SDO HMI 2011-10-24 05:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 67.51 | 338.16 | 37.48 | 187.82 | 15.52 | 278.99 | -24.91 | 64.91 | 0.4488 | -101.6 | -121.1 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-24 05:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.74 | 0.00 | 0.90 | 13.43 | 289.65 | -14.25 | 58.52 | 0.2820 | -1023.0 | -876.4 | |
| 0.00 | 3.31 | 0.00 | 1.70 | 12.64 | 289.60 | -14.30 | 61.09 | 0.2765 | -826.0 | -752.5 | |
| 0.00 | 0.96 | 0.00 | 0.49 | 12.85 | 289.46 | -14.44 | 60.65 | 0.2801 | -1142.0 | -935.7 | |
| 0.00 | 0.87 | 0.00 | 0.45 | 13.48 | 289.39 | -14.51 | 58.78 | 0.2861 | -790.0 | -658.7 | |
| 0.00 | 1.91 | 0.00 | 0.99 | 13.03 | 289.26 | -14.64 | 60.40 | 0.2844 | -916.0 | -765.2 | |
| 0.00 | 3.83 | 0.00 | 1.98 | 13.24 | 289.22 | -14.68 | 59.82 | 0.2867 | -1032.0 | -820.7 | |
| 0.00 | 1.04 | 0.00 | 0.54 | 13.45 | 289.17 | -14.73 | 59.24 | 0.2890 | -946.0 | -749.8 | |
| 0.00 | 1.91 | 0.00 | 0.99 | 13.90 | 288.98 | -14.91 | 58.20 | 0.2953 | -578.0 | -635.2 | |
| 0.00 | 4.35 | 0.00 | 2.25 | 12.96 | 288.85 | -15.05 | 61.25 | 0.2898 | -596.0 | -658.3 | |
| 0.00 | 0.96 | 0.00 | 0.50 | 13.04 | 288.25 | -15.65 | 61.90 | 0.2993 | -880.0 | -692.4 | |
| 0.00 | 1.74 | 0.00 | 0.91 | 13.16 | 286.13 | -17.77 | 64.23 | 0.3315 | -828.0 | -531.3 | |
| 0.00 | 0.96 | 0.00 | 0.51 | 17.42 | 285.19 | -18.71 | 54.68 | 0.3768 | -708.0 | -541.0 | |
| 0.00 | 1.22 | 0.00 | 0.67 | 19.82 | 282.37 | -21.52 | 53.11 | 0.4334 | -845.0 | -664.4 | |
| 12.44 | 93.76 | 6.82 | 51.46 | 15.80 | 280.47 | -23.43 | 63.36 | 0.4299 | -1200.8 | -588.0 | |
| 10.26 | -14.00 | 5.65 | -14.00 | 15.88 | 279.98 | -23.92 | 63.61 | 0.4371 | -1006.4 | 999999 | |
| 2.44 | -14.00 | 1.34 | -14.00 | 15.63 | 279.98 | -23.92 | 64.13 | 0.4358 | -939.1 | 999999 | |
| 2.09 | 2.78 | 1.15 | 1.54 | 16.63 | 279.78 | -24.12 | 62.19 | 0.4445 | -727.1 | -592.5 | |
| 3.22 | -14.00 | 1.77 | -14.00 | 16.02 | 279.79 | -24.11 | 63.46 | 0.4406 | -844.5 | 999999 | |
| 0.00 | 1.13 | 0.00 | 0.62 | 13.49 | 280.03 | -23.87 | 68.84 | 0.4238 | -927.0 | -679.7 | |
| 0.00 | 0.96 | 0.00 | 0.52 | 13.45 | 279.83 | -24.07 | 69.05 | 0.4266 | -550.0 | -516.4 | |
| 10.96 | 112.55 | 6.04 | 62.24 | 15.37 | 279.50 | -24.40 | 65.07 | 0.4411 | -1071.2 | -181.7 | |
| 0.00 | 1.65 | 0.00 | 0.92 | 16.55 | 279.28 | -24.62 | 62.77 | 0.4510 | -669.0 | -525.8 | |
| 0.00 | 1.13 | 0.00 | 0.62 | 13.44 | 279.63 | -24.27 | 69.20 | 0.4295 | -484.0 | -421.9 | |
| 2.44 | 3.39 | 1.34 | 1.86 | 13.86 | 279.55 | -24.35 | 68.32 | 0.4326 | -961.6 | -813.5 | |
