SDO HMI 2011-10-22 22:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 86.96 | 394.26 | 58.73 | 264.11 | 15.51 | 279.34 | -41.59 | 72.59 | 0.6716 | -239.3 | -123.0 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-22 22:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 4.52 | 0.00 | 2.64 | 14.21 | 289.64 | -31.29 | 71.54 | 0.5330 | -745.0 | -716.8 | |
| 0.00 | 0.52 | 0.00 | 0.31 | 15.48 | 288.30 | -32.63 | 69.82 | 0.5559 | -509.0 | -531.2 | |
| 0.00 | 6.44 | 0.00 | 3.80 | 13.61 | 288.57 | -32.36 | 73.03 | 0.5460 | -848.0 | -772.4 | |
| 0.00 | 1.30 | 0.00 | 0.78 | 15.75 | 288.17 | -32.76 | 69.41 | 0.5585 | -662.0 | -561.8 | |
| 0.00 | 1.13 | 0.00 | 0.67 | 13.19 | 288.60 | -32.33 | 73.79 | 0.5444 | -779.0 | -607.4 | |
| 0.00 | 1.22 | 0.00 | 0.72 | 13.09 | 288.43 | -32.50 | 74.02 | 0.5465 | -715.0 | -557.1 | |
| 0.43 | 8.00 | 0.26 | 4.74 | 13.69 | 288.30 | -32.63 | 72.99 | 0.5500 | -752.4 | -669.3 | |
| 0.00 | 0.87 | 0.00 | 0.52 | 13.95 | 288.08 | -32.85 | 72.60 | 0.5539 | -597.0 | -517.9 | |
| 0.00 | 1.04 | 0.00 | 0.67 | 11.96 | 281.97 | -38.96 | 77.50 | 0.6324 | -532.0 | -415.5 | |
| 0.00 | 6.00 | 0.00 | 3.95 | 16.83 | 280.48 | -40.45 | 70.39 | 0.6615 | -179.0 | -189.4 | |
| 10.52 | 251.02 | 6.89 | 166.34 | 15.65 | 280.65 | -40.28 | 72.11 | 0.6565 | -1209.3 | -239.3 | |
| 22.44 | -11.00 | 14.80 | -11.00 | 15.99 | 280.20 | -40.73 | 71.72 | 0.6629 | -803.5 | 999999 | |
| 10.44 | -11.00 | 6.90 | -11.00 | 15.21 | 279.94 | -40.99 | 72.94 | 0.6644 | -961.2 | 999999 | |
| 6.78 | 19.66 | 4.48 | 12.98 | 14.20 | 279.84 | -41.09 | 74.47 | 0.6636 | -905.1 | -459.3 | |
| 16.00 | -11.00 | 10.62 | -11.00 | 14.95 | 279.63 | -41.30 | 73.40 | 0.6677 | -814.8 | 999999 | |
| 0.52 | -11.00 | 0.35 | -11.00 | 14.87 | 279.36 | -41.57 | 73.58 | 0.6709 | -442.3 | 999999 | |
| 0.00 | 2.44 | 0.00 | 1.66 | 17.23 | 278.37 | -42.56 | 70.39 | 0.6882 | -784.0 | -590.8 | |
| 0.00 | 1.04 | 0.00 | 0.71 | 17.09 | 278.02 | -42.91 | 70.68 | 0.6919 | -410.0 | -337.5 | |
| 0.00 | 1.04 | 0.00 | 0.72 | 17.00 | 277.66 | -43.27 | 70.89 | 0.6960 | -392.0 | -293.2 | |
| 1.39 | 22.61 | 0.97 | 15.77 | 17.49 | 277.04 | -43.89 | 70.36 | 0.7044 | 807.7 | 238.5 | |
| 0.00 | 1.22 | 0.00 | 0.84 | 16.43 | 277.35 | -43.58 | 71.78 | 0.6984 | -527.0 | -366.0 | |
| 0.00 | 0.35 | 0.00 | 0.24 | 14.58 | 277.54 | -43.39 | 74.38 | 0.6927 | 202.0 | 262.0 | |
| 0.00 | 2.70 | 0.00 | 1.87 | 16.34 | 276.90 | -44.03 | 72.01 | 0.7036 | 638.0 | 363.2 | |
| 2.70 | -20.00 | 1.88 | -20.00 | 17.00 | 276.67 | -44.27 | 71.13 | 0.7077 | 338.7 | 999999 | |
