SDO HMI 2011-10-24 08:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 160.45 | 910.96 | 131.51 | 745.58 | 8.00 | 249.57 | -52.69 | 83.95 | 0.7904 | -159.9 | -90.5 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-24 08:59:01 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 0.43 | 0.00 | 0.29 | 10.43 | 259.20 | -43.06 | 80.20 | 0.6838 | -633.0 | -559.6 | |
| 0.00 | 2.00 | 0.00 | 1.38 | 10.66 | 257.94 | -44.32 | 79.99 | 0.6996 | -612.0 | -524.5 | |
| 0.00 | 1.30 | 0.00 | 0.90 | 10.80 | 257.78 | -44.48 | 79.80 | 0.7016 | -756.0 | -665.3 | |
| 0.00 | 1.13 | 0.00 | 0.79 | 11.03 | 257.61 | -44.65 | 79.49 | 0.7039 | -775.0 | -690.2 | |
| 0.00 | 2.87 | 0.00 | 2.00 | 11.16 | 257.37 | -44.89 | 79.32 | 0.7069 | -647.0 | -592.8 | |
| 0.00 | 0.87 | 0.00 | 0.63 | 10.73 | 254.86 | -47.40 | 80.12 | 0.7364 | -629.0 | -510.1 | |
| 84.44 | 499.84 | 61.09 | 362.70 | 6.37 | 255.26 | -47.00 | 86.07 | 0.7309 | -993.9 | -310.9 | |
| 1.57 | -7.00 | 1.13 | -7.00 | 7.06 | 255.17 | -47.09 | 85.13 | 0.7318 | -713.8 | 999999 | |
| 0.00 | 2.17 | 0.00 | 1.61 | 11.26 | 254.20 | -48.06 | 79.45 | 0.7444 | -560.0 | -471.4 | |
| 1.39 | -7.00 | 1.02 | -7.00 | 6.74 | 254.45 | -47.80 | 85.56 | 0.7403 | -503.9 | 999999 | |
| 0.00 | 1.30 | 0.00 | 1.02 | 11.81 | 251.53 | -50.73 | 78.92 | 0.7745 | -611.0 | -529.6 | |
| 0.00 | 1.74 | 0.00 | 1.33 | 6.22 | 252.51 | -49.75 | 86.20 | 0.7627 | -425.0 | -332.8 | |
| 0.00 | 1.48 | 0.00 | 1.13 | 6.00 | 252.40 | -49.86 | 86.48 | 0.7641 | -510.0 | -346.4 | |
| 0.00 | 1.65 | 0.00 | 1.30 | 12.00 | 251.19 | -51.07 | 78.70 | 0.7782 | -435.0 | -385.7 | |
| 0.00 | 0.78 | 0.00 | 0.60 | 4.99 | 252.42 | -49.84 | 87.81 | 0.7642 | 543.0 | 395.6 | |
| 0.00 | 1.13 | 0.00 | 0.88 | 5.35 | 251.58 | -50.68 | 87.30 | 0.7734 | -554.0 | -439.1 | |
| 0.00 | 1.74 | 0.00 | 1.37 | 5.34 | 251.10 | -51.16 | 87.28 | 0.7787 | -424.0 | -286.5 | |
| 0.00 | 0.70 | 0.00 | 0.55 | 6.09 | 250.57 | -51.69 | 86.30 | 0.7841 | 416.0 | 320.4 | |
| 0.00 | 0.87 | 0.00 | 0.69 | 7.42 | 250.27 | -51.99 | 84.60 | 0.7870 | -589.0 | -545.6 | |
| 0.00 | 0.78 | 0.00 | 0.63 | 7.56 | 250.20 | -52.06 | 84.41 | 0.7878 | -392.0 | -364.7 | |
| 2.96 | 6.61 | 2.37 | 5.30 | 6.00 | 250.14 | -52.11 | 86.40 | 0.7887 | -560.5 | -594.8 | |
| 0.00 | 0.96 | 0.00 | 0.81 | 11.08 | 248.00 | -54.26 | 80.02 | 0.8110 | 640.0 | 533.5 | |
| 1.74 | 8.26 | 1.49 | 7.06 | 6.69 | 247.24 | -55.02 | 85.43 | 0.8185 | 655.0 | 604.3 | |
| 0.00 | 1.65 | 0.00 | 1.44 | 9.31 | 246.55 | -55.71 | 82.22 | 0.8251 | 474.0 | 441.8 | |
| 1.13 | 2.61 | 0.98 | 2.26 | 7.38 | 246.80 | -55.46 | 84.58 | 0.8228 | 534.0 | 525.4 | |
| 0.00 | 1.13 | 0.00 | 1.00 | 8.96 | 245.81 | -56.45 | 82.65 | 0.8322 | 555.0 | 469.1 | |
| 1.48 | 357.32 | 1.34 | 338.37 | 10.26 | 245.08 | -57.18 | 81.09 | 0.8391 | 788.4 | 147.1 | |
| 0.00 | 1.39 | 0.00 | 1.35 | 14.86 | 242.70 | -59.56 | 75.75 | 0.8618 | -450.0 | -370.9 | |
| 0.00 | 0.78 | 0.00 | 0.72 | 8.31 | 244.74 | -57.52 | 83.42 | 0.8424 | 440.0 | 414.0 | |
| 0.00 | 0.87 | 0.00 | 0.79 | 6.29 | 245.03 | -57.23 | 85.83 | 0.8401 | 448.0 | 477.8 | |
| 27.57 | -27.00 | 25.72 | -27.00 | 10.18 | 243.96 | -58.30 | 81.20 | 0.8495 | 753.2 | 999999 | |
| 1.74 | -27.00 | 1.62 | -27.00 | 9.66 | 243.94 | -58.32 | 81.80 | 0.8497 | 716.8 | 999999 | |
| 1.74 | -27.00 | 1.64 | -27.00 | 10.39 | 243.55 | -58.71 | 80.95 | 0.8532 | 455.8 | 999999 | |
| 1.65 | -27.00 | 1.56 | -27.00 | 9.82 | 243.66 | -58.60 | 81.62 | 0.8522 | 625.1 | 999999 | |
| 0.61 | -27.00 | 0.58 | -27.00 | 9.73 | 243.27 | -58.99 | 81.72 | 0.8557 | -99.4 | 999999 | |
| 15.30 | -27.00 | 14.57 | -27.00 | 9.34 | 243.26 | -59.00 | 82.18 | 0.8558 | 568.1 | 999999 | |
| 1.65 | -27.00 | 1.58 | -27.00 | 9.78 | 243.14 | -59.12 | 81.66 | 0.8569 | 149.5 | 999999 | |
| 15.48 | -27.00 | 14.82 | -27.00 | 8.72 | 243.07 | -59.19 | 82.90 | 0.8575 | 628.3 | 999999 | |
| 0.00 | 3.91 | 0.00 | 3.86 | 10.24 | 242.03 | -60.23 | 81.13 | 0.8666 | -230.0 | -179.9 | |
| 0.00 | 0.87 | 0.00 | 0.91 | 14.81 | 240.10 | -62.15 | 75.93 | 0.8832 | 434.0 | 392.0 | |
| 0.00 | 1.04 | 0.00 | 1.09 | 14.33 | 240.21 | -62.05 | 76.47 | 0.8822 | 421.0 | 377.1 | |
| 0.00 | 0.78 | 0.00 | 0.82 | 14.53 | 239.98 | -62.28 | 76.26 | 0.8841 | 304.0 | 215.2 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