| 0.00 | 1.30 | 0.00 | 0.72 | 15.76 | 279.28 | -24.62 | 64.42 | 0.4463 | -581.0 | -466.3 | |
| 11.92 | -21.00 | 6.57 | -21.00 | 14.91 | 279.32 | -24.58 | 66.19 | 0.4412 | -944.9 | 999999 | |
| 0.00 | 1.91 | 0.00 | 1.05 | 13.98 | 279.40 | -24.50 | 68.17 | 0.4354 | -726.0 | -676.1 | |
| 0.00 | 1.65 | 0.00 | 0.92 | 16.79 | 278.94 | -24.96 | 62.58 | 0.4571 | -740.0 | -656.3 | |
| 0.00 | 3.57 | 0.00 | 1.99 | 16.63 | 278.75 | -25.14 | 63.05 | 0.4587 | -597.0 | -358.5 | |
| 0.00 | 1.30 | 0.00 | 0.72 | 13.75 | 278.92 | -24.98 | 68.99 | 0.4413 | -625.0 | -500.4 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 16.38 | 278.58 | -25.32 | 63.69 | 0.4596 | -555.0 | -359.4 | |
| 0.00 | 0.96 | 0.00 | 0.53 | 13.65 | 277.91 | -25.99 | 69.82 | 0.4556 | -634.0 | -442.1 | |
| 0.00 | 1.74 | 0.00 | 0.98 | 16.07 | 276.96 | -26.93 | 65.46 | 0.4805 | 836.0 | 736.0 | |
| 0.00 | 2.87 | 0.00 | 1.62 | 16.22 | 276.84 | -27.06 | 65.26 | 0.4830 | 1008.0 | 846.1 | |
| 0.00 | 1.91 | 0.00 | 1.08 | 15.91 | 276.81 | -27.09 | 65.87 | 0.4818 | 939.0 | 819.7 | |
| 0.00 | 4.00 | 0.00 | 2.27 | 16.73 | 276.62 | -27.28 | 64.41 | 0.4886 | 766.0 | 743.1 | |
| 0.00 | 0.96 | 0.00 | 0.55 | 17.51 | 276.35 | -27.55 | 63.10 | 0.4965 | 816.0 | 656.8 | |
| 0.00 | 3.31 | 0.00 | 1.88 | 16.69 | 276.38 | -27.52 | 64.65 | 0.4917 | 879.0 | 644.6 | |
| 0.00 | 1.13 | 0.00 | 0.65 | 19.83 | 275.76 | -28.14 | 59.31 | 0.5180 | 869.0 | 629.6 | |
| 0.00 | 2.35 | 0.00 | 1.34 | 17.07 | 276.14 | -27.76 | 64.07 | 0.4970 | 956.0 | 779.4 | |
| 1.30 | 3.57 | 0.74 | 2.04 | 16.98 | 275.95 | -27.95 | 64.39 | 0.4992 | 964.7 | 675.5 | |
| 0.00 | 1.57 | 0.00 | 0.92 | 21.41 | 275.04 | -28.86 | 57.13 | 0.5372 | 802.0 | 576.3 | |
| 0.00 | 1.04 | 0.00 | 0.59 | 16.43 | 275.96 | -27.93 | 65.42 | 0.4961 | 725.0 | 585.2 | |
| 0.00 | 1.39 | 0.00 | 0.79 | 16.73 | 275.85 | -28.05 | 64.93 | 0.4993 | 864.0 | 730.6 | |
| 0.26 | 2.09 | 0.15 | 1.22 | 21.16 | 274.91 | -28.99 | 57.66 | 0.5371 | 961.7 | 814.7 | |
| 0.00 | 2.00 | 0.00 | 1.12 | 12.65 | 276.31 | -27.59 | 72.74 | 0.4752 | 786.0 | 697.9 | |
| 0.00 | 0.70 | 0.00 | 0.39 | 12.50 | 276.29 | -27.61 | 73.06 | 0.4749 | 789.0 | 586.8 | |
| 0.00 | 1.04 | 0.00 | 0.60 | 17.11 | 275.46 | -28.43 | 64.46 | 0.5064 | 840.0 | 790.3 | |
| 0.00 | 0.70 | 0.00 | 0.39 | 12.52 | 276.08 | -27.82 | 73.11 | 0.4781 | 622.0 | 627.0 | |
| 0.00 | 0.78 | 0.00 | 0.44 | 11.94 | 276.01 | -27.89 | 74.32 | 0.4773 | 825.0 | 708.6 | |
| 0.00 | 1.30 | 0.00 | 0.75 | 17.40 | 275.20 | -28.70 | 64.08 | 0.5115 | 603.0 | 486.5 | |
| 0.00 | 1.48 | 0.00 | 0.85 | 16.76 | 275.20 | -28.70 | 65.27 | 0.5082 | 874.0 | 790.0 | |