| 0.00 | 2.00 | 0.00 | 1.39 | 15.88 | 276.86 | -44.07 | 72.67 | 0.7032 | 648.0 | 592.3 | |
| 1.30 | -20.00 | 0.91 | -20.00 | 16.96 | 276.46 | -44.47 | 71.24 | 0.7100 | 596.7 | 999999 | |
| 0.00 | 3.57 | 0.00 | 2.49 | 16.39 | 276.63 | -44.30 | 72.00 | 0.7069 | 771.0 | 638.0 | |
| 0.00 | 1.74 | 0.00 | 1.22 | 17.19 | 276.26 | -44.67 | 70.96 | 0.7129 | 832.0 | 725.0 | |
| 0.00 | 3.31 | 0.00 | 2.32 | 16.68 | 276.37 | -44.56 | 71.65 | 0.7105 | 846.0 | 715.4 | |
| 0.00 | 0.61 | 0.00 | 0.45 | 21.20 | 274.74 | -46.19 | 65.93 | 0.7392 | 352.0 | 317.3 | |
| 0.00 | 0.61 | 0.00 | 0.42 | 13.22 | 277.18 | -43.75 | 76.39 | 0.6949 | 700.0 | 620.6 | |
| 0.00 | 1.22 | 0.00 | 0.89 | 20.60 | 274.80 | -46.14 | 66.70 | 0.7371 | 723.0 | 594.3 | |
| 0.70 | 2.61 | 0.49 | 1.83 | 16.24 | 276.23 | -44.70 | 72.29 | 0.7112 | 683.4 | 769.7 | |
| 0.00 | 1.39 | 0.00 | 0.96 | 13.99 | 276.83 | -44.10 | 75.35 | 0.7003 | 666.0 | 468.4 | |
| 0.00 | 1.48 | 0.00 | 1.05 | 16.40 | 275.83 | -45.10 | 72.16 | 0.7162 | 673.0 | 560.2 | |
| 1.04 | 1.65 | 0.74 | 1.17 | 16.48 | 275.68 | -45.25 | 72.08 | 0.7181 | 676.3 | 612.9 | |
| 0.00 | 3.13 | 0.00 | 2.22 | 16.11 | 275.70 | -45.23 | 72.58 | 0.7172 | 639.0 | 576.6 | |
| 0.00 | 1.57 | 0.00 | 1.12 | 17.09 | 275.18 | -45.76 | 71.34 | 0.7251 | 505.0 | 424.9 | |
| 0.00 | 2.52 | 0.00 | 1.81 | 16.71 | 275.03 | -45.91 | 71.89 | 0.7261 | 806.0 | 631.3 | |
| 0.00 | 0.43 | 0.00 | 0.31 | 16.85 | 274.80 | -46.13 | 71.74 | 0.7289 | 593.0 | 542.4 | |
| 0.43 | 2.17 | 0.31 | 1.57 | 16.72 | 274.66 | -46.27 | 71.95 | 0.7302 | 642.8 | 532.3 | |
| 0.00 | 1.30 | 0.00 | 0.94 | 15.13 | 274.73 | -46.20 | 74.10 | 0.7268 | 561.0 | 535.1 | |
| 0.00 | 0.43 | 0.00 | 0.32 | 16.37 | 274.37 | -46.56 | 72.49 | 0.7329 | 580.0 | 501.8 | |
| 0.00 | 2.09 | 0.00 | 1.47 | 11.39 | 275.56 | -45.38 | 79.19 | 0.7127 | 610.0 | 540.3 | |
| 0.00 | 1.91 | 0.00 | 1.39 | 16.29 | 274.12 | -46.81 | 72.64 | 0.7356 | 487.0 | 432.3 | |
| 0.00 | 0.96 | 0.00 | 0.70 | 16.64 | 273.91 | -47.02 | 72.20 | 0.7385 | 545.0 | 448.2 | |
| 0.00 | 1.22 | 0.00 | 0.89 | 15.81 | 273.90 | -47.03 | 73.32 | 0.7373 | 669.0 | 499.9 | |
| 0.00 | 2.96 | 0.00 | 2.17 | 16.02 | 273.74 | -47.19 | 73.07 | 0.7394 | 432.0 | 375.8 | |
| 0.00 | 1.13 | 0.00 | 0.82 | 11.05 | 273.95 | -46.98 | 79.80 | 0.7314 | 604.0 | 426.3 | |
| 8.70 | 14.44 | 6.46 | 10.73 | 14.83 | 272.86 | -48.07 | 74.81 | 0.7476 | 734.0 | 328.2 | |
| 3.57 | 4.26 | 2.67 | 3.19 | 15.44 | 272.49 | -48.44 | 74.04 | 0.7525 | 473.2 | 297.8 | |
| 0.00 | 0.43 | 0.00 | 0.34 | 13.03 | 269.71 | -51.22 | 77.51 | 0.7802 | 512.0 | 471.4 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
