SDO HMI 2011-10-26 17:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing)
(It is recommended to set high resolution on your display!)
| group | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 9.89 | 36.17 | 5.74 | 20.81 | 15.19 | 241.65 | -29.30 | 68.17 | 0.5106 | 41.5 | 63.8 | |
|
previous
or next observation for the same group /
back to the solar disc SDO HMI 2011-10-26 17:59:00 UT
See sunspots with tool (Click here to study sunspot positions and configurations with tool using white-light and magnetogram images and polarity drawing) (It is recommended to set high resolution on your display!) |
| spot | Proj. U | Proj. WS | Corr. U | Corr. WS | B | L | LCM | Pos. angle | r | MU | MP |
| 0.00 | 3.47 | 0.00 | 1.93 | 15.06 | 245.43 | -25.51 | 66.16 | 0.4566 | -991.0 | -817.2 | |
| 0.00 | 1.04 | 0.00 | 0.58 | 14.96 | 245.20 | -25.74 | 66.52 | 0.4594 | -715.0 | -571.2 | |
| 0.00 | 1.91 | 0.00 | 1.07 | 15.26 | 244.30 | -26.64 | 66.51 | 0.4736 | -761.0 | -419.5 | |
| 0.00 | 0.69 | 0.00 | 0.39 | 14.14 | 244.34 | -26.60 | 68.76 | 0.4677 | 806.0 | 609.4 | |
| 0.00 | 1.30 | 0.00 | 0.74 | 16.12 | 242.92 | -28.02 | 65.72 | 0.4971 | -931.0 | -681.7 | |
| 0.00 | 0.95 | 0.00 | 0.54 | 15.25 | 242.56 | -28.38 | 67.60 | 0.4981 | -629.0 | -446.5 | |
| 2.69 | 9.28 | 1.55 | 5.36 | 16.43 | 241.67 | -29.28 | 65.89 | 0.5159 | -741.2 | -59.2 | |
| 1.04 | 3.90 | 0.60 | 2.25 | 14.03 | 240.83 | -30.11 | 70.82 | 0.5174 | 886.8 | 839.3 | |
| 0.00 | 0.87 | 0.00 | 0.50 | 14.11 | 240.60 | -30.34 | 70.77 | 0.5209 | 625.0 | 566.7 | |
| 3.82 | 5.29 | 2.22 | 3.08 | 14.31 | 240.36 | -30.58 | 70.51 | 0.5250 | 857.0 | 628.3 | |
| 2.34 | 4.95 | 1.37 | 2.89 | 14.66 | 239.88 | -31.06 | 70.10 | 0.5330 | 837.2 | 686.6 | |
| 0.00 | 2.52 | 0.00 | 1.48 | 15.64 | 239.35 | -31.59 | 68.58 | 0.5440 | 733.0 | 541.7 | |
| Proj. U | - Projected umbra area in millionths of solar disc, negative values indicate | |
|
that the umbra consists of fragmented regions which cannot be separated without losing umbral area. In this way several spots (intensity minima in the umbra) have a common umbra, e.g. -2 means that the given spot shares an umbra with spot No.2, and the common U value is indicated at spot No.2. |
||
| Proj. WS | - Projected whole spot area in millionths of solar disc, negative values indicate | |
|
that several umbras have a common penumbra, e.g. -7 means that the given umbra shares a penumbra with umbra No.7, and the WS value is indicated at No.7. |
||
| Corr. U | - Corrected umbra area in millionths of solar hemisphere, for negative values see above | |
| Corr. WS | - Corrected whole spot area in millionths of solar hemisphere, for negative values see above | |
| B | - Heliographic latitude B; positive: North, negative: South | |
| L | - Heliographic longitude L | |
| LCM | - Longitudinal distance from the Sun's central meridian | |
| Pos. angle | - Position angle | |
| r | - Distance from the centre of Sun's disc in terms of Sun's radius | |
| MU | - Mean magnetic field within the umbra contour averaged the pixel values with sign. | |
| MP | - Mean magnetic field within the penumbra contour averaged the pixel values with sign. | |
