SDO HMI 2011-10-24 04:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 67.91 | 349.16 | 37.89 | 195.08 | 15.68 | 278.85 | -25.60 | 65.12 | 0.4594 | -83.6 | -79.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-24 04:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.57 | 0.00 | 0.81 | 13.42 | 289.63 | -14.82 | 59.49 | 0.2901 | -1076.0 | -936.3 | |
| 0.00 | 1.57 | 0.00 | 0.81 | 13.60 | 289.55 | -14.89 | 59.06 | 0.2926 | -774.0 | -648.6 | |
| 0.00 | 1.39 | 0.00 | 0.72 | 12.82 | 289.41 | -15.04 | 61.70 | 0.2886 | -1050.0 | -848.2 | |
| 0.00 | 1.13 | 0.00 | 0.59 | 13.45 | 289.37 | -15.08 | 59.81 | 0.2939 | -905.0 | -776.2 | |
| 0.00 | 3.39 | 0.00 | 1.76 | 13.23 | 289.19 | -15.25 | 60.73 | 0.2949 | -937.0 | -851.6 | |
| 0.00 | 1.22 | 0.00 | 0.63 | 13.44 | 289.12 | -15.33 | 60.22 | 0.2976 | -892.0 | -660.6 | |
| 0.00 | 2.70 | 0.00 | 1.40 | 13.92 | 288.99 | -15.46 | 58.99 | 0.3032 | -854.0 | -644.3 | |
| 0.00 | 1.30 | 0.00 | 0.68 | 12.68 | 288.85 | -15.60 | 62.92 | 0.2959 | -593.0 | -456.5 | |
| 0.00 | 2.87 | 0.00 | 1.49 | 12.95 | 288.70 | -15.74 | 62.30 | 0.3000 | -878.0 | -737.3 | |
| 0.00 | 1.48 | 0.00 | 0.77 | 13.48 | 288.29 | -16.16 | 61.30 | 0.3099 | -919.0 | -712.5 | |
| 0.00 | 1.22 | 0.00 | 0.63 | 13.15 | 288.31 | -16.14 | 62.24 | 0.3072 | -875.0 | -691.3 | |
| 0.00 | 1.13 | 0.00 | 0.59 | 13.00 | 288.22 | -16.22 | 62.81 | 0.3074 | -766.0 | -660.5 | |
| 0.00 | 1.57 | 0.00 | 0.82 | 13.60 | 287.96 | -16.49 | 61.42 | 0.3155 | -812.0 | -639.6 | |
| 0.00 | 1.65 | 0.00 | 0.87 | 13.13 | 286.13 | -18.32 | 64.96 | 0.3393 | -681.0 | -475.1 | |
| 0.00 | 1.22 | 0.00 | 0.68 | 24.38 | 283.62 | -20.83 | 44.06 | 0.4676 | 800.0 | 556.8 | |
| 0.00 | 1.83 | 0.00 | 1.01 | 19.81 | 282.38 | -22.07 | 53.76 | 0.4401 | -807.0 | -619.6 | |
| 13.13 | 91.67 | 7.23 | 50.53 | 15.79 | 280.47 | -23.97 | 63.85 | 0.4374 | -1224.7 | -555.6 | |
| 0.00 | 1.30 | 0.00 | 0.73 | 19.54 | 279.90 | -24.55 | 56.82 | 0.4697 | -835.0 | -588.8 | |
| 19.66 | -17.00 | 10.86 | -17.00 | 15.87 | 279.95 | -24.49 | 64.11 | 0.4451 | -948.9 | 999999 | |
| 1.30 | 1.83 | 0.72 | 1.01 | 16.65 | 279.81 | -24.63 | 62.59 | 0.4517 | -770.8 | -842.7 | |
| 0.00 | 1.57 | 0.00 | 0.86 | 13.47 | 280.04 | -24.41 | 69.23 | 0.4316 | -881.0 | -595.3 | |
| 1.74 | -17.00 | 0.97 | -17.00 | 15.94 | 279.47 | -24.98 | 64.34 | 0.4524 | -675.9 | 999999 | |
| 11.13 | 113.07 | 6.16 | 62.79 | 15.36 | 279.51 | -24.94 | 65.51 | 0.4486 | -1077.8 | -223.8 | |
| 0.00 | 2.70 | 0.00 | 1.50 | 16.54 | 279.31 | -25.13 | 63.22 | 0.4579 | -662.0 | -557.2 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 13.46 | 279.67 | -24.78 | 69.50 | 0.4370 | -629.0 | -507.8 | |
