SDO HMI 2011-10-23 06:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 11.15 | 0.00 | 6.03 | 24.41 | 330.65 | 14.11 | 326.30 | 0.4035 | -535.9 | -458.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-23 06:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.31 | 0.00 | 0.70 | 21.31 | 333.46 | 16.92 | 315.98 | 0.3919 | -656.0 | -479.3 | |
| 0.00 | 2.00 | 0.00 | 1.10 | 25.31 | 333.34 | 16.80 | 323.00 | 0.4360 | -671.0 | -497.0 | |
| 0.00 | 1.74 | 0.00 | 0.94 | 23.32 | 331.99 | 15.45 | 322.03 | 0.3993 | -833.0 | -635.9 | |
| 0.00 | 0.96 | 0.00 | 0.52 | 24.70 | 332.09 | 15.55 | 324.09 | 0.4170 | -769.0 | -576.9 | |
| 0.00 | 0.61 | 0.00 | 0.33 | 24.08 | 330.29 | 13.75 | 326.30 | 0.3928 | -520.0 | -582.4 | |
| 0.00 | 1.48 | 0.00 | 0.80 | 24.47 | 329.59 | 13.05 | 328.21 | 0.3918 | -676.0 | -480.8 | |
| 0.00 | 1.83 | 0.00 | 0.99 | 24.95 | 329.61 | 13.07 | 328.86 | 0.3982 | -997.0 | -858.0 | |
| 0.00 | 1.22 | 0.00 | 0.65 | 26.83 | 323.03 | 6.49 | 344.69 | 0.3838 | 835.0 | 670.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