| 0.00 | 1.30 | 0.00 | 0.75 | 16.57 | 275.13 | -28.77 | 65.67 | 0.5084 | 860.0 | 747.0 | |
| 0.00 | 2.00 | 0.00 | 1.15 | 16.18 | 275.16 | -28.74 | 66.39 | 0.5061 | 741.0 | 579.1 | |
| 0.00 | 0.96 | 0.00 | 0.55 | 17.48 | 274.87 | -29.03 | 64.15 | 0.5164 | 765.0 | 638.6 | |
| 0.00 | 1.48 | 0.00 | 0.84 | 11.90 | 275.60 | -28.30 | 74.58 | 0.4832 | 831.0 | 635.3 | |
| 0.00 | 0.87 | 0.00 | 0.50 | 17.17 | 274.85 | -29.05 | 64.73 | 0.5151 | 776.0 | 603.8 | |
| 2.09 | 3.39 | 1.20 | 1.96 | 16.96 | 274.81 | -29.09 | 65.14 | 0.5145 | 885.0 | 721.1 | |
| 0.00 | 1.74 | 0.00 | 1.00 | 15.23 | 275.09 | -28.81 | 68.23 | 0.5027 | 650.0 | 515.7 | |
| 0.00 | 1.57 | 0.00 | 0.92 | 19.55 | 274.19 | -29.71 | 60.93 | 0.5365 | 639.0 | 481.3 | |
| 0.00 | 0.61 | 0.00 | 0.35 | 14.80 | 274.98 | -28.92 | 69.11 | 0.5025 | 750.0 | 590.9 | |
| 0.00 | 4.17 | 0.00 | 2.42 | 17.44 | 274.52 | -29.38 | 64.46 | 0.5209 | 597.0 | 565.0 | |
| 0.00 | 1.13 | 0.00 | 0.65 | 16.28 | 274.71 | -29.19 | 66.46 | 0.5127 | 839.0 | 661.8 | |
| 0.00 | 1.39 | 0.00 | 0.81 | 17.65 | 274.44 | -29.46 | 64.12 | 0.5230 | 539.0 | 430.2 | |
| 0.00 | 1.39 | 0.00 | 0.80 | 16.70 | 274.53 | -29.36 | 65.78 | 0.5171 | 795.0 | 547.5 | |
| 0.00 | 0.87 | 0.00 | 0.50 | 15.73 | 274.59 | -29.31 | 67.56 | 0.5119 | 728.0 | 597.7 | |
| 0.00 | 2.09 | 0.00 | 1.21 | 15.81 | 274.25 | -29.64 | 67.60 | 0.5168 | 664.0 | 507.5 | |
| 0.00 | 0.78 | 0.00 | 0.46 | 18.17 | 273.84 | -30.06 | 63.55 | 0.5337 | 536.0 | 490.9 | |
| 0.00 | 1.04 | 0.00 | 0.60 | 16.32 | 274.13 | -29.77 | 66.72 | 0.5208 | 650.0 | 502.2 | |
| 0.00 | 1.48 | 0.00 | 0.86 | 16.16 | 274.09 | -29.81 | 67.03 | 0.5207 | 505.0 | 482.6 | |
| 0.00 | 1.39 | 0.00 | 0.80 | 12.09 | 273.76 | -30.14 | 74.89 | 0.5107 | 727.0 | 653.6 | |
| 8.09 | 10.52 | 4.71 | 6.13 | 14.75 | 273.13 | -30.77 | 70.11 | 0.5282 | 881.1 | 486.1 | |
| 0.00 | 2.09 | 0.00 | 1.21 | 12.40 | 273.33 | -30.57 | 74.44 | 0.5177 | 705.0 | 592.9 | |
| 0.00 | 0.70 | 0.00 | 0.42 | 18.43 | 271.43 | -32.47 | 64.49 | 0.5665 | 608.0 | 441.4 | |
| 0.00 | 1.74 | 0.00 | 1.04 | 18.12 | 271.27 | -32.63 | 65.10 | 0.5671 | 682.0 | 583.6 | |
| 0.00 | 0.26 | 0.00 | 0.16 | 18.91 | 269.81 | -34.09 | 64.54 | 0.5894 | 462.0 | 492.7 | |
| 0.00 | 0.52 | 0.00 | 0.32 | 18.89 | 269.40 | -34.50 | 64.78 | 0.5946 | 517.0 | 411.5 | |
| 0.00 | 1.65 | 0.00 | 1.01 | 13.90 | 268.71 | -35.19 | 73.28 | 0.5863 | 786.0 | 552.5 | |
| 0.00 | 1.30 | 0.00 | 0.81 | 15.47 | 267.81 | -36.09 | 70.98 | 0.6027 | 732.0 | 504.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
