999999 | |
| 1.39 | -2.00 | 1.78 | -2.00 | 5.65 | 253.97 | -67.51 | 86.08 | 0.9233 | -332.6 | 999999 | |
| 0.00 | 4.17 | 0.00 | 5.37 | 4.65 | 253.87 | -67.61 | 87.16 | 0.9244 | 61.0 | 47.7 | |
| 1.30 | -2.00 | 1.70 | -2.00 | 5.97 | 253.41 | -68.07 | 85.71 | 0.9269 | 141.1 | 999999 | |
| 0.00 | 1.04 | 0.00 | 1.49 | 11.22 | 251.22 | -70.27 | 79.98 | 0.9391 | -178.0 | -123.5 | |
| 0.00 | 4.00 | 0.00 | 6.19 | 5.74 | 249.76 | -71.73 | 85.71 | 0.9489 | -254.0 | -180.4 | |
| 2.70 | 7.31 | 4.61 | 12.50 | 6.66 | 247.90 | -73.59 | 84.62 | 0.9583 | 456.3 | 424.3 | |
| 0.00 | 0.96 | 0.00 | 1.84 | 9.22 | 245.76 | -75.72 | 81.84 | 0.9675 | 368.0 | 340.5 | |
| 4.44 | 151.24 | 9.24 | 336.94 | 10.26 | 244.49 | -76.99 | 80.70 | 0.9726 | 457.7 | 21.8 | |
| 1.65 | -11.00 | 3.40 | -11.00 | 9.90 | 244.78 | -76.71 | 81.09 | 0.9715 | 495.5 | 999999 | |
| 5.04 | -11.00 | 10.76 | -11.00 | 9.51 | 244.24 | -77.24 | 81.46 | 0.9737 | 470.8 | 999999 | |
| 0.00 | 9.74 | 0.00 | 18.90 | 6.50 | 245.77 | -75.72 | 84.65 | 0.9682 | 415.0 | 309.8 | |
| 0.00 | 0.70 | 0.00 | 1.37 | 6.79 | 245.63 | -75.85 | 84.34 | 0.9687 | 481.0 | 404.6 | |
| 0.00 | 5.31 | 0.00 | 11.39 | 8.75 | 244.23 | -77.25 | 82.24 | 0.9740 | 187.0 | 245.3 | |
| 1.04 | -11.00 | 2.37 | -11.00 | 9.17 | 243.49 | -77.99 | 81.76 | 0.9767 | -285.5 | 999999 | |
| 2.52 | -11.00 | 5.90 | -11.00 | 8.56 | 243.05 | -78.43 | 82.36 | 0.9784 | 240.3 | 999999 | |
| 3.04 | -11.00 | 7.30 | -11.00 | 8.53 | 242.76 | -78.73 | 82.37 | 0.9794 | -402.2 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