| 2.17 | 6.61 | 1.20 | 3.64 | 13.91 | 279.55 | -24.90 | 68.60 | 0.4408 | -1037.4 | -631.6 | |
| 6.61 | -23.00 | 3.66 | -23.00 | 15.02 | 279.31 | -25.13 | 66.37 | 0.4496 | -986.9 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.44 | 16.77 | 278.94 | -25.51 | 63.05 | 0.4645 | -729.0 | -626.2 | |
| 0.00 | 1.39 | 0.00 | 0.78 | 16.59 | 278.83 | -25.62 | 63.51 | 0.4650 | -723.0 | -565.1 | |
| 0.00 | 1.22 | 0.00 | 0.68 | 17.40 | 278.43 | -26.02 | 62.21 | 0.4751 | -651.0 | -538.6 | |
| 0.00 | 0.70 | 0.00 | 0.39 | 13.70 | 277.97 | -26.48 | 70.01 | 0.4628 | -616.0 | -442.5 | |
| 0.00 | 0.87 | 0.00 | 0.49 | 13.20 | 277.65 | -26.79 | 71.22 | 0.4655 | -409.0 | -337.5 | |
| 0.00 | 1.22 | 0.00 | 0.71 | 21.63 | 276.19 | -28.25 | 56.29 | 0.5310 | 758.0 | 592.6 | |
| 0.00 | 0.96 | 0.00 | 0.54 | 14.19 | 277.36 | -27.09 | 69.34 | 0.4738 | 743.0 | 576.5 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 16.03 | 277.07 | -27.38 | 65.85 | 0.4864 | 950.0 | 743.4 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 16.20 | 276.86 | -27.58 | 65.64 | 0.4901 | 973.0 | 823.4 | |
| 0.00 | 3.48 | 0.00 | 1.97 | 15.93 | 276.84 | -27.61 | 66.19 | 0.4891 | 952.0 | 731.5 | |
| 0.00 | 2.00 | 0.00 | 1.14 | 16.23 | 276.72 | -27.73 | 65.68 | 0.4922 | 959.0 | 713.3 | |
| 0.00 | 2.78 | 0.00 | 1.59 | 16.71 | 276.61 | -27.84 | 64.83 | 0.4962 | 814.0 | 799.6 | |
| 0.00 | 0.87 | 0.00 | 0.50 | 17.14 | 276.50 | -27.94 | 64.09 | 0.4998 | 875.0 | 751.5 | |
| 0.00 | 0.96 | 0.00 | 0.55 | 17.74 | 276.40 | -28.04 | 63.03 | 0.5045 | 805.0 | 680.4 | |
| 0.00 | 1.65 | 0.00 | 0.95 | 17.56 | 276.40 | -28.05 | 63.37 | 0.5035 | 779.0 | 724.5 | |
| 0.00 | 1.65 | 0.00 | 0.96 | 19.82 | 275.88 | -28.57 | 59.66 | 0.5234 | 849.0 | 733.7 | |
| 0.00 | 2.52 | 0.00 | 1.44 | 16.70 | 276.36 | -28.08 | 65.01 | 0.4995 | 916.0 | 747.8 | |
| 0.00 | 2.26 | 0.00 | 1.30 | 17.03 | 276.13 | -28.31 | 64.54 | 0.5043 | 958.0 | 760.9 | |
| 1.91 | 5.48 | 1.10 | 3.14 | 16.96 | 275.93 | -28.51 | 64.80 | 0.5067 | 919.9 | 762.0 | |
| 0.00 | 5.22 | 0.00 | 3.07 | 21.24 | 275.00 | -29.45 | 57.87 | 0.5433 | 817.0 | 734.3 | |
| 0.00 | 0.70 | 0.00 | 0.40 | 16.55 | 275.75 | -28.70 | 65.67 | 0.5072 | 774.0 | 637.4 | |
| 0.00 | 1.57 | 0.00 | 0.93 | 21.61 | 274.77 | -29.68 | 57.43 | 0.5484 | 510.0 | 377.3 | |
| 0.00 | 2.35 | 0.00 | 1.35 | 16.79 | 275.60 | -28.84 | 65.31 | 0.5103 | 841.0 | 609.5 | |
| 0.00 | 2.17 | 0.00 | 1.25 | 17.09 | 275.45 | -29.00 | 64.86 | 0.5140 | 832.0 | 725.6 | |
| 0.00 | 1.48 | 0.00 | 0.85 | 17.48 | 275.31 | -29.14 | 64.23 | 0.5178 | 668.0 | 508.5 | |
| 0.00 | 0.70 | 0.00 | 0.39 | 11.96 | 276.00 | -28.44 | 74.53 | 0.4855 | 847.0 | 672.8 | |
