SDO HMI 2011-10-26 10:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 23.80 | 107.85 | 25.57 | 111.31 | -21.59 | 331.31 | 56.52 | 242.04 | 0.8793 | -230.3 | -337.9 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-26 10:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 6.69 | 9.55 | 8.32 | 11.88 | -18.83 | 337.96 | 63.17 | 247.01 | 0.9192 | 429.1 | 219.0 | |
| 0.00 | 1.56 | 0.00 | 1.90 | -19.04 | 337.33 | 62.54 | 246.62 | 0.9155 | 663.0 | 578.1 | |
| 0.00 | 1.82 | 0.00 | 2.17 | -19.46 | 336.59 | 61.80 | 245.98 | 0.9115 | 606.0 | 394.9 | |
| 0.00 | 1.13 | 0.00 | 1.18 | -20.61 | 332.13 | 57.34 | 243.42 | 0.8830 | -407.0 | -323.2 | |
| 3.21 | 5.47 | 3.26 | 5.55 | -21.35 | 330.69 | 55.90 | 242.13 | 0.8744 | -498.9 | -344.0 | |
| 0.00 | 0.96 | 0.00 | 0.97 | -21.67 | 330.59 | 55.80 | 241.75 | 0.8745 | -289.0 | -252.6 | |
| 2.61 | 86.49 | 2.64 | 86.75 | -22.15 | 330.36 | 55.57 | 241.15 | 0.8742 | -390.0 | -413.2 | |
| 7.73 | -7.00 | 7.75 | -7.00 | -21.84 | 330.12 | 55.33 | 241.41 | 0.8714 | -811.1 | 999999 | |
| 1.74 | -7.00 | 1.77 | -7.00 | -22.49 | 330.45 | 55.66 | 240.82 | 0.8758 | -350.6 | 999999 | |
| 1.82 | -7.00 | 1.83 | -7.00 | -22.39 | 329.99 | 55.20 | 240.76 | 0.8721 | -688.3 | 999999 | |
| 0.00 | 0.87 | 0.00 | 0.91 | -26.68 | 329.59 | 54.80 | 236.04 | 0.8822 | -361.0 | -263.6 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
