SDO HMI 2011-10-22 23:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 77.34 | 512.19 | 114.52 | 767.33 | 7.73 | 249.51 | -70.87 | 83.68 | 0.9396 | -175.1 | -82.3 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-22 23:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.22 | 0.00 | 1.31 | 10.61 | 257.29 | -63.09 | 80.78 | 0.8899 | -433.0 | -395.9 | |
| 0.00 | 1.04 | 0.00 | 1.19 | 10.89 | 255.50 | -64.88 | 80.44 | 0.9035 | -372.0 | -265.2 | |
| 26.27 | 316.90 | 30.75 | 379.37 | 6.23 | 255.06 | -65.32 | 85.58 | 0.9077 | -967.0 | -216.5 | |
| 18.53 | -3.00 | 22.45 | -3.00 | 6.12 | 254.13 | -66.25 | 85.64 | 0.9145 | -442.9 | 999999 | |
| 1.57 | -3.00 | 1.95 | -3.00 | 5.95 | 253.48 | -66.90 | 85.80 | 0.9190 | 134.5 | 999999 | |
| 0.00 | 0.70 | 0.00 | 0.95 | 11.24 | 250.98 | -69.40 | 79.98 | 0.9339 | 49.0 | -41.6 | |
| 0.00 | 1.22 | 0.00 | 1.73 | 7.81 | 250.25 | -70.13 | 83.61 | 0.9391 | -150.0 | -59.3 | |
| 2.87 | 3.91 | 4.18 | 5.71 | 5.82 | 249.83 | -70.55 | 85.71 | 0.9422 | -289.5 | -210.8 | |
| 0.00 | 1.57 | 0.00 | 2.31 | 6.19 | 249.63 | -70.75 | 85.30 | 0.9432 | -218.0 | -187.5 | |
| 0.00 | 0.26 | 0.00 | 0.39 | 5.29 | 249.61 | -70.77 | 86.26 | 0.9436 | -106.0 | -79.7 | |
| 0.00 | 1.74 | 0.00 | 3.02 | 10.49 | 246.29 | -74.09 | 80.60 | 0.9598 | 242.0 | 198.7 | |
| 2.96 | 9.05 | 4.78 | 14.57 | 6.69 | 247.81 | -72.57 | 84.65 | 0.9531 | 450.1 | 435.4 | |
| 0.00 | 1.13 | 0.00 | 2.03 | 10.14 | 245.72 | -74.66 | 80.94 | 0.9625 | 509.0 | 442.2 | |
| 6.61 | 164.32 | 12.77 | 338.25 | 10.31 | 244.51 | -75.87 | 80.71 | 0.9679 | 479.5 | 24.7 | |
| 5.13 | -14.00 | 9.82 | -14.00 | 9.87 | 244.70 | -75.68 | 81.17 | 0.9672 | 572.4 | 999999 | |
| 7.22 | -14.00 | 14.37 | -14.00 | 9.58 | 244.14 | -76.24 | 81.45 | 0.9697 | 421.8 | 999999 | |
| 0.00 | 9.13 | 0.00 | 16.50 | 6.55 | 245.81 | -74.57 | 84.68 | 0.9630 | 477.0 | 325.2 | |
| 2.96 | -14.00 | 6.37 | -14.00 | 8.60 | 243.06 | -77.32 | 82.39 | 0.9743 | 254.2 | 999999 | |
| 3.22 | -14.00 | 7.08 | -14.00 | 8.60 | 242.77 | -77.61 | 82.37 | 0.9754 | -364.7 | 999999 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