| 0.00 | 1.39 | 0.00 | 0.80 | 16.99 | 275.21 | -29.23 | 65.19 | 0.5166 | 687.0 | 605.0 | |
| 0.00 | 1.30 | 0.00 | 0.75 | 16.75 | 275.22 | -29.23 | 65.63 | 0.5154 | 900.0 | 790.3 | |
| 0.00 | 1.04 | 0.00 | 0.60 | 16.16 | 275.17 | -29.27 | 66.74 | 0.5133 | 781.0 | 707.4 | |
| 0.00 | 2.52 | 0.00 | 1.46 | 16.56 | 275.07 | -29.37 | 66.07 | 0.5165 | 824.0 | 691.4 | |
| 0.00 | 1.74 | 0.00 | 1.01 | 17.46 | 274.84 | -29.60 | 64.55 | 0.5240 | 732.0 | 532.8 | |
| 0.00 | 1.22 | 0.00 | 0.71 | 18.44 | 274.66 | -29.78 | 62.92 | 0.5314 | 640.0 | 499.6 | |
| 2.52 | 5.04 | 1.46 | 2.93 | 16.94 | 274.83 | -29.62 | 65.50 | 0.5216 | 843.5 | 615.3 | |
| 0.00 | 1.22 | 0.00 | 0.69 | 11.88 | 275.56 | -28.89 | 74.86 | 0.4918 | 777.0 | 666.7 | |
| 0.00 | 1.13 | 0.00 | 0.65 | 15.18 | 275.04 | -29.40 | 68.65 | 0.5108 | 746.0 | 608.5 | |
| 0.00 | 1.30 | 0.00 | 0.75 | 15.70 | 274.96 | -29.48 | 67.73 | 0.5141 | 582.0 | 469.3 | |
| 0.00 | 1.74 | 0.00 | 1.01 | 17.52 | 274.62 | -29.83 | 64.59 | 0.5272 | 633.0 | 599.5 | |
| 0.00 | 0.96 | 0.00 | 0.55 | 16.27 | 274.73 | -29.72 | 66.80 | 0.5199 | 774.0 | 592.5 | |
| 0.00 | 0.35 | 0.00 | 0.20 | 17.36 | 274.54 | -29.91 | 64.92 | 0.5275 | 673.0 | 610.8 | |
| 0.00 | 1.48 | 0.00 | 0.85 | 14.81 | 274.92 | -29.52 | 69.41 | 0.5110 | 875.0 | 723.5 | |
| 0.00 | 1.30 | 0.00 | 0.76 | 17.44 | 274.38 | -30.07 | 64.86 | 0.5301 | 514.0 | 460.2 | |
| 0.00 | 1.22 | 0.00 | 0.71 | 16.29 | 274.51 | -29.94 | 66.88 | 0.5229 | 573.0 | 504.8 | |
| 0.00 | 1.22 | 0.00 | 0.71 | 16.16 | 274.28 | -30.17 | 67.25 | 0.5255 | 580.0 | 410.3 | |
| 0.00 | 1.13 | 0.00 | 0.66 | 16.33 | 274.10 | -30.34 | 67.02 | 0.5286 | 613.0 | 460.7 | |
| 0.00 | 0.87 | 0.00 | 0.51 | 16.17 | 273.95 | -30.49 | 67.40 | 0.5300 | 538.0 | 447.4 | |
| 0.00 | 1.13 | 0.00 | 0.65 | 11.33 | 274.57 | -29.87 | 76.30 | 0.5047 | 618.0 | 460.0 | |
| 0.00 | 1.22 | 0.00 | 0.70 | 12.95 | 273.91 | -30.54 | 73.39 | 0.5188 | 683.0 | 539.8 | |
| 0.00 | 1.65 | 0.00 | 0.96 | 12.13 | 273.73 | -30.71 | 75.01 | 0.5190 | 755.0 | 641.6 | |
| 7.74 | 13.05 | 4.53 | 7.64 | 14.73 | 273.11 | -31.34 | 70.41 | 0.5360 | 870.6 | 506.8 | |
| 0.00 | 2.61 | 0.00 | 1.52 | 12.38 | 273.34 | -31.10 | 74.66 | 0.5253 | 812.0 | 596.2 | |
| 0.00 | 1.74 | 0.00 | 1.05 | 18.13 | 271.22 | -33.23 | 65.41 | 0.5749 | 749.0 | 584.4 | |
| 0.00 | 1.65 | 0.00 | 1.00 | 18.34 | 271.17 | -33.27 | 65.08 | 0.5765 | 623.0 | 458.4 | |
| 0.00 | 1.83 | 0.00 | 1.12 | 13.91 | 268.73 | -35.72 | 73.43 | 0.5934 | 672.0 | 593.7 | |
| 0.00 | 1.74 | 0.00 | 1.09 | 15.47 | 267.74 | -36.71 | 71.19 | 0.6108 | 752.0 | 553.3 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
