SDO HMI 2011-10-24 07:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 164.54 | 915.34 | 136.19 | 759.50 | 7.99 | 249.49 | -53.31 | 83.96 | 0.7970 | -156.5 | -76.6 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-24 07:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 1.48 | 0.00 | 1.03 | 10.62 | 257.89 | -44.92 | 80.09 | 0.7068 | -713.0 | -562.8 | |
| 0.00 | 2.17 | 0.00 | 1.53 | 11.16 | 257.31 | -45.50 | 79.39 | 0.7142 | -625.0 | -586.9 | |
| 0.00 | 1.39 | 0.00 | 0.98 | 10.70 | 257.18 | -45.62 | 80.04 | 0.7154 | -611.0 | -468.8 | |
| 0.00 | 2.52 | 0.00 | 1.86 | 10.64 | 254.92 | -47.88 | 80.28 | 0.7419 | -593.0 | -492.4 | |
| 84.97 | 495.89 | 62.09 | 363.66 | 6.34 | 255.27 | -47.53 | 86.11 | 0.7372 | -1039.3 | -304.1 | |
| 1.13 | -5.00 | 0.83 | -5.00 | 7.08 | 255.13 | -47.67 | 85.10 | 0.7387 | -688.3 | 999999 | |
| 0.00 | 0.78 | 0.00 | 0.58 | 11.02 | 254.29 | -48.51 | 79.81 | 0.7494 | -667.0 | -528.7 | |
| 0.00 | 1.57 | 0.00 | 1.17 | 11.23 | 254.25 | -48.56 | 79.53 | 0.7500 | -558.0 | -482.6 | |
| 1.48 | -5.00 | 1.09 | -5.00 | 6.84 | 254.67 | -48.14 | 85.42 | 0.7441 | -356.4 | 999999 | |
| 2.09 | -5.00 | 1.54 | -5.00 | 6.66 | 254.60 | -48.20 | 85.67 | 0.7449 | -526.2 | 999999 | |
| 1.30 | -5.00 | 0.97 | -5.00 | 6.73 | 254.41 | -48.39 | 85.56 | 0.7471 | -482.7 | 999999 | |
| 0.00 | 1.30 | 0.00 | 0.98 | 8.09 | 254.03 | -48.78 | 83.74 | 0.7514 | 118.0 | 135.1 | |
| 1.57 | -5.00 | 1.17 | -5.00 | 5.88 | 254.25 | -48.56 | 86.69 | 0.7493 | -435.9 | 999999 | |
| 0.00 | 1.30 | 0.00 | 1.00 | 5.37 | 252.92 | -49.89 | 87.31 | 0.7645 | 261.0 | 218.3 | |
| 0.00 | 1.48 | 0.00 | 1.17 | 11.87 | 251.53 | -51.28 | 78.89 | 0.7804 | -618.0 | -518.9 | |
| 0.00 | 2.17 | 0.00 | 1.68 | 6.00 | 252.42 | -50.38 | 86.47 | 0.7699 | -513.0 | -379.8 | |
| 0.00 | 2.09 | 0.00 | 1.61 | 4.99 | 252.49 | -50.31 | 87.79 | 0.7695 | 543.0 | 493.5 | |
| 0.00 | 1.30 | 0.00 | 1.04 | 11.93 | 251.21 | -51.59 | 78.82 | 0.7838 | -404.0 | -323.1 | |
| 0.00 | 0.96 | 0.00 | 0.75 | 5.34 | 251.50 | -51.30 | 87.29 | 0.7803 | -514.0 | -401.6 | |
| 0.00 | 1.57 | 0.00 | 1.24 | 5.40 | 251.11 | -51.70 | 87.19 | 0.7845 | -338.0 | -292.1 | |
| 0.00 | 1.22 | 0.00 | 0.98 | 7.36 | 250.38 | -52.42 | 84.67 | 0.7917 | -654.0 | -569.5 | |
| 0.00 | 1.13 | 0.00 | 0.91 | 6.05 | 250.58 | -52.22 | 86.33 | 0.7899 | 492.0 | 278.2 | |
| 1.22 | 6.61 | 0.99 | 5.37 | 5.93 | 250.10 | -52.70 | 86.47 | 0.7950 | -582.6 | -519.1 | |
| 0.00 | 0.61 | 0.00 | 0.52 | 11.29 | 247.69 | -55.11 | 79.80 | 0.8195 | 484.0 | 435.3 | |
| 3.04 | 9.13 | 2.64 | 7.91 | 6.72 | 247.36 | -55.45 | 85.38 | 0.8228 | 751.2 | 564.9 | |
| 0.00 | 1.04 | 0.00 | 0.92 | 9.30 | 246.44 | -56.37 | 82.24 | 0.8314 | 701.0 | 528.9 | |
| 0.00 | 1.57 | 0.00 | 1.38 | 7.37 | 246.81 | -56.00 | 84.58 | 0.8280 | 620.0 | 568.0 | |
| 0.00 | 0.96 | 0.00 | 0.86 | 8.92 | 245.76 | -57.05 | 82.70 | 0.8379 | 567.0 | 476.2 | |
| 0.00 | 0.96 | 0.00 | 0.94 | 14.84 | 242.63 | -60.17 | 75.81 | 0.8670 | -466.0 | -351.4 | |
| 0.00 | 1.83 | 0.00 | 1.70 | 8.27 | 244.72 | -58.08 | 83.46 | 0.8476 | 451.0 | 363.1 | |
| 0.00 | 1.04 | 0.00 | 0.96 | 6.28 | 245.13 | -57.68 | 85.82 | 0.8443 | 529.0 | 422.2 | |
| 32.87 | 370.40 | 31.13 | 355.85 | 10.20 | 243.97 | -58.83 | 81.18 | 0.8543 | 759.6 | 150.3 | |
| 2.00 | -32.00 | 1.89 | -32.00 | 9.68 | 243.95 | -58.86 | 81.78 | 0.8545 | 760.4 | 999999 | |
| 1.48 | -32.00 | 1.41 | -32.00 | 9.81 | 243.67 | -59.13 | 81.63 | 0.8570 | 566.7 | 999999 | |
| 2.00 | -32.00 | 1.94 | -32.00 | 9.81 | 243.19 | -59.61 | 81.64 | 0.8612 | 153.4 | 999999 | |
| 14.61 | -32.00 | 14.12 | -32.00 | 9.33 | 243.27 | -59.53 | 82.19 | 0.8605 | 565.2 | 999999 | |
| 14.78 | -32.00 | 14.38 | -32.00 | 8.74 | 243.01 | -59.79 | 82.88 | 0.8629 | 605.9 | 999999 | |
| 0.00 | 0.87 | 0.00 | 0.92 | 14.38 | 240.19 | -62.61 | 76.44 | 0.8867 | 426.0 | 378.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
